Double
Intelligence
Technology
http://www.navi-tuner.com
SIENNA
M u l t i m e d i a I n t e r f a c e
V1.1
Interface
Installation
Guide
for
SIENNA
Infotainment System
Contents
1. Multimedia Interface x1
2. Main cable x1
3. NAVI RGB cable x1
4. F/R-CCD cable x1
5. AV cable x3
6. Inner Board x1
7. SIENNA-LVDS cable x1
8. FPC28-S cable x1
9. FPC28-O cable x1
10. FPC30-O cable x2
11. IB-B cover x1
12. IB-T cover x1
13. IB screw(M3x5) x8
1. Multimedia Interface
2. Main cable
3. NAVI RGB cable
4. F/R-CCD cable
6. Inner Board
7. SIENNA-LVDS cable
8. FPC28-S cable
9. FPC28-O cable
10. FPC30-O cable
12. IB-T cover
P1
Cables' connection
Main
1
5. AV cable
11. IB-B cover
SIENNA
13. IB screw
Infotainment System
6
RGB
Input
Switch
Multimedia Interface
F/R
LVDS
DTV
DVR
DVD
CCD
7
2
3
4
5
Inner Board
IB Box
(IB-B cover &
IB-T cover)
FPC28-O/FPC28-S/
FPC30-O cables
Please study SIENNA V1,1
Unit Installation Guide
P2
Advertisement
Table of Contents
Summary of Contents for Double Intelligence Technology SIENNA Multimedia Interface
- Page 1 Contents Cables' connection 1. Multimedia Interface x1 Double 2. Main cable x1 Intelligence 3. NAVI RGB cable x1 4. F/R-CCD cable x1 Technology Input Switch 5. AV cable x3 http://www.navi-tuner.com 6. Inner Board x1 7. SIENNA-LVDS cable x1 Multimedia Interface 8.
- Page 2 Switch Setting Final test 1.Click the “ ”(Setting) icon to enter the code page. 2.Input " 8888 " of number code to enter the SETTING page. 1 2 3 4 5 6 Step 3: Select & enable the added devices Original page MAIN page NAVI сhannel...
