5. Assembling the high chair (80-92H cm)
Step 1 : Extending the four legs. Not executing obtains the low chair (62H cm)
Press the locking pin B and pull at the same time the inner leg from its housing. Extend the inner leg until
it clicks audibly into the lower slot with the locking pin C. Repeat with the remaining legs.
Optional step 2 : Increasing the seat height depending on the height of the child.
To raise : pull the seat support out of the seat and turn it around. Push the tray back on the seat.
Step 3 : Positioning the dining tray
Push the tablet into place with an audible click in one of the three possible positions in depth on the rails
below the armrests.
