ITC Stow & Go Standard Installation Instructions

PARTS NEEDED:

Stow & Go Handle
Standard or Mini
IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY FOR YOUR PROTECTION AND SAVE ALL INSTRUCTIONS.
* The Stow & Go handle should be installed into strong material or will run the risk of being pulled out of the wall.
* The Stow & Go handle should never be left in the operating position while traveling.
1.
Determine the installation location for your handle*, making sure there
is strong material behind the location to support the handle. Remove
the end caps, which are supplied not fully clipped into place.
*Ensure end caps are vertically aligned
2.
Mark the screw holes on the end caps. Note
that the standard handle measures 27.25" and
the mini handle measures 23" from the top
of one cap to the bottom of the other. It is
recommended that a 1/16" drill bit be used
to drill a pilot hole.
Phone: 616-396-1355 • Fax: 616-396-1152 • www.itc-us.com • sales@itc-us.com • Revision 1: 6/7/16
Stow & Go Assist Handle Installation Instructions
(Part #'s: 86472-XX/Y or 86473-XX/Y)
#8 1.25" x 8 Pieces Flat Head
Screws (not provided)
230 E. Lakewood Blvd. • P.O. Box 8338 • Holland • MI • 49422-8338

TOOLS NEEDED:

Power Drill w/ 1/16" Drill
Bit & Quad Bit
Silicone Sealant
(Optional)
