- Page 1 Parker IoT Antenna for PVSG–IQAN Gateway U s e r G u i d e Parker Hannifin Canada...
- Page 2 Offer of Sale The items described in this document are hereby offered for sale by Parker Hannifin Corporation, its subsidiaries or its authorized distributors. This offer and its acceptance are governed by the provisions stated in the "Offer of...
-
Page 3: Table Of Contents
Contents Publication History ......................iv Safety ........................... v Safety symbols ..........................v General safety regulations ....................... v Welding after installation ........................vi Construction regulations ........................vi Safety during installation ........................vi Safety during start-up ........................vii Safety during maintenance and fault diagnosis ................vii 1. -
Page 4: Publication History
Publication History The following table provides an overview of the changes made to this document over the course of its publication history. Release Date Description of Change Rev. 001 First release of this document User Guide... -
Page 5: Safety
Contact the manufacturer if there is anything you are not sure about or if you have any questions regarding the product and its handling or maintenance. The term "manufacturer" refers to Parker Hannifin Corporation. Safety symbols The following symbols are used in this document to indicate potentially... -
Page 6: Welding After Installation
Safety Do not use the product if electronic modules, cabling, or connectors are damaged or if the control system shows error functions. Electronic control systems in an inappropriate installation and in combination with strong electromagnetic interference fields can, in extreme cases, cause an unintentional change of speed of the output function. -
Page 7: Safety During Start-Up
Safety Safety during start-up Danger! Risk of death or injury. Do not start the machine's engine before the control system is mounted and its electrical functions have been verified. Do not start the machine if anyone is near the machine. Safety during maintenance and fault diagnosis Before performing any work on the hydraulics control electronics, ensure that... -
Page 8: About The Iot Antenna
About the IoT antenna 1. About the IoT antenna The IoT antenna is a heavy-duty, fully IP67 waterproof external antenna designed for use in telematics, transportation and remote monitoring applications. The antenna is unique because it combines a 3 in 1 GPS/GLONASS/GALILEO, Cellular (2G and 3G) and Wi-Fi, heavy-duty antenna with high efficiency in a compact format. -
Page 9: Mechanical Specifications
Non-condensing 65°C 95% RH 1.3. Ordering Part Numbers The IoT antenna comes in 2 variations. The antenna is specially designed to pair with the IQAN-PVSG Gateway. It is recommended that the Parker antenna is used for optimum performance. Part Number... -
Page 10: Mounting The Antenna To Equipment
Mounting the Antenna to Equipment 2. Mounting the Antenna to Equipment It is up to the original equipment manufacturer (OEM) or integrator to ensure the product is securely mounted to the vehicle. 2.1. Mounting Guidelines The following guidelines are related to physically attaching the IoT antenna to a vehicle: ... -
Page 11: Mounting Dimensions
Mounting the Antenna to Equipment 2.2. Mounting Dimensions User Guide... -
Page 12: Overall Antenna Dimensions
Mounting the Antenna to Equipment 2.3. Overall Antenna Dimensions 2.3.1. 10ft Antenna The IoT antenna dimensions are shown in milimeters. -
Page 13: Ft Antenna
Mounting the Antenna to Equipment 2.3.2. 20 ft antenna User Guide... -
Page 14: Antenna Connections
RF Specifications 2.4. Antenna Connections The antenna utilizes coaxial leads with included SMA adapters see table below for details. Antenna Connections Type Function RP-SMA Wi-Fi 3. RF Specifications 3.1. GPS Specifications GPS/GLONASS/GALIELO Centre Frequency 1575.42MHz / 1602MHz Bandwidth 10MHz Radiation Efficiency 50(without cable) 4.0 typ(with ψ=140mm ground) Passive Gain @ Zenith... -
Page 15: Cellular Specifications
RF Specifications 3.2. Cellular Specifications Cellular Frequency (GHz) 824~896 880~960 1710~1880 1850~1990 1710~2170 PeakGain (dBi) -0.2 Average (dBi) -4.7 -7.5 -2.7 -3.1 -3.1 Efficiency 50Ω Impedance Polarization Linear Radiation Pattern Omni Cable 10 ft, 20ft: CFD200 Connector SMA(M): 10ft straight, 20ft right angle 3.3. -
Page 16: Certifications
Certifications 4. Certifications 4.1. EU Declaration of conformity Conformity is declared under the following standard: EN55022 Class B Error! No text of specified style in document. - Page 18 HY33-5027-IB/US...
