Squire SS50 COMBI Recoding Instructions

Lock Diagram

Re-code Tool

Instructions

1.
The lock is pre-set at 00000. Set the
wheels to this code then pull the body
sleeve to open it. The code can only be
changed when the lock is open.
2. To set your own code, first write down
your new code in the box provided below.
Choose a code which is easy to remember
but is not easily guessed.
Insert the re-code tool into the wheel you
3.
wish to change.
Using the re-code tool as a lever, rotate
4.
the wheel to the required number, then
go past the code indicator until the lever
stops on the lock body, now turn the
IMPORTANT - Lubricate frequently with WD40 or a light oil
Hilton Cross Business Park, Cannock Road, Featherstone, Wolverhampton, WV10 7QZ
E-Mail: info@henry-squire.co.uk
Recoding Instructions

How to recode the SS50 COMBI

Record your code & store in a safe place
Henry Squire & Sons Limited
Tel: 01902 308050
Registered in England No. 88907

Code Indicator

Body Sleeve
wheel back until the required number lines
up with the code indicator, you will feel it
click into place. You may rotate the wheel in
either direction. Ensure that the number
lines up with the code indicator.
5.
Repeat instructions 3-4 for the additional
wheels you wish to change.
Close shackle and test the code by pushing
6.
and pulling the body sleeve to close and
open the padlock
Your lock is now ready to use.
7.
Remember to scramble the wheels when
8.
closing the lock.
Fax: 01902 308051
Website: www.squirelocks.co.uk
