Please read the operation and fitting instructions carefully before starting the installation.
MightyLock is suitable for doors from 17mm to 39mm thick.
A 1 x MightyLock
B
1 x Tubular Latch
C 1 x Strike Plate
D 1 x Frame Insert
E
1 x Handle Power Pack
F
4 x Screws
G 2 x 27mm Screws
H 2 x 37mm Screws
*
#
I
1 x E-Key
J
1 x Door Template
Important:
The default master code is *000000#. MightyLock requires 4 x AAA batteries to operate,
if the batteries fail, you can either use the E-Key to power the lock and gain access or use an alternative
power source via an A-B USB cable, the power output must not exceed 9v.
Do not turn the square door spindle more than 90 degrees before installing MightyLock on the door.
1
A
Ekey
Important!
First install 4 x AAA batteries into the Handle Power Pack (E)
and check the handle operates using the default master code:
*000000#
"Make It Once...Make It Mighton..."
MightyLock
Installation Instructions
A
*
#
Ekey
Set
E
Ekey
Set
E
Set
Parts List
F
G
H
Ekey
Set
Installation
2
G
Mark the height and centre of the door edge
at the height you want your door handle installed.
*
#
B
C
I
Ekey
Set
www.mightonproducts.com
D
J
MightyLock Door Template
UP
DOOR EDGE
CENTRE
ALIGNMENT
ø 39.5mm
ø 60.0mm
ø 80.5mm
DOOR EDGE
www.mightonproducts.com
Advertisement
Summary of Contents for Mighton MightyLock
- Page 1 E-Key to power the lock and gain access or use an alternative power source via an A-B USB cable, the power output must not exceed 9v. Ekey Do not turn the square door spindle more than 90 degrees before installing MightyLock on the door. Installation Ekey...
- Page 2 Ensure the handle keypad is on the correct side. Door frame Power Pack plug Plug the MightyLock (A) cable into the Handle Power Pack (E). In the appropriate position on the door frame, install the Strike Plate (C) and Frame Insert (D) using the Close the handle cover using screws (G) provided.
-
Page 3: Operation
*#000000#3#132435# Important: If the batteries in MightyLock fail, you can either use the E-Key to power the lock and gain access or use an alternative power source via an A-B USB cable, the power output must not exceed 9v. 4 x new AAA batteries should then be installed. - Page 4 The E-Key (I) can be used as an external emergency power supply for MightyLock (A). It can also be paired with MightyLock (A) which will allow the E-Key to unlock the door simply by pressing the Open Button on the E-Key. You can pair up to 5 E-Key’s with each MightyLock.
- Page 5 MightyLock Door Template DOOR EDGE CENTRE ALIGNMENT ø 39.5mm ø 60.0mm ø 80.5mm DOOR EDGE www.mightonproducts.com...
