A5 HC38 instructions US
18/06/07
Location Criteria
The unit should always be
located in accordance with the
diagram information shown to
the right. If the system is
different then the unit should
be fitted onto the cold water
pipe to where the water is being
heated, preferably without any
'T' off's after the unit.
The Hydropath Guarantee
Should any fault occur during
the first three years of operation
it will be replaced or repaired
free of charge.
Do not attempt to carry out any
unauthorised repair as this will
invalidate the guarantee.
Retain the proof of purchase
and contact the supplier or place
where the unit was purchased.
This guarantee does not affect
the consumers statutory rights
and does not include the cost of
carriage.
Hydropath does not accept any
responsibility for water leaks
that may occur by the removal
of lime scale or for any losses
arising from the use of its water
conditioners.
16:13
Page 1
COMBI SYSTEM & WATER HEATERS
COLD WATER IN
HOT WATER OUT
HydroCare
HEATING CIRCUIT
DIRECT FIRED WATER HEATER
HOT WATER
OUT
COLD WATER IN
HydroCare
INSTALLATION INSTRUCTIONS
Advertisement
Table of Contents
Summary of Contents for HydroCare HC44
-
Page 1: Installation Instructions
COLD WATER IN HOT WATER OUT Hydropath does not accept any responsibility for water leaks HydroCare that may occur by the removal HEATING CIRCUIT of lime scale or for any losses arising from the use of its water conditioners. - Page 2 A5 HC38 instructions US 18/06/07 16:14 Page 2 INSTALLATION INSTRUCTIONS Stage 1 Stage 2 Stage 3 Screw the mounting bracket to the Push the top section firmly onto the Clip on the lower section and withdraw pipe work with a screwdriver. bracket.
