Fire Innovations MOHAWK Instructions For Use Manual

Nfpa escape/ladder belt
Hide thumbs

Advertisement

Quick Links

Download this manual
Fire Innovations
830 Petaluma Blvd N
Petaluma, California 94952
United States
www.fireinnovations.com
INSTRUCTION FOR USE
MOHAWK
NFPA ESCAPE BELT
NFPA LADDER BELT
UL CERTIFIED TO
NFPA 1983 - 2012
FLAME RESISTANCE OPTION
BELT DESIGN FEATURES
Design to quickly adjust to any
firefighter's waist size.
Sized to be donned over the coat.
Easy forward fine adjustment.
With the optional Multi-Use Strap
this belt is a NFPA Ladder Belt.
Three gear loops allow installation of
multiple tool holders and accessories.
®
,
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOHAWK and is the answer not in the manual?

Questions and answers

Related Manuals for Fire Innovations MOHAWK

Summary of Contents for Fire Innovations MOHAWK

  • Page 1 INSTRUCTION FOR USE MOHAWK ® NFPA ESCAPE BELT NFPA LADDER BELT UL CERTIFIED TO NFPA 1983 - 2012 FLAME RESISTANCE OPTION BELT DESIGN FEATURES Design to quickly adjust to any firefighter’s waist size. Sized to be donned over the coat.

  • Page 2: User Information

    REPAIR Programs, and NFPA 1983, Standard on Life Safety Rope and Equipment for Emergency Services. Fire Innovations requires that all repair work be done by the manufacturer. All other repair work INSPECTION or modifications may void the warranty and shall release Fire Innovations, LLC from all liability and Inspect the belt according to your department’s...
  • Page 3 This number is unique for every belt … manufactured. † 4. The Mohawk is certified with optional buckles, this ‡ would indicate which one is installed. (2) Butterfly (3) Inverted 5. If a Multi-Use Strap is sewn-on, then this space will show (1).

  • Page 4: Product Overview

    PRODUCT OVERVIEW The Cheyenne Belt is a certified NFPA 1983:2012 Fire Resistance (FR) Escape Belt. It is easy to use and makes an outstanding multi-function firefighter escape belt. The accessory Kevlar gear loops are located on both sides, and aid the modular design of this belt.
  • Page 5 SIZING & DONNING IMPORTANT Belt should be donned prior to donning your SCBA. • Don the belt and rotate so the rear adjusting buckle is located to the front-side. • Pull the rear adjustment strap to approximate waist size, it should be snug. •  •...
  • Page 6 ACCESSORIES MULTI-USE STRAP™ / NFPA LADDER STRAP • A certified NFPA 1983:2012 Fire Resistance (FR) Ladder strap • A one leg harness • Used in RIT operations to drag a down firefighter • NFPA Positioning Point (Safety strap) in an aerial platform/bucket •...
  • Page 7 ACCESSORY POUCHES Accessory pouches allow stowage of the Multi-Use Strap as well as a multitude of firefighter accessories such as tethers. gloves, etc. ACCESSORY OR BAILOUT POUCH The installation procedures shown below apply to all accessory pouches. These pouches are recommended to be installed on the closest gear loops to the fixed Attachment Point (D-Ring).
  • Page 8 AXE - TOOL HOLDER The Tool/Axe Loop can be installed on any available Gear Loop, although the recommended installation is on the second Gear Loop from the fixed Attachment Point (D-Ring). REQUIRED TOOLS: None Use caution when donning/doffing your belt with a tool in the Axe/Tool Holder. Tool may fall and cause serious injury.
  • Page 9 SCABBARD CLIP AKA FEMALE CLIP The tool clip allows quick connection and disconnection of various tool holders, while retaining the durability and flexibility needed for today’s firefighter. REQUIRED TOOLS: Philips screwdriver Start by removing the corner screws from the clip assembly. (NOTE: do not remove center screws) Position the clip securing brackets behind the belt, keeping the debossed end towards...
  • Page 10 The Mohawk Belt has been tested and certified with several buckles. The inverted buckle is standard on this belt and highly recommended. BUTTERFLY BUCKLE (OPTION) As an option to the Mohawk Escape Belt a Butterfly style buckle is available as a factory installed option. This option has been tested and certified. BUCKLE SPECIFICATIONS •...

  • Page 11: Warranty & Return Policies

    Review Request Form included with the product or available online and fax or mail it back to Fire Innovations. Once the form is reviewed, a RMA will be issued. The customer must return the product, shipping charges prepaid, along with the warranty request to the provided address.
  • Page 12 MOHAWK ® NFPA ESCAPE BELT NFPA LADDER BELT Fire Innovations 830 Petaluma Blvd N Petaluma, California 94952 United States www.fireinnovations.com...
