Metal Detector

METARIDDER MC Series

User's Manual

MC-E (01) / 201805

Saika Technological Institute Foundation

Table of Contents

Need help?

Do you have a question about the METARIDDER MC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Saika METARIDDER MC Series

Page 1 Metal Detector METARIDDER MC Series User’s Manual MC-E (01) / 201805 Saika Technological Institute Foundation...
Page 2 Introduction Thank you for purchasing METARIDDER MC Series (hereinafter referred to as the machine). Read this manual before and during the operation to use the machine properly.
Page 3: Table Of Contents
 Symbols used in this manual ·········· 1 Warranty and Customer  Safety Precautions ························ 1 Support  Notes on the Operation ·················· 2  Warning Labels ···························· 3 6.1 Warranty Information ····················· 6-2 6.2 Inquiries & Consultations on the Before Using the Machine Product ·······································...
Page 4 OFF the primary power supply as well. If a power plug is provided, pull out the plug from the outlet. Contact SAIKA or the place of purchase for assistance.  Always use the machine at the rated voltage.
Page 5 Disassembling the metal detector will void the product warranty and SAIKA may refuse to perform maintenance services thereafter. [7] Use the machine at the rated voltage. Using it at a voltage other than the rated voltage may result in a machine failure, damage on the machine or electric shock to the operator.
Page 6 Metal Detector METARIDDER Note that SAIKA will not be held responsible for secondary accidents and/or troubles other than those caused directly by the machine. Warning Labels Rear side of frame, Transformer housing, Optional box Maintenance door Maintenance door (with safety switch)
Page 7 Metal Detector METARIDDER Inside the control panel (Main unit) Inside the control panel (Door) WARNING When opening and closing the rear side of Pinching fingers the frame and the maintenance door, use thorough caution. Be extra careful not to suffer an electric 2.3.5 Electric shock shock.
Page 8: Detection Principle And Features ·····
Metal Detector METARIDDER Before Using the Machine 1.1 Detection Principle and Features ····················· 1-2 1.1.1 Detection Principle ······································· 1-2 1.1.2 Features ···················································· 1-3 1.2 Names and Functions of Parts ························ 1-4 1.2.1 Names and Functions of Various Sections of the Machine ··············································· 1-4 1.2.2 Detection Sensitivity ·····································...
Page 9: Features ·····························
The machine is designed to make a highly accurate metal detection by the adoption of Dielectric Loss Isolated High Frequency Oscillation method sensor, which was developed by SAIKA. If a metal piece approaches the magnetic field A generated by the sensor, an eddy current runs on the metal surface and the magnetic field B will be generated to cancel the magnetic field A.
Page 10: Machine ·····························
Metal Detector METARIDDER 1.1.2 Features The machine is capable of detecting and removing metal pieces mixed in the material using a highly sensitive metal detector.  Four types of sensor calibers (20 mm, 24 mm, 30 mm and 40 mm) are available, which can be selected according to intended application, by sensitivity, the volume to be treated and shape of material.
Page 11 Metal Detector METARIDDER Names and Functions of Parts 1.2.1 Names and Functions of Various Sections of the Machine...
Page 12 Metal Detector METARIDDER Internal view 内部 Name Function Counter (optional) Displays a metal piece (foreign object) detection count. Top hopper (optional) The hopper to load the material. PLC unit (optional) Detection history data can be stored in a SD card. Buzzer/reset switch At occurrence of an error, the buzzer sounds.
Page 13 Metal Detector METARIDDER • Control unit door front view Internal buzzer: At occurrence of an error, the buzzer sounds. LEVEL lamp: Used for maintenance (gain adjustment) OUT lamp: POWER lamp: At detection of a foreign object, this lamp lights. When the power switch is ON, this lamp lights. 1.2.2 Detection Sensitivity In using the machine, note that there is a difference in the sensor signal depending on the path of...
Page 14: Running & Stopping ······················
