Summary of Contents for OZ Trends Oz Safe OZT191
- Page 1 User Manual...
- Page 2 Model:OZT191 Website: h ttp://www.oztrends.com.au Customer Service / Support Email: info@oztrends.com.au...
- Page 3 Introduction Oz Safe s mart garage door opener is the companion device of your existing garage door opener. It can make your garage door smarter and secure. By using it, garage door opener can be controlled or monitored at your own will.
- Page 4 If you find any part is missing in the package, please contact us, we will provide proper solution for you.
- Page 5 Installation Guide 1. D ownload the witgarage app...
- Page 6 2. C reate an account Warning : Power must be off before installation.
- Page 7 3. P ower on the device and wait about 5 seconds until the LED flashes rapidly.
- Page 8 4. C onnect the device to your router with witgarage app Tap “add device” on your app, and follow the instruction to complete the setting. When device has been successfully added, LED will turn into solid green. Note: I f the led flashes in blue color, it is ok, please continue to the next step.
- Page 9 6. S ensor installation C lose your garage door, remove the sticker at the back of sensor and stick it on the top flap of your garage door.see the following figure. Please note the direction.
- Page 10 7. C onnect the wire of the device to the terminals that connect to the wall button, and wire order does not matter. See following figure:...
- Page 11 8. T est Power on both the garage door opener and device, and control your garage door through app and check the corresponding status of your garage door. Note: T he state may be not correct at the first and second time,if it is not correct, please try to open or close the door for more times,it will be ok after up to four operations.
-
Page 12: Points For Attention
Points for attention: 1. 1) Flash rapidly in red In default mode with network disconnected, please use default mode to connect Wi- Fi. 2) Flash slowly in red In default mode with network disconnected, please use AP mode to connect Wi-Fi. 3) Flash in green Network connected but Wi-Fi configuration information is wrongly inputted, or the device is blocked by firewall, please check your... - Page 13 button will clear the configuration of Wi- Fi. The device will be reset， and you need to add device and reset configuration. 3) Long press the button for 7 seconds or above, the controll will unbind the sensor, it will flashes in blue. 3.
-
Page 14: About App
About App Home Page Witgarage app support Tuya IP camera. If you add a Tuya IP camera to Witgarage app, it will show and will work with our iGarage device. The picture below shows all functions of iGarage which work with Tuya IP camera. - Page 15 1 Name. The name of actived iGarage device. 2 Status. The status of your garage door. 3 Control icon. It will active your garage door when you click this icon. 4 Delete icon. I f the network is ok, once tapping it，the iGarage device will be deleted and the configuration will be reseted.
- Page 16 2. Function Page. 1 Bind iGarage device: B ind the camera with one or more iGarage devices. 2 Rename: Rename your device by tapping it. 3 Share device: B y tapping it, you can share your device with family members on condition that they use the same app and have their accounts.
- Page 17 4 Smart control: U sing GPS to automatically open and close garage door. T his function is a limited one for systematical reasons, this function is only available on some phones. Turn off the function if you don’t need it. 5 ...
- Page 18 3. V oice Commands When using voice command, pay attention to the name of device which can be changed. In the following order, “witgarage” is the name of the device. Voice Commands: “Alexa, turn on (Witgarage)” “Alexa, turn off (Witgarage)” Google Home The integration of iGarage and Google Assistant Action allows voice command to control the door status.
- Page 19 ✓ A Google Home device, or an Android phone with Google Assistant. ✓ Latest Google Home app. ✓ Latest Google app (Android only) ✓ A Google account. ✓ The device display language must be set to English US. ✓ Witgarage app and a related account. ✓...
- Page 20 FAQs The app shows “try again” when configure the Wi-Fi, or other Wi-Fi connection issues. How to check compatibility and how to connect the wires of Witgarage to my garage door opener? How to create an account for Witgarage app? How to share the device to your family members? Does Witgarage app support two or more Witgarage device to control more garage doors?
- Page 21 Please try to find help from our website or send us E-mail for support.
