- Page 1 Tank Filling sysTem 462F4501 Software rel. 1.x insTallaTiOn, Use anD mainTenanCe...
- Page 2 This manual is an integral part of the equipment to which it refers and must accompany the equipment in case of sale or change of ownership. Keep it for future reference; ARAG reserves the right to modify the specifications and instructions regarding the product at any time and without prior notice.
-
Page 3: Table Of Contents
SUMMARY 1 SAFETY GUIDELINES ............................ 4 2 PRODUCT DESCRIPTION ..........................4 Intended use ......................... 4 3 INSTALLATION ..............................5 Electric connections ......................6 Hydraulic connections ......................7 3.2.1 General warnings ........................ 7 3.2.2 Hydraulic connections ......................7 Connections - general diagram .................. -
Page 4: Safety Guidelines
Do not operate the valve with no load for long periods of time, as this might damage the components inside the valve. ARAG can not be held responsible for direct or indirect damage caused by the type of fluids used for spraying and crop spraying applications. -
Page 5: Installation
50 mesh, together with a safety valve to limit use pressure at the specified max. value (12 bar). CAUTION: ARAG is not liable for damage to the system, persons, animals or things caused by the use of material other than specified. Failure to observe the above instructions automatically voids the warranty. -
Page 6: Electric Connections
INSTALLATION Electric connections The tank filling system must be connected using the supplied cables. valve cable 12 Vdc to flowmeter to computer (e.g., Bravo 400s, Bravo 300s) - Remove the protection cap from the valve - Position seal (1 in Fig. A) onto connector (2 in Fig. A), then connect the latter pressing it fully home (3 in Fig. -
Page 7: Hydraulic Connections
Regarding connections, use tubes and fittings properly sized for the operating pres- sure of the system. Use Arag T6 fittings (see general catalogue) with female fork coupling. Do not use elbow fittings. WARNING: For the implementation on already operating systems it is necessary to follow all safety rules described herein. -
Page 8: Monitor Rotation
INSTALLATION Monitor rotation In case of vertical assembly, to simplify the use of the DigiWolf it is possible to rotate the monitor by 90° with respect to the body. 1) Remove the fork from the monitor using a screwdriver. 2) Remove the monitor from the flowmeter body. If the monitor is turned upside down, the letters A and B can be seen: these correspond to the two possible monitor positions (parallel and perpendicular to the... -
Page 9: Controls In The Menu
CONTROLS COntROlS in tHe Menu SWitCH On The flowmeter is turned on when powered. 0.0 l Press the key to see the succession of different values written in full (central part of the display). 0.0 l/min Whenever the device is switched on, it will briefly display its name and software version. -
Page 10: Menu Structure
MENU Menu StRuCtuRe Calibration Auto calibration Setup menu Man. calibration Par. 9.1.1 Calibration Calibration Flowrate alarms Display Auto calibration Man. calibration Par. 9.1.2 Flowrate alarms Min flow alarm Setup menu Max flow alarm Par. 9.2 Calibration Flowrate alarms Flowrate alarms Display Min flow alarm Max flow alarm... -
Page 11: Preliminary Setup For Use
SETUP PReliMinaRy SetuP fOR uSe For a correct display of data regarding treatment, some preliminary set ups are necessary when installing DigiWolf on farming machines. Operating mode selection (FILLING / FLOWRATE) DigiWolf can be used to measure the flowrate of a fluid in a hydraulic circuit ("Flowrate" mode), or to control the filling of a tank by stopping the introduction of liquid once the set quantity has been reached ("Filling"... -
Page 12: Flowmeter Use (Filling Mode)
USE (FILLING MODE) Flowmeter use (FILLING mode) The main screen shows the display divided into three horizontal sectors: - upper sector: The Start item refers to the key on the side, which allows starting the procedure (OK key); - central sector: ¬... -
Page 13: Use In Flowrate Mode
- To avoid damaging the flowmeter, do not exceed the maximum rate except for short periods. ARAG can not be held responsible for damage caused to persons, animals or things from the incorrect or unintended use of Digiwolf or its parts. -
Page 14: Other Settings