Metal Detector METARIDDER Basic Operations 2.1 Running & Stopping ······································ 2-2 2.1.1 Running ····················································· 2-2 2.1.2 Stopping ···················································· 2-3...
Page 15: Stopping ·····························
Metal Detector METARIDDER Running & Stopping 2.1.1 Running 1. Turn ON the Main circuit breaker. (See Table 2, No. 15 in Section 1.2.1 Names and Functions of Various Sections of the Machine.) 2. Press the Operation Switch on the left side of the door. (See Table 2, No.
Page 16 Metal Detector METARIDDER Metal piece detection Detection count (Optional) Green light ON Green light ON Yellow light ON Light tower (Optional) Home Discharge position Home Discharge damper operation * The detection count value is a conceptual image. 2.1.2 Stopping 1. Press the Operation Switch while the machine is in operation. (See Table 2, No.
Page 17: Routine Inspection ························
Metal Detector METARIDDER Maintenance 3.1 Routine Inspection ······································· 3-2 3.2 Routine Cleaning ········································· 3-3 3.2.1 Routine Cleaning ········································· 3-3 3.2.2 Points of Cleaning ······································· 3-4 3.3 Sensor Sensitivity (threshold) and Sensor Signal (white noise) Adjustment”. ······························ 3-6...
Page 18 To check the detection sensitivity, confirm that a test piece will be discharged to the discharge chute properly. If the test piece cannot be discharged properly, contact SAIKA. (*1): Test pieces are optional. In order to prevent the test piece being lost in the line or mixed with the Important material, provide a protection to the discharge port.
Page 19 Metal Detector METARIDDER The cooling fan turns ON if the ambient temperature rises above 30C and turns OFF if the temperature drops to 15C. It may not be running depending on the ambient temperature. The cooling fan service life (*1) is approx. 4 years and 6 months (approx. 40,000 hours), assuming that it runs for 24 hours.
Page 20 Metal Detector METARIDDER 3.2.2 Points of Cleaning Clean the area on which the material may be adhered (the area in the yellow dotted line) with a vacuum cleaner or an air blowing device. Important Be careful not to let materials infiltrate the machine while cleaning. Cooling fan (Inside of cover) Sensor unit Lead tube...
Page 21 Metal Detector METARIDDER Name Cleaning Method Remove the cover, and clean the cooling fan with a vacuum cleaner or an air blowing Cooling fan device. Clean the door and areas around it with a vacuum cleaner and a rag. * Check for wear Maintenance door of the packing, etc.
Page 22 Metal Detector METARIDDER Sensor Sensitivity (threshold) and Sensor Signal (white noise) Adjustment. This section describes sensor sensitivity (threshold) and sensor signal (white noise) adjusting procedure. For relationship between sensor sensitivity and sensor signal, refer to the following figure. Metal piece (foreign object) detection Sensor sensitivity (SENS) * Changes depending on sensor type and operating condition.
Page 23: Errors ·········································
Metal Detector METARIDDER Errors and Troubleshooting 4.1 Errors ························································ 4-2 4.2 Troubleshooting ··········································· 4-2 4.2.1 Troubleshooting ·········································· 4-2 4.2.2 Troubleshooting for other errors ····················· 4-2...
Page 24: Troubleshooting
Troubleshooting This section explains how to address errors. If the troubleshooting method Important described in this section does not work, contact SAIKA. 4.2.1 Troubleshooting  The internal buzzer sounds.  Sensor error has occurred. If a sensor error occurs, the metal detecting function is disabled.
Page 25 Ensure that the capability of the machine. target matches the detection capability of the machine. * If larger metal pieces cannot be detected, contact SAIKA. If above actions do not solve the problem, the sensor may have failed. The sensor has failed.
Page 26 Metal Detector METARIDDER D) The discharge damper is activated frequently or there is too much material discharged improperly Assumed Cause Troubleshooting Metal pieces have attached Clean the inside (the path of the material) of the sensor unit. (*1) inside the sensor unit. Too many metal pieces are If there are too many metal pieces mixed in the material, it is possible that most of the material mixed in the material.
