eNet radio dimming actuator 1-gang mini
eNet radio dimming actuator 1-gang mini
Art. no.: FMUD20250UP
Operating instructions
1
Safety instructions
Electrical devices may only be mounted and connected by electrically skilled persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Danger of electric shock. Always disconnect before carrying out work on the device or load. In
so doing, take all the circuit breakers into account, which support dangerous voltages to the
device and or load.
Danger of electric shock. Device is not suitable for disconnection from supply voltage. The load
is not electrically isolated from the mains even when the device is switched off.
Risk of destruction if the set operating mode and load type do not match. Set correct operating
mode when connecting or exchanging the load.
Fire hazard. For operation with inductive transformers, each transformer must be fused on the
primary side in accordance with the manufacturer's instructions. Only safety transformers ac-
cording to EN 61558-2-6 may be used.
These instructions are an integral part of the product, and must remain with the end customer.
2
Intended use
–
Switching and dimming of lighting
–
Operation with suitable radio transmitters
–
Mounting in appliance box according to DIN 49073 in combination with a suitable cover
–
Installation in surface-mounted housing or panel-mounted housing (accessories) for sus-
pended ceilings
Product characteristics
–
Switch-on via bulb-preserving soft start
–
Switch-on brightness can be saved permanently
–
Minimum brightness can be saved permanently
–
Scene operation possible
–
Status indication with LED
–
Status feedback to radio transmitter
–
Switchable with Prog. button
–
Electronic short-circuit protection with permanent switch-off after 7 seconds at the latest
–
Electronic over-temperature protection
–
Automatic or manual setting of the dimming principle suitable for the load
–
Power extension possible by means of power boosters
Can be set with eNet server:
–
Maximum brightness
–
Dimming speed
–
Switch-on delay / switch-off delay
–
Dim up/dim down ramp
–
Switch-off warning
–
Operation locks
–
Continuous on, Continuous off
–
Hotel function
–
Run-on time
82580733
J0082580733
1 / 16
14.10.2019
Advertisement
Table of Contents
Summary of Contents for Jung FM J 50700 UP
-
Page 1: Safety Instructions
eNet radio dimming actuator 1-gang mini eNet radio dimming actuator 1-gang mini Art. no.: FMUD20250UP Operating instructions Safety instructions Electrical devices may only be mounted and connected by electrically skilled persons. Serious injuries, fire or property damage possible. Please read and follow manual fully. Danger of electric shock. -
Page 2: Operation
eNet radio dimming actuator 1-gang mini – Light control Supplementary functions with eNet Server: – Fully encrypted radio transmission (AES-CCM) from eNet Server software version 2.0 – Update of the device software – Repeater function – Reading of error memory Behaviour after mains voltage return The response after mains voltage return can be configured with the eNet server. - Page 3 eNet radio dimming actuator 1-gang mini Connect 600 Watt LED lamps or compact fluorescent lamps at most per 16 ampere circuit breaker. When connecting transformers, observe the data of the transformer manufac- turer. Our dimmers take into account the different electronic characteristics of most LED lamps found on the market.
- Page 4 eNet radio dimming actuator 1-gang mini ￭ Perform commissioning. In installation positions that are not easily accessible, turn the operating mode switch to position PC after commissioning and performing a function test. Subsequent changes to the device settings can thus be carried out with the aid of the eNet Server without in- volving excessive installation work.
-
Page 5: Technical Data
eNet radio dimming actuator 1-gang mini All On and All Off buttons of a radio transmitter are disconnected automatically as soon as the last connection to the radio transmitter is disconnected. Manual disconnection is not possible. Resetting actuator to default setting All connections to radio transmitters are disconnected and parameters are reset to default set- ting. - Page 6 eNet radio dimming actuator 1-gang mini Figure 4: Connected load If the operating mode is set to HV-{ LED trailing edge phase control, the maximum connected load for LED lamps increases to typ. 200 W. Mixed load ohmic-inductive 20 ... 250 VA ohmic-capacitive 20 ...
-
Page 7: Parameter List
eNet radio dimming actuator 1-gang mini Parameter list The device parameters can be changed with the eNet server: Device and channels Parameters Setting options, Basic setting Explanations Function Light, unused Light Basic setting: Light The channel is integrated for the "Lighting" central function in the eNet SMART HOME app. - Page 8 eNet radio dimming actuator 1-gang mini Parameters Setting options, Basic setting Explanations ness, then the system will switch to the appropriate limit value. Minimum brightness 1...67 % Specifies the minimum set- Basic setting: 5 % table brightness. Note: If parameters or scene values are set to a level lower than the minimum brightness, then the system will dim to...
- Page 9 eNet radio dimming actuator 1-gang mini Parameters Setting options, Basic setting Explanations If scenes are recalled or switching uses logic modules, the switch-on brightness is ap- proached using so-called soft dimming (not configurable). Dim down ramp 0 s … 24 h Time until reaching minimum Basic setting: 0 s brightness.
- Page 10 eNet radio dimming actuator 1-gang mini Parameters Setting options, Basic setting Explanations reset the counter to "0". The device must be programmed to apply the change. Extended channel settings Parameters Setting options, Basic setting Explanations Operating mode Normal operation see Device and channels Continuous on Continuous off Basic setting: Normal Opera-...
- Page 11 eNet radio dimming actuator 1-gang mini Parameters Setting options, Basic setting Explanations dimming principle. Connection of incandescent lamps, HV halogen lamps, dimmable in- ductive transformers for halo- gen or LED lamps. Trailing edge phase control Dimming principle, trailing edge phase control. Connec- tion of incandescent lamps, HV halogen lamps, Tronic transformers for halogen or...
- Page 12 eNet radio dimming actuator 1-gang mini Parameters Setting options, Basic setting Explanations command restarts the time for the switch-off warning. Note: The set time apply to operation using radio transmit- ters. The device is switched immediately when the Prog button is pressed. Priority, lock-out protection 0...4 Specifies the priority for recall-...
- Page 13 eNet radio dimming actuator 1-gang mini Parameters Setting options, Basic setting Explanations Activate sun protection bright- 0…100 % Defines the behaviour of the ness value Basic setting: 100 % output on activating the sun protection. Deactivate sun protection 0…100 % Defines the behaviour of the brightness value Basic setting: 0 %...
-
Page 14: Troubleshooting
eNet radio dimming actuator 1-gang mini Parameters Setting options, Basic setting Explanations %, then the system dims to the set minimum brightness when the hotel function is ac- tivated. Information window In the Information window, the load can be controlled and the information about the device can be displays. -
Page 15: Warranty
Art. no. KMLED230U Conformity Albrecht Jung GmbH & Co. KG hereby declares that the radio system type art. no. FMUD20250UP meets the directive 2014/53/EU. You can find the full article number on the device. The complete text of the EU Declaration of Conformity is available under the Internet address: www.jung.de/ce... - Page 16 1-gang mini ALBRECHT JUNG GMBH & CO. KG Volmestraße 1 58579 Schalksmühle GERMANY Telefon: +49 2355 806-0 Telefax: +49 2355 806-204 kundencenter@jung.de www.jung.de 82580733 14.10.2019 16 / 16 J0082580733...
