Summary of Contents for Avidow AD-M808-10804G
- Page 1 4G SOLAR POWER BULLET WIFI CAMERA Quick Guide * Before using the product, please read the Quick Guide carefully and keep it well. * This instruction manual is for reference only.
- Page 3 4G Contents English 01-15 16-29 中文...
-
Page 4: Packing List
Packing List After opening the package, please check the low-power wireless battery camera (the “Equipment”) to verify whether the following parts are complete. Screw Package (including Screw) Equipment Bracket Quick Start Guide Appearance Reset Button TF Card Slot USB Interface SIM (4G) Card Slot Power Button Battery Compartment... - Page 5 Solar panel IR LED Indicator Lights Lens Light Sensor Fixed Hole Stent Screw TF Card Slot The user can insert 8G, 16G, 32G SD card (Please use branded card with C10 and above) to store video image files Users can insert 4G SIM card or 4G flow card SIM (4G) Card Slot Speaker...
- Page 6 USB Interface The battery of the equipment is charged through the USB interface, When connected USB the equipment will be automatically turned on Power Button Press and hold for 3 seconds to shut off, you can hear the horn sound; In sleep mode, press briefly for 1 second to wake up the device;...
-
Page 7: Installation Guide
Light Sensor Used to collect ambient light. When luminance is lower than 2 Lux, turn on the IR LED Fixed Hole Use the mounting screws included in the accessory kit to fix the rear stand Stent Screw For vertical stand (optional) Installation Guide As shown in the figure, install the stand Use the screws in the mounting kit to fit... -
Page 8: Equipment Connection
Fixed the camera with brakect Equipment Connection Thanks for choosing our product. To start with, scan the following QR codes to install the app. After completion, set up your Equipment by following the steps below 1.Download the Mobile App iOS APP Android APP 1)Scan the QR codes to download it 2) For Apple users, search “UBell”... - Page 9 2.Setting up New Equipment Connect with power and wait for the system voice prompt: "Enter configuration status." (If not in this state, please wake up the device) Press and hold the reset button for 5 seconds, release it until the device LED light off, and the system restarts automatically.
- Page 10 Install a solar camera on the The name is entered according to QR code on the scanning the requirement, and the password device defaults to “admin”. Direction selection according to individual needs, equipment area. Choose according to your region (China mainland: Choose mainland China, Non-Chinese mainland: choose Non-Chinese mainland)
- Page 11 The setting is done. The Equipment will automatically enter the List of Equipment interface. Congratulations! The Equipment has been successfully installed...
-
Page 12: Setting Menu
Open the reminder mode, select the push message, when the PIR triggers the alarm, you can receive the reminder message. If you choose not to remind, you will not receive the reminder. If you choose the incoming call, you will receive the incoming call. Call reminding QR code If you have already installed your device and... - Page 13 Cloud Storage 1). In the UBell APP setting 2). At the bottom of the preview menu, choose storage manag- page, the“Switch”button in the ment, and open Cloud Storage panorama mode becomes the “Cloud Storage”button 3). Cloud Storage Description: When the device is in sleep state, PIR trigger or press the doorbell button, the device will automatically upload 8 seconds of video to the cloud, each device can record 20 events per day, and have a week of permanent free storage cloud for...
- Page 14 4). Tap the calendar icon in the 5). Click on the event video to upper right corner and select see the cloud video the date to see all the cloud videos for the selected date 4.Attention! 1) 1. This device is powered by 18650 battery. It is expected to be used for 6 months when fully charged.
-
Page 15: Technical Parameters
3)This device is a low-powered consumption intelligent product. support APP remote wake-up, PIR motion detection wake-up, press the power button wake-up, work for 15 seconds, 30 seconds, 60 seconds after each wake-up. No standby option, enter standby automatically, will keep standby untill next time wake-up. Technical Parameters MainChipset Hisilicon...
