Solartron OD5 User Leaflet

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OD5
USER LEAFLET
©
Copyright 1995
501569
Issue 10
July, 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OD5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Solartron OD5

  • Page 1 USER LEAFLET © Copyright 1995 501569 Issue 10 July, 2005...

  • Page 2: Safety Summary

    SAFETY SUMMARY 1. Safety Characteristics This apparatus has been tested in accordance with IEC publication 348, Safety Requirements for Electronics Measuring Apparatus, and supplied in a safe condition. This manual contains some information and warnings which must be followed by the user to ensure safe operation and to retain the apparatus in a safe condition.

  • Page 3: Service Safety Summary

    SERVICE SAFETY SUMMARY FOR QUALIFIED SERVICE PERSONNEL ONLY Refer also to the preceding Safety Summary This product contains no user serviceable parts Adjustments may be made to the internal gain settings by qualified personnel, Chapter 3 paragraph 3.6 refers. Do Not Service Alone Do not perform internal adjustment of this product unless another person capable of rendering first aid and resuscitation is present.

  • Page 4: Table Of Contents

    LIST OF CONTENTS PAGE SECTION Safety Summary ........... Service Safety Summary ........... List of Contents ........... List of Drawings ........... List of Tables ........... 1. GENERAL 1.1 Introduction ........... 1.2 Specifications ........... 1.3 Safety Considerations ........... 1.4 Instruments Covered by Manual ...........
  • Page 5 5. SETTING UP 5.1 Gain ........... 6. CALIBRATION 6.1 Calibration with Standard Solartron Transducers......6.2 Calibration using Phase Adjustment ........... APPENDIX A General Transducer Connections (LVDT) ..........B General Transducer Connections (MACH 1) ..........C Specifications ..........Return of Goods...

  • Page 6: List Of Drawings

    LIST OF DRAWINGS FIGURE TITLE PAGE Instrument Identification Protective Cover Voltage Selection Switch Mounting Bars Internal Option Links Connector 3 Connector 1 and 2 Voltage Output Current Output LIST OF TABLES TABLE TITLE PAGE Link Position Gain Selection Connector 3 LVDT Connections Connector 2 Designation Gain Selection...

  • Page 7: General

    The self-contained unit offers excellent characteristics, together with full flexibility and ease of use. For the industrial user, the OD5 will provide facilities for diverse applications such as automatic processing, testing, etc., both on the shop floor or in the laboratory. In more scientific fields, the unit will find favour due to its versatility and adaptability to a wide range of transducers.

  • Page 8: Installation

    If the contents are incomplete, or if there is a mechanical damage or defect, or if the instrument does not pass the operator’s checks, notify the nearest Solartron Metrology office. Keep the shipping materials for carrier’s inspection.

  • Page 9: Protective Cover

    Securing Screws Protective Cover Link 2 Frequency Zero Gain Link 4 Filter Phase R B W G Link 1 Gain CON1 Link 3 CON2 Filter LVDT Connector Output Connector Fig. 2.1 - Protective Cover 120V 250V Note: Switch SW1 shown in 250V operation position.

  • Page 10: Mounting

    2.6 MOUNTING The instrument is supplied with two (2) mounting bars that may be fitted to the base of the OD5 box. These bars in turn provide accessible fixing holes for mounting the instrument into a jig or fixture. 2.6.1 Fitting Mounting Bars To fit the optional mounting bars perform the following steps.

  • Page 11: Options

    OPTIONS 3.1 INTRODUCTION The OD5 has optional excitation frequencies of 2.5kHz and 5kHz which allow the device to operate with all standard Solartron Displacement and Gauging LVDT’s. Selection of the excitation frequency is by internal link settings. 3.2 5kHz OPERATION The 5kHz excitation frequency is required for operation with standard Solartron Gauging and Displacement LVDT’s calibrated at 5kHz.

  • Page 12: Gain Selection

    Link 2 Link 4 Link 1 Link 3 CON1 CON2 Fig. 3.1 - Internal Option Links Frequency Frequency Selection Filter Selection Link 2 Link 3 Link 4 5.0kHz 2.5kHz = Position of Shorting Link Table 3.1 - Link Position 3.6 GAIN SELECTION Link 1 allows selection of Hi and Lo gain.

  • Page 13: Electrical Connections

    Input (-) Case Screen/Shield Table 4.1 - Connector 3 Fig. 4.1 - Connector 3 4.2 TRANSDUCER CONNECTIONS LVDT Connections - The following connections for standard Solartron transducers should be made: AX/AC/MACH 1 (5kHz) MACH 1 (2.5kHz) Pin Number Function Series...

  • Page 14: Non-Standard Connections

    Fig. 4.2 - Connector 1 and 2 4.5 OUTPUT CONNECTIONS The output of the OD5 is simultaneously available as a ±5V DC or ±20mA current source/sink (with reference to CON2 Pin 2 ground). From the connector block CON2 situated on the PCB wires connecting to CON2 should be passed through the adjacent hole in the case.

  • Page 15: Power Connections

    Earth (Ground) Blue to N Neutral Brown to L Live (Hot) The power supply line must contain a switch or other adequate means for isolation of the power supply from the OD5. 501569 Issue 10 15 of 20 July, 2005...

  • Page 16: Gain Selection

    SETTING UP 5.1 GAIN SELECTION The OD5 is designed to operate with a transducer having a full scale output in the range 17-1,000mV/V. An internal link allows selection of Hi and Lo gain ranges (ref. section 3.6). Multi turn potentiometers allow fine adjustment of phase, zero and span settings.

  • Page 17: Calibration Using Phase Adjustment

    CALIBRATION 6.1 CALIBRATION WITH STANDARD SOLARTRON TRANSDUCERS With reference to Section 5 select the appropriate link 1 position. Unplug transducer and insert a link between pins 4 and 5 of connector 3. Adjust the zero control for zero output of the conditioner. Remove the link and replace the transducer.
  • Page 18 Plug connections apply to DIN standard 5-way 240° type. Where screen is used, connect to case of plug. Ensure that elsewhere the screen is isolated electrically. Cable colours are as fitted to Solartron transducers. Increase of element impedance marked P gives a positive going voltage output.
  • Page 19 Do not extend beyond standard cable length fitted to transducer. Plug connections apply to DIN standard 5-way 240° type. Cable colours are as fitted to Solartron transducers. Increase of element impedance marked P gives a positive going voltage output. Yellow/Black...

  • Page 20: Instruments Referred To By This Manual

    APPENDIX C Common Specification Power Supply Oscillator/Demodulator Power Supply 250V AC 50-60Hz Oscillator frequency 2.5 or 5kHz Sinusoid or 120V AC 50-60Hz Oscillator output voltage 3V rms Oscillator max. current 20mA 4W (Max.) Input sensitivity for rated output Lo 35 to 1000mV/V Loading Hi 17 to 500mV/V Fuse Rating...
