AppliCATiOns: For wood or metal furniture in home office
furniture and office workstation desktops. This product is
covered by U.s. (D447,145 s) and foreign (ROC 74826)
patents issued and/or pending.
Inches
mm
Finish:
Black powder-coated (CB) finish
Unit profile:
Width: 29.6" [751.7]
Depth: 19-1/2" [495.3]
slide Travel:
11.0" [279.4]
Tray profile:
Inside tray width: 25-1/2" [647.7]
Inside tray depth: 9-13/32" [239.0]
Mounting
space:
Minimum 30.0" [762.0]
load:
Slides are rated to carry 75 lbs.
Brackets:
Variable height,
Inboard/Outboard.
Tray Fit:
Fixed at -7°
9-13/32"
[239.0]
End Cap
Palm Rest
Features
• Ergonomic design
• Slides fully concealed from view
• All rough edges and pinch points eliminated
• No transfer of grease
• Accommodates any size keyboard by removing palm rest
• Large tray width provides unhanded mouse surface
• Removable full-length foam palm rest
• Cable management fixtures incorporated in rear of tray
• Slides silenced in the open and closed positions
• Detent-in and detent-out
CBERGO-TRAY 200
Standard Keyboard Tray System
3/4 Extension Ball Bearing Slides
30-3/8" [771.5] Bracket Outboard
24-3/4" [628.7] Bracket
Reversible Adjustable
Brackets
Keyboard Tray
25-1/2"
[647.7]
End Cap
Mouse Pad
