EUCHNER ESM-F Series System Manual

Modular safety system
Hide thumbs
Table of Contents

Advertisement

Quick Links

System Manual
GB
Modular Safety System
ESM-F
More than safety.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESM-F Series and is the answer not in the manual?

Questions and answers

Summary of Contents for EUCHNER ESM-F Series

  • Page 1 System Manual Modular Safety System ESM-F More than safety.

  • Page 2: Table Of Contents

    System Manual ESM-F Contents Correct use Exclusion of liability and warranty General safety instructions Function Status LEDs and pin assignment Status LEDs and connections on the base units Status LEDs and connections on the input modules Status LEDs and connections on the output modules Technical data General technical data Items supplied...

  • Page 3: Correct Use

    EN 6004-1. With this unit safety category 4 according to EN 954-1 can be achieved. The base unit can only be expanded using expansion devices in the modular safety system ESM-F from EUCHNER. The device is not allowed to be opened, tampered with, or modified. The permissible operating parameters are to be observed during operation (see section “Technical data”).

  • Page 4: Function

    The modules in the ESM-F system are used for the evaluation of the safety com- ponents connected and the safe interruption of a safety circuit. The base unit ESM-F-B... is part of the ESM-F system from EUCHNER. The ESM-F system comprises at least one base unit.

  • Page 5: Status Leds And Pin Assignment

    System Manual ESM-F Status LEDs and pin assignment All modules in the ESM-F system have status LEDs for the important module sta- tes. The significance of the individual LED states is given in the section Trouble shooting. Status LEDs and connections on the base units GO1 GI1 GO2 GI2 33 A1...

  • Page 6: Technical Data

    System Manual ESM-F Technical data General technical data Parameter Value Unit Housing material Polyamide PA6.6 Dimensions ESM-F-B.. ESM-F-I.. ESM-F-O.. 114 x 99 x 45 114 x 99 x .5 114 x 99 x .5 Weight Approx. 0.6 Approx. 0.13 Approx. 0.18 Connection type Plug-in connection terminals Terminals...
  • Page 7 System Manual ESM-F Dimension drawing Suitable for 35 mm DIN rail according to DIN EN 500-35 GO1 GI1 GO2 GI2 33 A1 SI SA OV Out 1 Out 2 Feedb Out B S23 S21 S22 S24 14 24 34 A2 Block diagram ESM-F-B...
  • Page 8 3 inputs, NC contact/NO contact, -channel with short-circuit monitoring and earth fault monitoring ESM-F-IMI-3C for the connection of safety switches with NO contact/NC contact combination (e.g. CMS from EUCHNER) 1) Supplied via expansion connector...
  • Page 9 System Manual ESM-F Dimension drawing Suitable for 35 mm DIN rail according to DIN EN 500-35 S13 S11 S13 S11 S33 S31 S32 S34 22,5 22,5 Block diagram ESM-ISI-2C2 S11 S12 S14 S21 S22 S23 S24 Input circuit 1 Input circuit 2 Inputs Group Monitoring...
  • Page 10 System Manual ESM-F Connection data, output modules ESM-F-O... Parameter Value Unit Operating voltage 4 ± 10% V DC Reverse polarity protection Power consumption Approx. .4 Current consumption, max. External contact fuses (safety circuit) 10 AgG (T6A / F8A) according to EN IEC 6069-1 Rated impulse withstand voltage Leakage path and air gap acc.
  • Page 11 System Manual ESM-F Dimension drawing ESM-F-O... Suitable for 35 mm DIN rail according to DIN EN 500-35 13 23 13 23 Y1 Y2 Y1 Y2 Out 1 Out 1 Out 2 Out 2 Feedb Feedb 22,5 22,5 Block diagram ESM-F-OSN-O4 Feedback loop Block diagram ESM-F-OSN-O3M1...
  • Page 12 System Manual ESM-F Connection data output modules ESM-F-OT.. Parameter Value Unit Operating voltage 4 ± 10% V DC Reverse polarity protection Power consumption Approx. .4 Time-delay ESM-F-OTN… 1 … 30 (adjustable) ESM-F-OT05N… 0.5 (fixed) Current consumption, max. without monitoring output with monitoring output Leakage path and air gap acc.
  • Page 13 System Manual ESM-F Dimension drawing ESM-F-OT... Suitable for 35 mm DIN rail according to DIN EN 500-35 Feedb Feedb 22,5 22,5 Black diagram ESM-F-OT... Feedback loop Monitoring output...