Page 27: Specifications·······························
CAUTION The sensor has failed. If above actions do not solve the problem, contact SAIKA. [Table 7: Troubleshooting the problem of frequent discharge damper operation] (*1): See Section 3.2.2 Points of Cleaning.
Page 28: Dimensions ·································
Metal Detector METARIDDER Specifications This chapter describes the specifications for the machine. 5.1 Specifications ·············································· 5-2 5.2 Dimensions ················································· 5-3...
Page 29 Metal Detector METARIDDER Specifications Model MC-20 MC-24 MC-30 MC-40 sφ0.2 sφ0.3 sφ0.4 sφ0.6 Detection capacity sφ0.3 sφ0.3 sφ0.5 sφ0.7 Sensor caliber φ20 mm φ24 mm φ30 mm φ42 mm Discharge port diameter φ50 mm φ60.5 mm Metal piece elimination Solenoid-driven damper mechanism 5°C to 40°C * High-temperature type: 5°C to 45°C.
Page 30 Metal Detector METARIDDER Dimensions <Standard model> 173 (Door opened) Center of hopper...
Page 31 Metal Detector METARIDDER <With optional machine> Caliber  A Model Connection pipe (example) series Test piece series loading port series Caliber  A series 173 (Door 200 (Door opened) opened)
Page 32 Metal Detector METARIDDER Warranty and Customer Support 6.1 Warranty Information ··································· 6-2 6.2 Inquiries & Consultations on the Product ········· 6-2...
Page 33: Warranty Information
METARIDDER Warranty Information SAIKA warrants that the product will be repaired with no cost to the customer is it fails due to manufacturing defects within the period of one year from the date of acceptance (or, if there is no explicit acceptance date, the delivery date).
Page 34 Metal Detector METARIDDER Options COP-1e...
Page 35 Metal Detector METARIDDER Safety Switch (Option) COP02 ⚫ It describes the Safety Switch Option. 1．Function As a safety measure function, While the maintenance door is open, automatically stops the operation of discharge dampers. 2．Names and Functions On the lower side of each maintenance door safety switch is equipped with. Discharge Damper Frame Maintenance Door...
Page 36 Metal Detector METARIDDER 3 ．Basic action While the maintenance door is open, stops the operation of discharge dampers. When the light option is used, the buzzer sounds and the light (option) red lights up. When a door is closed, warning is released, and all operation about this warning is cleared. Maintenance door is open Maintenance door is close Close...
Page 37 Metal Detector METARIDDER Counter(Option) COP03 ⚫ It describes the Safety Switch Option. 1．Function The number of metal detections is displayed on the counter. 2．Names and Functions A Counter is on the Control-box Door. It displays the number of metal-detection. ●How to Reset of the counter. Push the button on front panel of counter (about 1 second ), then the Counter is reset.
Page 38 Metal Detector METARIDDER Bridge Prevention Unit （Option） S001e Description for Bridge Prevention Unit Overview A Option-Unit for MC/MHD that prevents and eliminates clogging due to material bridges in the Upper Hopper Specifications The Motor is driven to swing the Stirring Plate through the Link. （The swing width changes with the sensor aperture.）...
Page 39 Metal Detector METARIDDER Basic action The rocking of the stirring plate starts at the same time with the power ON. It is always moving while driving. ■Recommended set value Motor rotation speed ： 300rpm (As Shipped) ※Refer to Operation Manuals of Motor (7.Appendix) ,for how to change the set value. Maintenance Check and clean it regularly.
Page 40 Metal Detector METARIDDER ▼1ch *1:Holes for setting protector unit *2: Dimensions in () are for Sensor ID=φ30,42 type of MHD. When it use Anti-Wear Processing, the Stirring plate is subjected to the treatment. S001-3...
Page 41 Metal Detector METARIDDER ▼2ch <Unit type for φ15,20 of Sensor > Note1 *1:Holes for setting protector unit <Unit type for φ30,40 of Sensor > Note1 When it use Anti-Wear Processings, the Stirring plate is subjected to the treatment. Note1: The Unit type to be attached differs depending on the sensor diameter.
Page 42 Metal Detector METARIDDER ▼4ch *1:Holes for setting protector unit When it use Anti-Wear Processing, the Stirring plate is subjected to the treatment. *2: Dimensions in () are for Sensor ID=φ40 type. S001-5...