SETUP OtHeR SettingS What follows applies to both operating modes of the flowmeter. Calibration Rate reading may not be correct due to different system configurations (tubes, valve, etc.). Therefore, we recommend to make a spray test; in case the measured value is different from the real one, perform an automatic calibration procedure or manually calculate flowrate constant. -
Page 15: Manual Calibration
SETUP 9.1.2 Manual calibration To set the flowrate constant manually, calculate and set the correct constant using the following formula: [amount measured by device] x [constant indicated on flowmeter body] [actually delivered quantity] 1) Access Manual calibration menu (Setup menu > Calibration > Man. calibration). Calibration In Calibration menu, selecting Manual calibration, under the item the cur- Auto calibration... -
Page 16: Display
SETUP Display Adjust display brightness and contrast. Access display menu (Setup menu > Display). Brightness and contrast adjustment is done in the same way. Display Brightness Under the selected item, the currently set value will be displayed. Contrast Press OK key to access modification of the selected item. 1) Set the value using the key. -
Page 17: Units Of Measurement
SETUP 9.4.2 Units of measurement Set units of measurement for flowrate values and volume read by the device. 9.4.2.1 Rate units of measurement Access instant rate units of measurement menu (Setup menu > Options > Units of measurem. > Flowrate). Units of measurem. -
Page 18: Test
SETUP Test In this menu is it possible to see some information and run a device operation test: - Firmware version: The display shows the firmware version installed on the device. - Sensor frequency: In the presence of flow passage, the display shows in real time the frequency of the signal from the sensor reading the flowrate. -
Page 19: Maintenance
MAINTENANCE MaintenanCe 10.1 Notes on maintenance - At the end of each treatment, run clean water through the tubes. - Clean the tank filling system pipe with a special detergent on a regular basis. - Clean (and if necessary, replace) the flowmeter paddle on a regular basis (page 19, chap 10.2) - Do not use metal or abrasive objects to clean the paddle. -
Page 20: Or Replacement
1) Remove the fork from the ring nut using a screwdriver. 2) Remove the ring nut. - OR replacement: Replace the ORs (Code G10051V - ARAG spare parts catalogue). 3) Refit the sensor housing block ensuring that the fork is correctly inserted in the ring nut. -
Page 21: Troubleshooting
MAINTENANCE 10.4 Troubleshooting fault CauSe ReMedy • Make sure there are no foreign bodies; Presence of foreign bodies The valve leaks or the seal of the if so, remove them. ball is not enough Worn seals • Contact your nearest assistance centre. •... -
Page 22: Technical Data
TECHNICAL DATA teCHniCal data Data Min. Max. Default UoM Notes Calibration Manual calibration 50,000 The alarm can be deactivated Min. flowrate alarm 99999.9 l/min. setting the value "OFF" flowrate alarms The alarm can be deactivated Max. flowrate alarm 999999.9 l/min. setting the value "OFF"... -
Page 23: Disposal At The End Of Service
diSPOSal at tHe end Of SeRviCe Dispose of the system in compliance with the established legislation in the country of use. INFORMATION TO USERS – PROFESSIONAL WEEE RECYCLING This product complies with European Directive 2002/96/EC and subse- quent modifications. At end-of-life and for disposal, the device must be ta- ken to a waste recycling centre for electrical and electronic waste, or retur- ned to the seller when buying a new equivalent device. - Page 24 Notes...
- Page 25 Notes...
-
Page 26: Guarantee Terms
GUARANTEE guaRantee teRMS 1. ARAG s.r.l. guarantees this apparatus for a period of 360 day (1 year) from the date of sale to the client user (date of the goods delivery note). The components of the apparatus, that in the unappealable opinion of ARAG are faulty... - Page 27 (*) Dichiarazione ai sensi All. II B Dir. 2006/42/CE • la documentazione tecnica pertinente è custodita da Arag, nella persona del suo legale rappresentante, sig. Giovanni Montorsi; • ci si impegna a trasmettere, in risposta ad una richiesta adeguatamente motivata delle Autorità Nazionali, informazioni pertinenti sulle quasi-macchine.
- Page 28 Only use original ARAG accessories and spare parts, to maintain safety conditions foreseen by the constructor. Always refer to the ARAG spare parts catalogue. 42048 RUBIERA (Reggio Emilia) - ITALY Via Palladio, 5/A Tel. +39 0522 622011 Fax +39 0522 628944 http://www.aragnet.com...