  • Page 14: Items Supplied

    Operating instructions (please retain!) Warning! Only use plug connectors from EUCHNER for connection and mounting. On the use of parts not approved by EUCHNER, the safety function may be lost or the device damaged. Accessories To connect the ESM-F modules you will need appropriate connection terminals that are not included with the modules.

  • Page 15: Mounting And Replacing Modules

    System Manual ESM-F Mounting and replacing modules Mounting The ESM-F system must be installed in a control cabinet that has a degree of pro- tection of at least IP 54. For fastening, the expansion connectors must be clipped to a horizontally mounted DIN rail. The technical data given only apply in this installation position.

  • Page 16: Replacing Modules

    System Manual ESM-F Replacing modules Any expansion modules can be removed from a safety group at any time. The remaining modules will continue to function without limitations. Warning! The safety function will be lost if safety modules are removed while the system is in operation.

  • Page 17: Electrical Connection

    System Manual ESM-F Electrical connection Warning! The device is only allowed to be installed and placed in operation by authorized personnel who are familiar with the correct mounting of safety components. Caution! Excessively high loads may cause damage to the base unit. Comply with the operating values in the section Technical data.

  • Page 18: Starting Behavior

    System Manual ESM-F Starting behavior The base unit can be placed in operation either using the autostart mode or by starting it manually. Connection for monitored, manual start For monitored, manual start, a start button must be connected between the termi- nals SO and SI.

  • Page 19: Connecting Safety Inputs

    (ESM-F-BSN...) or for the connection of one normally closed contact and one normally open contact (ESM-F-BMN...). The version ESM-F-BMN... is therefore suitable for the connection of diverse safety switches (e.g. CMS, from EUCHNER). All safety inputs have short circuit and earth fault monitoring. Important! Unused normally closed contact safety inputs must be fitted with jumpers (see Figure 6 and Figure 8).
  • Page 20 System Manual ESM-F Inputs on the base unit ESM-F-BSN... You can connect two dual-channel safety switches (e.g. two emergency stops) to the base unit. In the example below (Figure 6) only one safety switch has been connected, jumpers must therefore be fitted to the remaining safety inputs. Safety component Base...
  • Page 21 You can connect two safety switches with one normally closed contact and one normally open contact (e.g. CMS from EUCHNER) to the base unit. If an input is not used, a jumper only needs to be fitted to the pair of contacts to which the normally closed contact is connected (see Figure 8).

  • Page 22: Connecting Safety Contacts And Feedback Loop

    System Manual ESM-F Connecting safety contacts and feedback loop The base unit has three redundant, error monitored safety contacts that shut down immediately if one of the safety circuits connected is interrupted or a fault occurs. To check the switching state on a connected load, the auxiliary contacts on a con- tactor or relay can be connected to terminals Y1 and Y2 to form a feedback loop.

  • Page 23: Connecting Base Unit Monitoring Outputs 3

    System Manual ESM-F Connecting base unit monitoring outputs The base unit has six short circuit-proof semiconductor outputs that can be used to signal different operating states, e.g., to a PLC. If the monitoring output is active, a voltage of DC 4 V is present at the related terminal (referred to the potential at terminal 0 V).

