- Page 1 User manual C-Node 7 C-Node7 Outdoor luminaire controller...
- Page 2 In the set C-Node 7 NOTE: Before installing, check the conformity of device configuration. NOTE: Before installing, check the conformity of device configuration. Necessary Flat-headed screwdriver Cross-headed screwdriver C-Node 7 User manual...
- Page 3 Ensure that the AC power mains are turned OFF before removing the cover, handling the wiring, or or any other work is carried out on C-Node 7. DO NOT apply power to the device until you have checked all wiring connections and you are instructed to apply power.
- Page 4 Placing into the luminaire Place the C-Node 7 into the luminaire and fasten it. C-Node 7 User manual...
- Page 5 Wiring Connect the incoming 230 VAC power supply to the C-Node 7 in accordance with the symbols Li and Ni. Connect the power supply 230 VAC of LED driver to the C-Node 7 in accordance with the symbols Lc and No.
- Page 6 C-Node 7 inputs + and -. NOTE: Polarity does not have to be observed. Connect the 0-10V control wires of the LED driver to the C-Node 7 inputs + and -. NOTE: Mind the polarity. Connect the PWM control wires of the LED driver to the C-Node 7 inputs + and -.
- Page 7 Indication diodes Establishing the connection with the segment controller. Active connection with the segment controller. C-Node 7 User manual...
- Page 8 Teliko Ltd Zemitana str. 2b, Riga, LV-1012, Latvia Phone: +371 67620626, Fax: +371 67620653 E-mail: info@teliko.com www.teliko.com...
