Thorne & Derrick THERMON Terminator ZT-P-XP Installation Procedures Manual

Thermostat connection kit
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Tel: +44 (0)191 490 1547
Fax: +44 (0)191 477 5371
Email:
northernsales@thorneandderrick.co.uk
Website:
www.heattracing.co.uk
www.thorneanderrick.co.uk
TM
Terminator
ZT-P-XP
Thermostat Connection Kit
INSTALLATION PROCEDURES
PN 27656
For Thermostat Connection (1-2 Heating Cables) Applications
For Use with Parallel Heating Cables

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THERMON Terminator ZT-P-XP and is the answer not in the manual?

Questions and answers

Summary of Contents for Thorne & Derrick THERMON Terminator ZT-P-XP

  • Page 1 Tel: +44 (0)191 490 1547 Fax: +44 (0)191 477 5371 Email: northernsales@thorneandderrick.co.uk Website: www.heattracing.co.uk www.thorneanderrick.co.uk Terminator ZT-P-XP Thermostat Connection Kit INSTALLATION PROCEDURES PN 27656 For Thermostat Connection (1-2 Heating Cables) Applications For Use with Parallel Heating Cables...

  • Page 2: Installation Procedures

    Terminator ZT-P-XP INSTALLATION PROCEDURES Receiving, Storing and Handling . . . The following installation procedures are suggested guidelines for the installation of the Terminator ZT-P-XP Kit. 1. Inspect materials for damage incurred during shipping. 2. Report damages to the carrier for settlement. Kit Contents .
  • Page 3 Terminator ZT-P-XP INSTALLATION PROCEDURES GRW-G/Tstat Locate bus connection (HPT and FP only) and For HPT and FP cable, exchange grommet in Insert cable into expediter. If mounted on cable as shown. Cut end of cable at angle to aid Terminator with grommet provided in PETK-3-ZT. bottom or side of pipe, punch out weep hole.
  • Page 4 Terminator ZT-P-XP INSTALLATION PROCEDURES Fix thermostat bulb and capillary tube to pipe. Mount expediter to pipe using pipe band. Do Route thermostat bulb through nut and not band over cable. Tape cable expansion expeditor opening in junction box base. If loop to pipe.

  • Page 5: Wiring Details

    Terminator ZT-P-XP INSTALLATION PROCEDURES Two Cable Layout Tips Locate bus connection (HPT and FP only) and Insert two cables into expediter. cable as shown. Cut end of cable at angle to aid Note: For HPT and FP cable, exchange grommet in in piercing grommet.
  • Page 6 Française Deutsch Terminator ZT-P-XP Terminator ZT-P-XP Thermostat-Anschluss-Set Kit de connection pour thermostat INSTALLATIONSANWEISUNG Procédure d'installation Für Temperatursteuerung/-anschluss (1 bis 2 Heizkabel) Pour connexion d'un thermostat (1 ou 2 câbles chauffants) Warnhinweise… Avertissement… • Wegen der Risiken eines Stromschlags, eines Funkendurchschlags •...

  • Page 7: Инструкция По Монтажу

    Spanish Русский Terminator ZT-P-XP Термостат ZT-P-XP Kit de conexión a termostato Комплект для подключения термостата INSTRUCCIONES DE INSTALACIÓN ИНСТРУКЦИЯ ПО МОНТАЖУ Para conexión a termostato (aplicaciones con 1 o 2 cables calefactores) Для подключения (1-2 нагревательных кабелей) Advertencias… Меры предосторожности… •...
  • Page 8 Nederlands Теrminator ZT-P-XP Thermostaat aansluitset Installatie Richtlijnen T.b.v. thermostaat aansluiting (1-2 verwarmingskabel) Waarschuwingen… • Thermon verwarmingssystemen moeten altijd geïnstalleerd worden met de correcte elektrische beveiligingen. Thermon adviseert altijd een installatie automaat/zekering met aardlekbeveiliging toe te passen. • De installatie moet in zijn geheel voldoen aan de locale voorschriften voor elektrische installaties (inclusief form PN 50207U voor Ex systemen) en aan de IEC 60079-14 bij gebruik in explosiegevaarlijke omgevingen.
