AT-500 Audio Guide

Troubleshooting

No display
Check if battery is properly installed and powered.
T urn on the player as instructed above.
If the problem still exists, return the player to your supplier.
No sound
Adjust the player volume to the proper level.
I f you are using an earphone, make sure it is properly connected.
C heck if the audio content is correctly uploaded.
If the problem still exists, return the player to your supplier.
SD error
An error happens to the SD card. Press the reset button
If the problem still exists, return the player to your supplier.
File error
An error happens to uploaded files in the SD card. Return the player to the counter for
content re-uploading.
If the problem still exists, return the player to your supplier.
Anti-theft system alarmed
Alarm will also be active when this screen shows up. Return the player to the counter
for alarm release.
To mute the player temporarily, press both
Alarm screen will remain on the screen.
Alarm can be released via Loop Controller LT-200+ or chargers/updaters.

Specifications

Audio parameters
Audio format High quality audio compression
Bandwidth 20 Hz - 15 kHz
Dynamic range
90 dB
< 0.1%
Distortion
Built-in 0.5 W @ 8 Ω
Speaker
Earphone output 3.5 mm Jack x 2 (stereo)
4
9
and then reboot the player.
and button simultaneously.
General paramters
Display 2.8 inch TFT-LCD (240 x 320 pixel)
Memory capacity 8 GB, support up to 32 GB
Automatic triggering IR
Anti-theft system
Alarm
Nubmer of languges Max. 32
Max. 9999 x 32
Number of messages
-10 °C ~ +50 °C
Operating temperature
Battery
3.7 V, 1700 mAh Li-Polymer battery
battery life 12 hours
Dimensions (DxWxH) 23.2 x 61.5 x 135 (mm)
Weight
175 g (with battery)
AT-500 Audio Guide
Illustration
AT-500
1
2
3
4
5
1
6
7
1 Charging/battery indicator
Steady red/green indicator stands for charging/fully charged status.
Flashing red indicator stands for potentially defective battery inside.
2 Triggering area
Inbuilt infrared trigger is available for commentary (auto) playback.
3 Hi-Fi stereo and hearing-aid-compatible (HAC) speaker
4 2.8" TFT touch screen
5 Backlit keypad
Fast backward
Volume down
6 Uploading/Charging port
This port is connected with compatible updater for content updating.
Charging is applicable only when the player is connected with PC via an USB cable.
Follow steps below.
1. Connect the player with your PC via an USB cable.
2. USB shows up on the screen.
3. Press the button and red indicator
4. The player is being charged now. When the player is fully charged, green indicator
illuminates.
7 Earphone jacks
8 Wireless charging module
Players are being wirelessly charged when they are inserted into compatible chargers.
9 Reset button
The player will be forced to be shut down when this button is pressed.
Lanyard hole
10
10/17
8
9
10
Play/Pause Fast forward
Power On/Power off/Stop Volume up
1 illuminates.
