EARSHOT INNOVATIONS Chameleon 2001 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Chameleon 2001 and is the answer not in the manual?

Questions and answers

Summary of Contents for EARSHOT INNOVATIONS Chameleon 2001

  • Page 3 Introduction We at Earshot Innovations, LLC would like to extend our sincere gratitude for your decision to purchase a Chameleon Headset ™ . The #1 choice in versatile hands-free headsets. ™ Your Chameleon Headset has been engineered and manufactured to the highest quality standards. Earshot Innovations, LLC is dedicated to bringing you more comfort, greater durability and superior sound clarity then the original equipment manufacturer.

  • Page 4: Table Of Contents

    Table of Contents Introduction: ................. ¡ Table of Contents: ..............¡¡ Anatomy of a Chameleon ............ 1 Monaural p/n 2001 ............. 1 Binaural p/n 2002 ............2 Classic Convertible Configurations p/n 2003 ...... 3 Classic Convertible p/n 2003 Headband Components ..4 Classic Convertible p/n 2003 Ear Loop Components ..
  • Page 5 To Disassemble The Speaker Housing From The Ear Loop ........17 To Assemble the Speaker Housing To The Headband ........18 To Disassemble The Speaker Housing From The Headband ........19 Rapid Release ™ Connector ........... 20 ™ Connecting the Rapid Release Connector ......

  • Page 6: Anatomy Of A Chameleon

    ANATOMY OF A CHAMELEON Monaural p/n 2001 Adjustable High efficiency full Non-slip ratcheted anodized metal spectrum speaker mic boom headband for superior sound (Rotates 270º) clarity Padded T-bar Commercial grade ™ Metal Flex foam earpad for mic boom added comfort ™...

  • Page 7: Binaural P/N 2002

    Binaural p/n 2002 Adjustable anodized metal headband Non-slip ratcheted mic boom High efficiency full (Rotates 270º) spectrum speakers for superior sound clarity Commercial grade foam earpad for Metal Flex ™ added comfort mic boom ™ Rapid Release connector Voice Trap ™...

  • Page 8: Classic Convertible Configurations P/N 2003

    CLASSIC CONVERTIBLE CONFIGURATIONS p/n 2003 Headband Configuration Ear Loop Configuration...

  • Page 9: Classic Convertible P/N 2003 Headband Components

    CLASSIC CONVERTIBLE p/n 2003 HEADBAND COMPONENTS Adjustable anodized Leatherette metal headband earpad 23mm high efficiency digital Padded speaker with T-bar Acoustic Shock Protection Headband Ring Release™ Clothing Connector Clip All items shown included with purchase...

  • Page 10: Classic Convertible P/N 2003 Ear Loop Components

    Classic Convertible p/n 2003 Ear Loop Components Ball and socket Post for a full Vinyl earpad range of speaker movement Ear loop with a Commercial grade malleable Gumby- foam earpad for like material to added comfort ensure a comfortable and stable fit Optional Foam Windscreen...

  • Page 11: Patch Cords

    Voice E-mail, PC Video Solutions for hands-free convenience. Conferencing, Digital appropriate part Others however, require Recording, Computer number per your system. the use of an adapter not Gaming, Voice/Data currently available from modems and much more. Coiled cord sold sperately. Earshot Innovations, LLC.

  • Page 12: Set-Up For Chameleon Headsets

    Set-Up for Chameleon Headsets Chameleon Headsets ™ have been designed to work with virtually every major brand of corded and cordless modular headset amplifiers, business telephone systems equipped with a "headset jack", cordless and mobile telephones and computer sound cards. If your corded telephone or telephone system is not equipped with a designated "headset Jack,"...

  • Page 13: Basic Operation

    Basic Operation Your Chameleon Headset ™ has been designed to adapt seamlessly to virtually any communication product and computer sound card. Your new headset will not alter in any way the functionality of your current communication product or computer sound card. All of the current features of your communication product or computer sound card will function the same as they always have.

  • Page 14: Putting Your Headset On P/N 2001 And P/N 2002

    Putting Your Headset On p/n 2001 and 2002 NOTE See Page 12 for Set-Up of Convertible Headsets. To put your headset on, slide the headband entirely open to its largest size. Place the headset on your head so that the speaker(s) are on your ear(s) in a comfortable position.

  • Page 15: Rotating The Metal Flex Microphone Boom

    ™ Rotating the Metal Flex Microphone Boom To rotate the Metal Flex ™ microphone boom for wear on the left or right ear, simply rotate the microphone boom downward to the opposite side. NOTE: Your Chameleon ™ Headset features two internal STOP mechanisms which prevent...
  • Page 16 The housing of your Voice Trap ™ noise canceling microphone is round in the front and flat in the back. You can recognize this by either removing the foam windscreen or feeling it through the foam while still on the microphone housing. FRONT BACK (round)

  • Page 17: Set Up For Convertible Headset

    Set-Up for Convertible Headset Rotating the Metal Flex™ Microphone Boom To rotate the Metal Flex™ microphone boom for wear on the left or right ear, simply rotate the microphone boom downward to the opposite side. NOTE: Your Chameleon Headset™ features two internal STOP mechanisms which prevent the microphone boom from rotating 360º...

  • Page 18: To Assemble The Speaker Housing To The Ear Loop

    To Assemble The Speaker Housing To The Ear Loop To assemble the speaker housing to the ear loop, first adjust Post the post at the top of the ear loop Hole in so that it is aligned vertically. speaker housing Then align the post with the hole found at the top of the speaker housing (the hole is located at the opposite end of where the headset cable exits the speaker housing).

