Illumination SF100 Installation Instruction

Installation Instruction
For Lithe 100 Family
REMODEL NON-INSULATED CEILING INSTALLATION TYPE
New construction non-insulated ceiling installation type
WARNING
&
CAUTION
WARNING
&
CAUTION
Type
It is IMPORTANT TO READ instruction sheets completely before installation
LTE100RXX-XXXX-X-RM
Light Engine Kit
LTE100SXX-XXXX-X-RM

Components Delivered

LTE100RME1-XXX
Power-supply
1x Light engine kit
Assembly
LTE100RMA3-XXX
Frame Kit LTE100FK-RD(SQ)
Components Delivered
1x Light engine kit
1

Make ceiling cutout

1
Prepare frame kit for ceiling installation
a. Make sure end tab on hanger bars is
facing outward.
b. Extend bar hangers to fit between
joists and position fixture by
hammering nail on bars into the joists.
c. Use T-Bar slot in the bottom of the
©2020 LF ILLUMINATION LLC
hanger bars for suspended ceilings,
We reserve the right to change or
bending the tabs to hold T-Bar tightly.
withdraw specifications without prior notice.
1. This luminaire must be installed in accordance with National Electrical Code and
local electrical and construction regulations. To assure full compliance with local
codes and regulations, check with your local electrical inspector before installation.
2. To prevent electrical shock, turn off electricity at fuse box before installation.
3. Product is not rated for insulation contact. Do not install insulation within 3 inches of
fixtures sides or drivers sides.
4. Do not exceed product specified luminaire voltage. Any other source will void
warranty.
5. Do not install if luminaire, parts or connectors are damaged.
6. Product must be installed with provided LF Illumination drivers and housings only.
Use of other manufacturers' components will void warranty.
Input
Model No.
Voltage
120-277V
120-277V
1x Power supply
HEADQUARTERS
9200 Deering Avenue
Chatsworth CA 91311
Wattage Frequency Lumen
1200lm
1200lm
20W 50/60Hz
1x Power supply assembly
20W 50/60Hz
assembly
2

Run wires to power supply assembly

Telephone: 818-885-1335
Toll Free: 855-885-1335
Fax: 818-576-1335
SF100 Series

INSTALLATION INSTRUCTIONS

Cutout Dimming Type
Ø105mm(4.13")
□105mm(4.13")
TRIAC/ELV
(DIM ON 120V)
1x Frame kit
Flex-conduit connector/
duplex connector
(supplied by others)
www.lfillumination.com
0~10V
PAGE 1
rev: 012220
