SecuSafe VTO2202F Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VTO2202F
(Version 1.0)
Quick Start Guide
V1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VTO2202F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SecuSafe VTO2202F

  • Page 1 VTO2202F (Version 1.0) Quick Start Guide V1.0.0...

  • Page 2: Cybersecurity Recommendations

    Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity 1. Change Passwords and Use Strong Passwords: The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible.
  • Page 3 ● Only forward the HTTP and TCP ports that you need to use. Do not forward a huge range of numbers to the device. Do not DMZ the device's IP address. ● You do not need to forward any ports for individual cameras if they are all connected to a recorder on site;...

  • Page 4: Regulatory Information

    Regulatory Information The regulatory information herein might vary according to the model you purchased. Some information is only applicable for the country or region where the product is sold. FCC Information Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

  • Page 5: Foreword

    Foreword General This Guide introduces the structure, mounting process, and basic configuration of the device. Safety Instructions The following categorized signal words with defined meaning might appear in the Guide. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury.
  • Page 6  All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the Guide. Please contact the customer service for the latest program and supplementary documentation. ...

  • Page 7: Important Safeguards And Warnings

    Important Safeguards and Warnings The following description is the correct application method of the device. Please read the manual carefully before use, in order to prevent danger and property loss. Strictly conform to the manual during application and keep it properly after reading. Operating Requirement Please don’t place and install the device in an area exposed to direct sunlight or near heat ...

  • Page 8: Table Of Contents

    Table of Contents Cybersecurity Recommendations ......................I Regulatory Information ........................... III Foreword ..............................IV Important Safeguards and Warnings ....................VI 1 Network Diagram ........................... 1 2 Appearance ............................2 Front Panel ............................ 2 Rear Panel ............................ 3 3 Installation .............................. 4 Installation Requirement .......................

  • Page 9: Network Diagram

    Network Diagram Network Diagram 1...

  • Page 10: Appearance

    Appearance Front Panel Figure 2-1 Front panel Table 2-1 Front panel description Name Description Inputs audio. Camera Monitors door area. Indicator When you are calling, this indicator will be on. During the call communication, this indicator Indicator will be on. When the door is unlocked, this indicator will Indicator be on.

  • Page 11: Rear Panel

    Rear Panel Figure 2-2 Rear panel Table 2-2 Rear panel description Name Description Tamper The VTO would make alarm sound if it is being removed from the wall switch by force, and the alarm will also be sent to the management center. GND: Ground.

  • Page 12: Installation

    Installation Installation Requirement 3.1.1 Notice Do not install the VTO to places with condensation, high temperature, grease or dust,  chemical corrosion, direct sunlight, or zero shelter.  The installation and adjustment must be finished by professional crew, and do not disassemble the VTO.

  • Page 13: Installed In The Wall

    Step 4 Install the mounting box on the wall by screw the four ST4×25 self-tapping screws into the expansion screws. Step 5 Put the VTO into the mounting box. Step 6 Fix the VTO to the mounting box by screwing two M3×8 screws from the bottom of the mounting box.
  • Page 14 Step 5 Put waterproof rings to the M3×8 screws. Step 6 Screw four M3×8 screws (with waterproof ring) into the mounting box front cover. Figure 3-3 Installed in the Wall Table 3-2 Names of numbers (2) Name M3×8 Screw Waterproof ring Mounting box front box Mounting box rear box Wall...

  • Page 15: Configuration

    Configuration This chapter introduces how to initialize, connect, and make primary configurations to the VTO and VTH devices to realize basic functions, including device management, calling, and monitoring. For more detailed configuration, see the user's Manual. Configuration Process Before configuration, check every device and make sure there is no short circuit or open circuit in the circuits.

  • Page 16: Configuring Vto Number

    Figure 4-1 Device initialization Step 3 Enter and confirm the password, and then click Next. The Email setting interface is displayed. Step 4 Select the Email check box, and then enter your Email address. This Email address can be used to reset the password, and it is recommended to finish this setting. Step 5 Click Next.

  • Page 17: Configuring Network Parameters

    Figure 4-3 Main interface Step 2 Select Local Setting > Basic. The device properties are displayed. See Figure 4-4. Figure 4-4 Device properties Step 3 In the VTO No. input box, enter the VTO number you planned for this VTO, and then click Confirm to save.

  • Page 18: Configuring Sip Server

    The VTO will reboot, and you need to modify the IP address of your PC to the same network segment as the VTO to log in again. 4.3.4 Configuring SIP Server The SIP server is required in the network to transmit intercom protocol, and then all the VTO and VTH devices connected to the same SIP server can make video call between each other.

  • Page 19: Configuring Call No. And Group Call

     If other servers work as SIP server Select the server type you need in the Server Type list, and then see the corresponding manual for the detailed configuration. 4.3.5 Configuring Call No. and Group Call You need to configure call No. on every VTO, and then all the VTO will call the defined room when you press the call button.
  • Page 20 which a VTO device works as SIP server, and if you are using other servers as SIP server, see the corresponding manual for the detailed configuration. Step 1 Log in the web interface of the SIP server, and then select Household Setting > VTO No.

  • Page 21: Adding Room Number

    Parameter Description Build No. Available only when other servers work as SIP server. Unit No. IP Address The IP address of the target VTO. Username The user name and password for the web interface of the target VTO. Password Step 4 Click Save.

  • Page 22: Verifying Configuration

    Figure 4-12 Add single room number Step 3 Configure room information. See Table 4-3. Table 4-3 Room information Parameter Description First Name Last Name Enter the information you need to differentiate each room. Nick Name The room number you planned. ...

  • Page 23: Doing Monitor From Vth

    Figure 4-13 Call screen on the VTH to answer the call. 4.4.2 Doing Monitor from VTH Step 1 In the main interface of the VTH, select Monitor > Door. The Door interface is displayed. See Figure 4-14. Figure 4-14 Door Step 2 Select the VTO you need to do monitor.
  • Page 24 Figure 4-15 Monitor screen Configuration 16...

  • Page 25: Connecting Mobile Phone App

    Connecting Mobile Phone App You can download the mobile phone app, and then add your villa VTO to the app. When someone is calling you from the villa VTO, there will be push message on your phone, and you can talk to the visitor or unlock the door remotely on your phone. Step 1 Scan the following QR code to download and install the app.
  • Page 26 Figure 5-3 Step 4 Give a name to your target VTO, and then tap the sign. The mobile phone starts to scan. Step 5 Log in the web interface of the VTO you need to add, and then select Network. The P2P interface is displayed.
  • Page 27 Figure 5-5 Live Step 7 Tap Alarm Manager > Subscribe, and then subscribe the VTO you need. See Figure 5-6. Figure 5-6 Subscribe When someone is calling you from the subscribed villa VTO, there will be push message on your phone. See Figure 5-7. Connecting Mobile Phone App 19...
  • Page 28 Figure 5-7 Push Connecting Mobile Phone App 20...