  • Page 19: Putting Your Headset On Using The Ear Loop

    Putting Your Headset On Using the Ear Loop To put the ear loop on the ear, first determine which ear you will rest the speaker housing on. If you wish, choose one of the two earpads included in the headset box and place it on the speaker housing at this time.
  • Page 20 The end of the loop should tuck behind your ear lobe. Tug slightly at your ear lobe and continue to curl malleable loop to ensure the headset is secure on the ear as Ear loop desired. behind ear lobe Now firmly on your ear, you may also push the speaker housing back towards the loop so that the back end of the speaker rests slightly inside the ear behind your cartilage.

  • Page 21: Clothing Clip

    While holding the headset in place with one hand, use other hand to rotate the microphone boom to desired position Clothing Clip To relieve the weight of the cord from the headset top, secure the clothing clip to your shirt or blouse in a comfortable location.

  • Page 22: To Disassemble The Speaker Housing From The Ear Loop

    To Disassemble The Speaker Housing From The Ear Loop IMPORTANT: Never attempt to separate the ear loop and speaker housing by pulling on either the microphone boom or headset cable. To separate the speaker from the ear loop, first hold the top of the ear loop firmly in one hand.

  • Page 23: To Assemble The Speaker Housing To The Headband

    To Assemble The Speaker Housing To The Headband To snap the speaker unit into the headband ring, first align the speaker unit with the opening on the back of the headband ring. The headset cable exiting the bottom of the speaker housing should be at 6:00 o’clock.

  • Page 24: To Disassemble The Speaker Housing From The Headband

    To Disassemble The Speaker Housing from the Headband IMPORTANT: Never attempt to separate the speaker housing from the headband ring by pulling on either the microphone boom or the headset cable. To disassemble the speaker housing from the headband ring, first hold the headband ring so that the fingers of both hands are placed on the headband ring with the speaker facing you.

  • Page 25: Rapid Release Connector

    ™ Rapid Release Connector Your Chameleon Headset ™ Rapid Release ™ connector features spring-loaded gold plated contact pins that are guaranteed against wear and defect for over 200,000 cycles (the highest number in the industry). ™ The Rapid Release connector is also the point where your ™...

  • Page 26: Connecting Your Chameleon Headset Coiled-Cord To A Modular Headset Amplifier Or Business System Telephone

    ™ Connecting your Chameleon Headset Coiled Cord to a Modular Headset Amplifier or Business System Telephone Replace the original equipment manufacturer’s coiled-cord from your amplifier with your new Chameleon Headset ™ coiled-cord by unplugging the modular plug at the end of the coiled-cord from your modular headset amplifier from the jack marked HEADSET or ( Connect the modular plug at the end of your new Chameleon ™...
  • Page 27 Then plug the 2.5mm gold-plated plug into the appropriate 2.5mm jack on the desired communication product. NOTE: Most mobile telephones come equipped with a 2.5mm jack for hands-free convenience. Others however, require the use of an adapter not currently available from Earshot Innovations, LLC. Communication Device Chameleon...

  • Page 28: Connecting Your Chameleon Headset Pc Cord To A Computer Sound Card

    ™ Connecting Your Chameleon Headset PC Cord to a Computer Sound Card ™ ™ Your new Chameleon Headset features a Rapid Release PC cord with two 3.5mm gold plated plugs and In-Line Volume Control. The ™ Chameleon Headset top will connect with the enclosed Chameleon ™...

  • Page 29: Chameleon Care And Maintenance

    Chameleon Care and Maintenance We suggest that you keep your Chameleon Headset ™ looking and feeling like new by replacing the ear-pads and windscreen every six to eight months. Call us for all your replacement needs at (877) 773- 7797. ™...

  • Page 30: Chameleon Troubleshooting Tips

    Chameleon Troubleshooting Tips Headset does not receive or transmit... 1. Check the headset connection to the communication product or computer ™ sound card and/or the Rapid Release connection. 2. Check that the batteries of the communication product you are connected to are not dead.

  • Page 31: Still Having Problems

    Continued from previous page: ™ If using the Chameleon Headset with a modular headset amplifier or computer sound card... 1. Adjust the Microphone Transmit Adjustment on your modular headset amplifier or computer sound card. Refer to the Owner's Manual of your modular headset amplifier or computer sound card.

  • Page 32: Chameleon Service Information

    Chameleon Service Information If it becomes necessary to return your Chameleon Headset ™ repair, contact the Earshot Innovations, LLC Customer Solutions Hot- Line for a Return Merchandise Authorization (RMA) number. When mailing the headset(s) for service, please use the original headset container or pack the headset(s) in a sturdy container with sufficient packing material to reduce the possibility of damage in transit.

  • Page 33: Unlimited Two Year Warranty

    The sole responsibility of Earshot Innovations, LLC under this warranty shall be limited to the repair or replacement of the product at the sole discretion of Earshot Innovations, LLC. Repaired or replaced units under warranty shall be warranted for 90 days or the balance of the original warranty, whichever is greater.

  • Page 34: Fcc Notice

    Some states do not allow limitations on implied warranty duration, so the above limitation may not apply to you. In no event shall Earshot Innovations, LLC be responsible for any special, incidental, or consequential damages for breach of this or any other warranty, expressed or implied, whatsoever.
  • Page 36 Earshot Innovations, LL C P.O. Box 1336 Thousand Oaks, CA 91358-0336 Ph: (805) 480-9162 www.chameleonheadsets.com Fx: (805) 499-8778 e-mail: talk2us@chameleonheadsets.com C, 2000 p/n 1901-Rev.2 ' Earshot Innovations, LL...
