Failure to comply with or observe all assembly, safety and operation
instructions and warnings regarding the use of this product may result
in serious property damage or bodily injury.
Make sure no obstacles are in the desk's path and all cords are of appropriate
length for the desk. Always maintain a 1" clearance around the table to prevent
pinching.
Never assemble (or disassemble) the table or components with the table plugged
into a power outlet. This product is for use on a nominal 120-volt circuit and has
a grounding plug. Make sure that the product is connected to an outlet having the
same configuration as the plug. No adapter should be used with this product.
Do not operate the workstation until it is completely assembled.
INSTRUCTION # 52819
VertDesk ™
4601-C Camp Phillips Road
Weston, WI 54476
PHONE: 866.733.0698
info@vertdesk.com Version
Dated: 02/03/16
Read all the instructions before beginning.
PAGE 1 OF 7
