LIGMAN AA-20076 Installation And Service Manual

INSTALLATION AND SERVICE MANUAL
For Installation of Atlantic medium shade post top LED.
Model. AA-20076
Product drawing (dimensions)
■ LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■ LIGMAN luminaires are designed to conform IEC 60598 2-1 standard.
Technical amendments and modifications techniques reserved.
