Zero GR250BC Installation, Service And User Instructions Manual

L.p. gas double lid bottle cooler

Advertisement

Quick Links

Installation, Service and User
INSTRUCTIONS
ZERO MODEL: GR250BC
L.P. Gas Double Lid Bottle Cooler
ZERO APPLIANCES (PTY) LTD
Cat. I
& I
3+ (28–30/37)
3B/P (30)
WARNING: THIS APPLIANCE MUST BE EARTHED
ENSURE THAT THE GAS SUPPLY HOSE IS NOT IN
CONTACT WITH OR NEAR THE BURNER BOX

Advertisement

loading
Need help?

Need help?

Do you have a question about the GR250BC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Zero GR250BC

  • Page 1 Installation, Service and User INSTRUCTIONS ZERO MODEL: GR250BC L.P. Gas Double Lid Bottle Cooler ZERO APPLIANCES (PTY) LTD Cat. I & I 3+ (28–30/37) 3B/P (30) WARNING: THIS APPLIANCE MUST BE EARTHED ENSURE THAT THE GAS SUPPLY HOSE IS NOT IN...
  • Page 2: Technical Data

    Page 1 TECHNICAL DATA Zero Appliances Model GR250BC Category: For use on Butane at 2.8 - 3.0 kPa 3+ (28-30/37) and Propane at 3.7 kPa. For use on Butane and Propane 3 B/P (30) mixtures at 3.0 kPa Declared Rate: Injector size 0.42mm diameter, marked ‘13’...
  • Page 3 Page 2 INSTALLATION INSTRUCTIONS: IMPORTANT INFORMATION FOR THE USER This appliance may only be installed by a registered LP Gas installer. All registered installers are issued with a card carrying their registration number. Ask to be shown the card before allowing the installation work to commence and make a note of the Installer QCC number.
  • Page 4 Page 3 GAS CONNECTION: The appliance inlet is to the 8mm plain straight tube, allowing connection by means of a gas-tight compression fitting to comply with both EC and local regulations. The cooler is suitable for connection to butane at 2.8-3.0 kPa and to propane at 3.7 kPa. Means must be provided to turn off the gas supply.
  • Page 5 Page 4 OPERATING INSTRUCTIONS FOR COOLER It is important to read through these instructions carefully before operating the cooler. This instruction manual should be kept in a safe place for future reference. GAS THERMOSTAT OPERATION USER OPERATING INSTRUCTIONS Note: Appliance cannot be run off 2 heat sources at the same time. TO START GAS OPERATION 1.
  • Page 6 Page 5 TROUBLESHOOTING IF THE COOLER FAILS TO WORK Check the following points before calling for service: 1. That the instructions for starting the cooler have been followed. 2. The cooler is level. 3. If the cooler fails to work check: a) That the gas bottle is not empty.
  • Page 7 Page 6 SOME USEFUL HINTS Make sure that: 1. Defrosting is carried out periodically. 2. The cooler is clean and dry with the lid open when it is not to be used for some time. If the appliance is fitted with a locking device – remove key to prevent accidental locking.
  • Page 8 Page 7 DEFROSTING Frost may gradually accumulate on the cooler surface. It must not be allowed to grow thick as it acts as an insulator and adversely affects cooler performance. Check the formation of frost regularly and when it gets around 5mm thick, defrost the cooler.
  • Page 9: In The Event Of Failure

    Page 8 IN THE EVENT OF FAILURE If the burner will not light: Check adequate gas supply – through to the burner. Depress flame failure device for 15sec and try lighting with a match. This must be done in a well ventilated area! Check injector is clean –...
  • Page 10 Page 9 THERMOSTATICALLY CONTROLLED GAS BURNER PARTS LIST 1. SANS BRASS HOSE TAIL. 2. GAS THERMOSTAT. 3. CAPILLARY WIRE. 4. FLAME FAILURE DEVICE. 5. M10 NUTS. 6. M10 x 3/8 UNF JET HOLDER. 7. M10 x 1 JET RETAINER. 8. THERMOCOUPLE. 9.
  • Page 11 Made in South Africa (Pty) Ltd...
