Drake Muscle Cars JR3B-6510129-AB Installation Instructions

If any part of this installation seems beyond your level of installation experience, please seek the help
Before installing this Drake Muscle Cars product, please read through
the installation procedure and verify that all parts are present, including
the supplied hardware. If any items are missing, please contact Drake
Muscle Cars at (702) 853-2060, 8:00 AM to 5:00 PM PST.

KIT INCLUDES

• 2 Side Rocker Splitters
• T20 Head Self-Tapping Screws

TOOLS NEEDED FOR INSTALLATION

• T20 Torx Bit
• Plastic Panel Removal Tool

INSTALLATION

1. Suspend the front of the vehicle on jack stands or place the vehicle
on a lift to ensure ample working space.
2. Thoroughly clean the underside of the factory side rocker panels
prior to installing the side splitters.
3. Pry the 8 plastic pins from the factory locations. (figure 1)
4. Remove the factory deflector from the rocker panel towards the rear
of the car (figure 2)
2015+ SIDE ROCKER SPLITTERS
Installation Instructions for 2015-20 Ford Mustang

WARNING!

of a certified professional.
JR3B-6510129-AB
Figure 1
Figure 1A
Figure 2
