MEIJI SMOKE DETECTOR MSD-02
14
1134-CPR-101
EN 14604
Introduction
Design
I. Technical Parameters
Working Voltage: DC 9V
Quiescent Current: < 10uA
Alarming Current: < 20mA
Alarming Decibel: > 85dB/3m
LED Indicator: LED (Red)
Low Voltage Alarming : < 7.3V
Working Temperature: -10°C~+40°C
Working Humidity: < 95%RH
Advertisement
Table of Contents
Related Manuals for Meiji MSD-02
Summary of Contents for Meiji MSD-02
- Page 1 MEIJI SMOKE DETECTOR MSD-02 1134-CPR-101 EN 14604 Introduction Design I. Technical Parameters Working Voltage: DC 9V Quiescent Current: < 10uA Alarming Current: < 20mA Alarming Decibel: > 85dB/3m LED Indicator: LED (Red) Low Voltage Alarming : < 7.3V Working Temperature: -10°C~+40°C...
- Page 2 II. Dimension (mm) TO TEST: Note: if battery is installed in the wrong way, the detector will not work and can damage the item. If the detector operates smoothly, the Red LED will flash once in about 43S 1.
- Page 3 TO INSTALL: 1. Choose a good positon to install the smoke alarm on your ceiling. 2. Use the screw to fix the installation panel on the ceiling. 3. Turn the smoke detector clockwise in order to lock it to the installation panel tightly.
