Summary of Contents for Converters.TV 4K UHD LPCM 7.1
- Page 1 UHD 4K 6G Audio Extractor - ID# 15477 Operation Manual...
- Page 2 Introduction This 4K UHD LPCM 7.1 Channel Audio Extractor can extract up to 8 channels of LPCM audio from an HDMI source, allowing the user to convert high quality lossless HDMI audio into multi-channel analog signals for use with powered speakers or non-HDMI AV receivers.
- Page 3 System Requirements • HDMI source equipment such as media players, video game consoles or set-top boxes. • HDMI receiving equipment such as HDTVs, monitors or audio amplifiers. • Analog audio receiving equipment such as audio amplifiers or powered speakers. • he use of “Premium High Speed HDMI”...
- Page 4 Rear Panel 1. HDMI IN: Connect to HDMI source equipment such as a media player, game console or set-top box. HDMI OUT: Connect to HDMI TVs, monitors or amplifiers for digital video and audio output. (LPCM up to 7.1, bitstream, HD bitstream) OPTICAL OUT: Connect to powered speakers or an amplifier for digital audio output using an appropriate optical cable.
- Page 5 Default: ON FADEFAULT SET UNIT TO NONE FACTORY DEFAULT SHOW UNIT NONE FIRMWARE VERSION REBOOT SYSTEM REBOOT NONE SHOW DESCRIPT OF NONE COMMAND SHOW DESCRIPT OF HELP NONE COMMAND Note: Commands will not be executed unless followed by a carriage return. Commands are not case-sensitive.
- Page 6 detected units will be displayed in the list. Clicking on a detected unit will open the EDID Commander window. EDID Controller Tab Mode Select: The currently selected EDID is displayed here. The “User 1” EDID corresponds to the “Bitstream” setting on the front of the unit. The “User 2”...
- Page 7 EDID Creator Tab Click on the EDID Creator tab to begin designing a new EDID from scratch (select the “New” icon), to modify an existing EDID stored on the PC as a .bin file (select the “Load” icon) or to edit an EDID copied from the unit via the EDID Analyzer’s edit option.
- Page 8 formats and bit depths are supported, including BT.2020 and HDR support options. • Others: This tab contains options for supporting 3D and defining the CEC Address. Once the user is finished editing or creating an EDID it can be saved to a *.bin file locally or uploaded directly to the unit using the “Save”...
- Page 9 Connection Diagram...
- Page 10 Specifications Video Bandwidth 600MHz/18Gbps Input Ports 1 x HDMI, 1 x Mini-USB (service & control only) Output Port 1 x HDMI, 1 x Optical S/PDIF (Digital Audio) HDMI Audio Sampling Up to 192 kHz Rate Optical Audio Sampling Up to 192 kHz Rate HDMI Cable I/O 10 meters, 1080p@12-bit...
