MeCan MA-HDS User Manual

Connect main unit(①) and φ37mm
conversion ring(④) for XR550V.
Install ( + ) to camera's filter
① ④
thread which is located around lens.
Instruction for connecting to each
microscope type is as follow.
Insert main unit ( )
①
directly into phototube.
If a fixating screw is
attached to phototube,
use it to secure the
adapter tightly to the
phototube.
Install ［ NY-JIS ］
fixation sleeve (sold
separately) to JIS
phototube. Then,
Insert main unit( )
①
into it and secure with
screw at the side of
［NY-JIS］.
Take out eyepiece lens
and directly install main
unit(①)
When inside diameter
of eyepiece is φ30mm,
use conversion ring(②)
※When unstable, try fixate with duct tape, or
have a support unit beneath the camera.
Screw-in C-mount sleeve
( ③ ) to microscope's
C-mount.
conversion ring ( ② ) to
main unit(
into
Secure with screw at the
side.
※ Compatible with direct (1.0x) c-mount only
Install
fixation sleeve (sold
separately)
phototube.
Insert main unit and
secure with screw at
the side of ［NY-BH］.
Install
①
), and insert
C-mount sleeve.
［ NY-BH ］
to PT
Then,
