Incra Twin Linear Owner's Manual

Dual carriage, dual split fence universal woodworking system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Hi-Rise fence cap
Fence cap braces
Fence mounting
bracket
Infeed fence
during outfeed fence offset adjustments)
Please read this Ownerʼs Manual before
use and keep it at hand for reference.
If you are setting up the TWIN at your
NOTE
table saw, follow the mounting instructions
included with the TSII Base Mount Kit
Stainless steel
primary scale
Base
Rear black thumbscrew (Tighten only
Hairline cursor
OWNER'S MANUAL
Please take just a few minutes of your time to read
your new INCRA TWIN LINEAR ownerʼs manual.
Youʼll find it full of interesting and useful information
about safety, setting up, and putting to use the many
wonderful features of the TWIN. And itʼs all written
by someone who continues to use every INCRA
product from the very first INCRA Jig all the way up
to our best offering ever — the INCRA TWIN LINEAR!
In eight years of using one INCRA Jig or another
virtually every weekend (and some week nights) Iʼve
come to know these tools inside out. In writing this
manual I want to share this experience with you. Iʼve
attempted to make everything as clear as possible,
but if you are in doubt, weʼll be here to help. See
you in the shop!
Outfeed fence
Forward black thumbscrew
Black infeed fence
adjustment knob
Infeed carriage
(black)
— Perry
(Loosen only during fence
offset adjustments
Carriage clamp
Lexan
®
"floating" scale
Outfeed carriage
(gold)
Red
micro adjust
Dust
knob
collection
port

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Twin Linear and is the answer not in the manual?

Questions and answers

Related Manuals for Incra Twin Linear

Summary of Contents for Incra Twin Linear

  • Page 1 TWIN. And itʼs all written by someone who continues to use every INCRA product from the very first INCRA Jig all the way up to our best offering ever — the INCRA TWIN LINEAR! In eight years of using one INCRA Jig or another virtually every weekend (and some week nights) Iʼve...

  • Page 2: Table Of Contents

    Extender Bar and Stop ....6 carriage clamp is fully engaged and the jig is securely Incra Stop Assembly ..... 6 locked in place.

  • Page 3: Twin Linear Setup

    TWIN LINEAR SETUP Fig. 1 For those of you setting up the TWIN on an “INCRA NOTE Suggested router TWIN ready” router table, the mounting holes will be table dimensions predrilled with T-nuts installed. Skip to Step 2. Suggested Router Table Dimensions If you donʼt already own a router table, Fig.
  • Page 4 Access blade and “zero” to the cutter, but remember this: Since the holes INCRA TWIN will only clamp every ⁄ ", you must always Socket head make sure the carriage clamp is locked before positioning...

  • Page 5: Accessories

    Stainless steel washer and tighten the two cap mounting screws, Fig. 7. Though designed for permanent residence on your INCRA TWIN, you may prefer to take it off, since it is not needed for most of the things youʼll do with the TWIN. Just...

  • Page 6: Installing The Extender Bar

    #8 – 32 hex nut thumbscrews to clamp the INCRA Stop to the fence. In use, the plastic strip provides a non-metallic stop surface which can be shaped for special stop setups and can be...
  • Page 7 For most applications, you will be using your INCRA Stop on Top view of stop setup the outfeed end of the INCRA Fence to control the length of a cut relative to the front end of the board. Here is how to set...

  • Page 8: Operation

    When you see your measurement under the hairline, pull the clamp back up to the locked position, Fig. 14. Remember that the INCRA TWIN will First: only clamp every ", so donʼt try to Unlock carriage clamp clamp in between scale marks.

  • Page 9: Micro Adjusting

    First, always micro adjust your fingers. See Fig. 16. back to mid-range before beginning a new project. The micro adjust feature of the INCRA TWIN has an Second, whenever you need to micro adjust a adjustment range of + "...

  • Page 10: Offset Adjustment

    Offset Adjustment The infeed and outfeed fences of your INCRA TWIN Micro adjust the infeed fence position can be moved independently in two directions to Rotate the knob with the black dial (located at provide a variety of setup configurations. By making...

  • Page 11: Outfeed Fence Adjustment

    Outfeed Fence Adjustment Most offset fence operations can be accomplished with an infeed fence adjustment, but on occasion you may wish to fine-tune the outfeed fence without altering the infeed fence position. Hereʼs how it is done. See Fig. 18 as you read the steps.

  • Page 12: Gap Adjustment

    Gap Adjustment Follow these steps to adjust the opening between the Fig. 19 infeed and outfeed fences (See Fig. 19) Adjusting the fence gap Caution: When adjusting the fence opening or Second: gap, never position the aluminum fence ends Adjust gap closer than ”...
  • Page 13 Attach subfence to infeed fence Fig. 22 Place the (2) - 20 x " socket head cap screws Offset infeed fence with washers through the holes in the subfence and loosely attach the - 20 rectangular nuts. (Fasteners supplied in the auxiliary fence hardware pack) Slide the subfence onto the infeed fence so the fasteners are captured in the T-slots.

  • Page 14: In-Line Fence Applications

    Youʼll also find the in-line position useful for many specialty countless varieties of box joints and dovetails. General Purpose Fence The essence of any INCRA JIG is its ability to accurately Fig. 25 position your board for a cutting operation. In a nutshell, it is General purpose fence a precision fence system.

  • Page 15: Vertical Panel Raising

    Joint Making Joint making represents one of the most exciting applications for your INCRA TWIN. Just by applying a little technique to the accuracy of the TWIN, youʼll be able to add joinery for box and drawer making to your list of shop skills.

  • Page 16: Offset Fence Applications

    OFFSET FENCE APPLICATIONS One of the most valuable features of the INCRA TWIN LINEAR is the ability to offset the infeed and outfeed fences. The offset fence adds a whole new dimension to the router table, allowing it to perform two new operations: jointing and shaping.

  • Page 17: Shaping

    Shaping Many shaping operations involve Fig. 29 the removal of the entire edge of a Set initial fence position square piece of stock as it is moved past the cutter. With a careful offset fence setup, a shaping operation can simultaneously straighten or joint the shaped edge.

  • Page 18: Adjustments

    All of the components and features of your new INCRA TWIN LINEAR have been factory set and should require no The INCRA TWINʼs base must be attached to the router further attention. If, however, you wish NOTE table with all eight mounting screws (see Fig. 3 on page 4.) to adjust or recalibrate these before adjusting the clamping pressure.

  • Page 19: Realigning Carriage And Fence Racks

    Bridge the gap between the loosened and the already tightened rear rack and the second rack. See tightened racks using the INCRA Stop, then tighten the Fig. 33. Tighten the one mounting screw you have access two screws on the loose rack.

  • Page 20: Parts And Optional Accessories

    LIFETIME WARRANTY ON POSITIONING RACKS If an Incra positioning rack in this tool becomes damaged for ANY reason, Taylor Design Group will replace it free of charge for as long as you own your tool. Return the damaged rack, postage prepaid, and allow 1 to 2 weeks for delivery.