  • Page 24: Connecting Expansion Modules

    ESM-F-I3I..The version ESM-F-IMI… is suitable for the connection of safety switches with normally closed/normally open contacts, e.g. CMS safety switches from EUCHNER. All safety inputs have short circuit and earth fault monitoring (not ESM-F-ILI...). The input modules detect the switch state of each safety component connected or a fault and signal this information to the base unit.
  • Page 25 System Manual ESM-F Each input module also has short circuit-proof semiconductor monitoring outputs that can be used to signal the states of the safety inputs to a PLC. If the monitoring output is active, a voltage of DC 4 V is present at the related terminal (referred to the potential at terminal 0 V on the base unit).

  • Page 26: Connecting Output Modules 6

    System Manual ESM-F Connecting output modules Important! Output modules must always be connected to the right of the base unit. If a feedback loop is not connected, a jumper must be fitted to the terminals Y1 and Y2. Caution! In the event of a fault (e. g. short circuit) in the load circuit, excessively high currents may flow through the safety contacts.

  • Page 27: Expanding Time-Delay Output Modules 7

    System Manual ESM-F Output modules with fixed and adjustable time-delay On output modules with time-delay, the safety contacts are not opened immediately after the stop signal from the base unit, but only after a time-delay has elapsed. In this way parts of the system can continue to be supplied with power after an emergency stop request, e.g.

  • Page 28: Forming Safety Groups

    System Manual ESM-F Forming safety groups Important! If you do not want to form safety groups, please read the section "Connecting group outputs" on page 3. Safety groups can be formed using the ESM-F system. In this way it is possible to shutdown only that part of the system in which maintenance or setup work is to be performed.

  • Page 29: Forming A Group With The Outputs Go1 And Go2 On A Base Unit 9

    System Manual ESM-F Forming a group with the outputs GO1 and GO2 on a base unit It is also possible, e.g., to connect daisy-chained emergency stops to a base unit and for only this chain to act on other base units. The following example shows such an application.

  • Page 30: Setup

    System Manual ESM-F Setup Warning! The device is only allowed to be placed in operation by authorized personnel who are familiar with the correct setup of safety components. Proceed as follows: Ensure nobody can be placed in danger during setup. Prior to setup check whether all connections are correct (jumpers connected, external circuit correct) and the outer extension connectors are fitted with terminal plugs.

  • Page 31: Trouble Shooting

    System Manual ESM-F Trouble shooting Status table Status LEDs on the base units GO1 GI1 GO2 GI2 33 A1 Significance SI SA OV Illuminates if operating voltage is present. In 1-1 Illuminates if the safety circuit on safety input 1, channel 1 is in the safe state. In 1-2 Illuminates if the safety circuit on safety input 1, channel  is in the safe state.
  • Page 32 Rx and/or Internal device fault Contact EUCHNER customer service. TX off Device does not have expanded diagnostics (not a fault).
  • Page 33 In - flash with of flashes interrupted by a fixed pause). regular signal Possible cause: If it was not possible to rectify the fault with a sequences Fault because off severe EMC interference restart, contact EUCHNER customer service. Unit is faulty...

  • Page 34: Inspection And Service

    No servicing is required. Repairs to the device are only allowed to be made by the manufacturer. Service In case of a need for service, contact: EUCHNER GmbH + Co. KG Kohlhammerstraße 16 D-70771 Leinfelden-Echterdingen Service telephone: +49 (0) 7 11 / 75 97 - 301 E-mail: info@euchner.de...

  • Page 35: Declaration Of Conformity

    The use of these products in a machine or system does not guarantee the entire machine or system complies with the European directives. Leinfelden, November 005 Dipl.-Ing. Stefan Euchner Director...
  • Page 36 Euchner GmbH + Co. KG Kohlhammerstraße 16 D-70771 Leinfelden-Echterdingen info@euchner.de www.euchner.de Issue: 09719-04-0/07 Title: System Manual Modular Safety System ESM-F Copyright: © EUCHNER GmbH + Co. KG, 0/007 Subject to technical modifications, all data supplied without liability. More than safety.
