- Page 1 ° : MUV1600178 SmartCrystal™ Cinema Version : A01 Neo Dual USER MANUAL Date : 10/05/2019 User Guide MODEL: VBSP-12000 This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission...
-
Page 2: Table Of Contents
VIII. IMPORTANT SAFETY RECOMMENDATIONS ................16 IX. WARRANTY ..........................17 FURTHER INFORMATION ......................17 XI. REGULATORY STANDARDS ....................... 17 XII. VOLFONI CONTACTS........................18 This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 3: Product Overview
The system is easy to set up with a DCI-compliant DLP projector and works with projector lamps up to 7KW. Please consult Volfoni for additional information. This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 4: Smartcrystal Cinema Neo Dual Features
To rectify any indicated faults, please contact your dealer, installer stating the model number shown in the silver label of the product. This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 5: Theoretical Brightness Performance Scc Neo Dual
«RIGHT EYE» is in front of your right projector and the polarizer marked with a «LEFT EYE» is in front of your left projector. This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 6: Bracket Description
This wall fixing part is provided with all the screws and wall anchors you might need This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 7: Optical & Mechanical Requirements
«RIGHT EYE» is in front of your right projector and the polarizer marked with a «LEFT EYE» is in front of your left projector. This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... - Page 8 ° : MUV1600178 SmartCrystal™ Cinema Version : A01 Neo Dual USER MANUAL Date : 10/05/2019 A. Phase one B. Phase two This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission...
-
Page 9: Projectors Settings
As Auto-Mode option is disabled and there are no 3D signal coming from projectors, BNC connectors are not used with Dual systems This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 10: Using The Smart Crystal Cinema Neo Dual
4- USB (Software update) 5- LEDs (Visual Control) 6- Remote control 7- BNC (Synchronization): Not Applicable for Dual Systems 8- 12V (Power supply) This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 11: On / Off Switch
NOC mode: information and operations are automatically sent from the server via the central network: Follow the procedure: http://volfoni.com/en/smartcrystal- dual-a/: Remote Connection Guide This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 12: Software Update - Usb Port
This button is not illuminated when the polarization window is in 2D mode 7. Remote control : Please contact us for more details 8. BNC connector : Not applicable for Dual systems This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 13: Maintenance
LCD from dust for example a. Unscrew 2 following screws b. Fix the handle to the LCD frame with the two screws you have just removed This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 14: Software Update
Once the device is connected, press CHECK FOR UPDATE Load the latest version if it’s not already on your SmartCrystal™ Cinema Neo Dual This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 15: Troubleshooting
7- Silver screen must be used 8- We recommend to use Volfoni passive glasses (circular polarization) 9- Remove projection porthole in case of it depolarizes the light This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 16: Important Safety Recommendations
Do not touch the polarization window. Avoid vibrations and shock. Use a clean soft cloth when cleaning the polarization modulator to avoid scratching. This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 17: Warranty
This Class B digital apparatus complies with Canadian ICES-003. This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission... -
Page 18: Volfoni Contacts
Distributed in US by Volfoni INC Commercial & Support 3450, Cahuenga Bd West contact@volfoni.com Unit 504 support@volfoni.com Los Angeles, CA www.volfoni.com 90068 - USA This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission...
