User's Manual

The Wireless Headset is using standard Bluetooth technology. It is compatible with any Bluetooth

enabled audio gateway devices. Its unique state-of-the-art design and user-friendly interface can

bring you the most convenient way of life.

Front

1. Power Key/Talking Button

2. Volume up Key

3. Volume down Key

4. Status Indicator

Standby：Green light flashing once in 4 seconds

Pairing: Green & Red light alternately flashes once / second

Talking：Green light flashing 3 times / second

Low Battery Standby：Red light flashing once in 4 seconds

Low Battery talking：Red light flashing 3 times / second

Charging：Red light on

Charging complete：Red light off

5. Earpiece receiver

6. Earpiece microphone

7. Earpiece audio jack

Side

8. Re-set Key

Headset's safety installation, which can enable

the headset to be back to the original status

9. Headset clip

H B M -004

Table of Contents

Need help?

Do you have a question about the HBM-004 and is the answer not in the manual?

Questions and answers

Summary of Contents for Human Interface Technologies HBM-004

Page 1 H B M -004 User’s Manual The Wireless Headset is using standard Bluetooth technology. It is compatible with any Bluetooth enabled audio gateway devices. Its unique state-of-the-art design and user-friendly interface can bring you the most convenient way of life. Front 1.
Page 2 Charge When first use this Bluetooth headset, the build-in battery is not fully charged. It is highly recommended to fully charge the battery before first use. When charging the battery, please see the below diagram followed by the instruction. First, please plug in the transformer (13) into an AC wall plug, then connect the transformer output connector (12) with headset charger jack (11), the status indicator (4) will turn on and it will be red by now, meaning that the headset is being charged at the moment.
Page 3 HBM-004”, press Select Enter passcode: press 0000, then press OK When the screen shows “connected to HBM-004” & the headset status indicator changes to green light flashing once in 4 seconds from the green & red light flashing alternately once/ second, meaning that the pairing process succeeds.
Page 4 Sony Ericsson T68 Scroll to Menu, Connect – Bluetooth – Discover When the screen shows HBM-004 press YES Add to paired，press YES A headset is already paired with the phone. Replaced? Press YES Passkey：Press 0000，and then press YES Pairing succeeded，Name tag Press NO Add device，Press NO...
Page 5 & mobile phone. Otherwise mobile phone will disconnect headset (mobile phone screen will show “Disconnected to: HBM-004”), you must need to connect headset & mobile phone again. Sony Ericsson T68 When headset is on standby mode, directly dial numbers from the mobile phone, the call will transfer automatically from the phone to headset.
