wodtke
Stove Technology
Quick Operating Instructions for
Control System S5
for Software BM 010 and Higher
CAUTION:
Please also read the general operating and assembly instructions.
This is a short version of the operating instructions which explains only the most important
commands and display messages. It is neither complete nor sufficient in itself!
We hope your pellet stove gives you many hours of warm, snug comfort in your home.
wodtke GmbH
Standby dot
or
feed screw
working time
interval
(dot flashes)
ON/OFF-key
Overrides all other
controls including
external
controllers.
© Wodtke GmbH Tübingen. All rights reserved. Subject to change without notice.
Pellet
®
and
H
13.0
®
Display:
operating state + values
PLUS + MINUS keys:
adjust output +
move forward / back in menu
MENU key:
Change between operating
level and menu level
(for making data queries)
Month of issue 03/2011
Page 1 / 4
Art. No. 950 325
