SEA GSM-BGS5-EEN User Manual

GSM-BGS5-EEN
1. Introduction
Modem in an industrial metal aluminum case which
is suitable for installation into a control cabinet.
Modem has two communication ports (Ethernet and
USB) with adjustable watchdog. The modem is equipped with a GSM module Gemalto
(Cinterion) BGS5 rel.2. Thanks to standard Ethernet and USB interface, the modem is
suitable for fast implementation in devices that require remote communication.
The modem has JAVA OPEN PLATFORM in which you can write your own program, for
example a program for downloading and sending data from connected technology.
Etherner interface is implemented as a converter from RS232 to Ethernet.
In factory default, DHCP sever assigns dynamic IP address, name: admin ,
password: admin .

2. Package Content

1pc GSM modem
1pc 2-pin connector 3,5mm

3. Recommended Accessories

3.1 Antenna
GSM-ANT11K 2dB, Whip jointed antenna, without cable
GSM-ANT01S 5dB, magnetic, cable 3m
GSM-ANT51S 9dB, magnetic, cable 3m
GSM-ANT07S 9,5dB log–per, cable 10m

3.2 Power Supply

GSM-PWR12 Power supply adapter into socket 230V
GSM-PWR1 DIN rail mounted supply module 230VAC / 12VDC, 1.25A
Note: for DIN rail mounting inside of a cabinet suitable:
GSM-75-DIN Plastic DIN rail holder
GSM-ZIP50 Industrial 3M Dual-Lock ZIP 25x50mm for wall mounting
3.3 Cables
HW-11.99.8752 USB 2.0 AB (micro USB to a modem), length 1.8m

4. Technical Specification

Parametr
Voltage DC
Standby power.
Power Supply connected to
consumption
(PWR) GSM network
Max. power.
(call o GPRS)
consumption
POWER 2-pin removable screw terminal block, pitch 3.5 mm (PWR),
supply conn.
Power supply Voltage
via USB ** Current
Ingress IP
Protection
Storage
Temperature
Operating
Humidity Operating
Width
Dimensions Height
Length
Weight
Note: If the power supply and USB connectors are connected at the same time, current
goes only from power supply connector PWR.
** As the power consumption from USB is higher than 500mA, it is sometimes needed to
reserve the current or use powered USB hub.

5. Modem Parameters

Parameter
GSM , GPRS 12 850/900/1800/1900 MHz
(GPRS 85.6 kbps DL, 85.6 kbps UL)
Antenna connector Device - SMA (F), 50 Ohm
Internet services TCP/UDP server/client, DNS, Ping, FTP client, HTTP client
JAVA 2 MB RAM and 4 MB Flash File System
USB 2.0 Micro USB; USB2.0
Ethernet Connector RJ45
HW watchdog See the chapter Watchdog setting
6. Documentation
For USB driver, a list of AT commands and other information, visit the
www.seapraha.cz , type "GSM-BGS5-EEN" into the search box.
In the Name field, enter the text sea. In the Password box, type siemens.
GSM-BGS5-EEN_User_Manual EN v2-02.docx
/ 12V
AC DC
or
Symbol MIN. TYP. MAX.
7 V 8 to 30 33 V
DC
0,84 (70mA for 12 V )
DC
2.1
or micro USB connector
5
300 500
40
tSTG -40 +85
tA -30 +65
95
W 54
H 24
L 82
0.103
Description
If you are using WIN10 and you will use only control via AT commands, do not
download the driver, WIN10 will install its own driver automatically.
7. Hardware
7.1 Power supply and indication LEDs
Supply voltage is connected to terminals PWR and must be in the range of 7-33 V
The device is protected against overvoltage and has a built-in refundable SMD fuse. If
the external fuse is needed, use 1.25 A fuse at V
USB is higher than 500mA, it is sometimes needed to reserve the current or use powered
USB hub.
The modem can be powered directly from the USB connector. If the power supply and
USB connectors are connected at the same time, current goes only from power supply
connector PWR.
LED PWR is located on the bottom-right side of PWR connector, LED ETH is located
bottom-left side of Ethernet connector.
LED
PWR
RS232
7.2 NANO SIM card reader and GSM state indication
Insert the nano SIM card into the holder (cut corner first, contacts
up - towards the inscription SIM). The correct insertion is indicated
by mechanical click noise. Push gently and release to remove the
SIM card.
Above the SIM card holder is located the LED which indicates status of GSM.
LED
, 1A
Located
above SIM
card holder
SIM
7.3 Antenna
The antenna is connected via SMA connector. The device is fitted with SMA female. The
connected antenna must have SMA male. The impedance is 50 Ω.
7.4 Communication ports (Ethernet and micro-USB)
To communicate with the modem (AT commands) is designed interface Ethernet and
USB. The device includes a connector Ethernet RJ45 and micro-USB.
Unit
Ethernet module you can set via webserver which is included in Ethernet module (In
V
DC
factory default, DHCP sever automatically assigns dynamic IP address, name: admin ,
W
password: admin .
Ethernet module is internally connected to GSM module instead of RS232 interface.
W
Baud rate for USB is not needed to set.
You will see two COM ports in WIN Control panel. For sending AT commands you must
V
use the port, which you find in Device Manager „Modems" (Parameters/Modem). Other
mA
port is determined for JAVA application´s development.

7.5 DIN rail mounting

°C
°C
If you need to place the device into the switchboard on DIN rail, screw the plastic holder
% R.V.
GSM-75-DIN drilled hole in the side of the modem.
mm
mm
8. Warranty
mm
kg
General warranty period is 24 months after purchase, when eventual malfunction device will be repaired free of charge in
SEA spol. s r.o. while shipping to SEA is paid by customer and SEA pays for shipping back to customer.
The warranty does not cover any damage caused by wrong use which does not comply the technical specifications and
user instructions and any accidental damage (e.g. by water, lightening etc.).
SEA spol. s r.o. has NO RESPONSIBILITY for any damage, lost, costs and any other problems direct or inducted, caused
by device malfunction from any reason.
In case of incompleteness or any damage in the packaging it is necessary to inform SEA spol. s
r.o. immediately (within five days).
in accordance with the Radio and Telecommunications Terminal Equipment Directive
1999/5/EC (R&TTE) and Directive 2011/65/EU (ROHS).
We SEA, spol. s r.o., Dolnoměcholupská 21, CZ 102 00 Praha 10, ID: 47117931
(manufacturer)
declare under our sole responsibility, that product GSM modem with Ethernet a USB type GSM-BGS5-EEN
is in conformity with the following standards:
health and safety:
EMC:
radio frequency:
Place of issue: Praha
Date of issue: 19.7.2018
line. As the power consumption from
CC
COLOR
dark
... device is not supplied, or internal power
green convertor is out of order
light ... device in operation state
Blinking
... communication from the GSM module
yellow
into Ethernet module
COLOR
Device state indication.
Dark
... device failure; Device was switched of using
blue AT command
blinking 1:1 ... device starting up
1 short blink per 4 seconds
CE Declaration of conformity
EN 62368-1:2015 + Opr.1:2016 + A11:2017
EN 301489-1 v2.1.1 EN 301489-52 v1.1.0
EN 301 511 v 12.1.10
Name: Ing. Vladimír Rosůlek
Grade: director
.
DC
MEANING
MEANING
... device operational
Strana 1 z 2
