Summary of Contents for Delta Core Pack TYXAL+
-
Page 1: Quick Installation Guide
Pack TYXAL+ www.deltadore.com Quick installation guide... - Page 2 Thank you for purchasing this DELTA DORE alarm pack. This quick installation guide provides you with the basic installation instructions for your products. Refer to the system guide for an advanced installation of your Pack. The Pack TYXAL+ comprises: - 1 CS 8000 TYXAL+ siren control unit - 2 TL 2000 TYXAL+ remote controls - 2 DMB TYXAL+ motion detectors - 1 CLT 8000 TYXAL+ touch screen keypad...
- Page 3 Activation: main steps The products in the Pack TYXAL+ were associated in the factory so as to make them easier to install. Installing and mounting the products starting with: - the CS 8000 TYXAL+ siren control unit - the CLT 8000 TYXAL+ touch screen keypad - the DMB TYXAL+ motion detectors The TL 2000 TYXAL+ remote controls can be programmed (functions of buttons 1 and 2) and associated with the control of control systems...
- Page 4 Installing and mounting the products 1.1 CS 8000 TYXAL+ control unit • Location - On a fl at surface, with enough space all around for installation and opening the battery cover. - In the centre of the system and fi tted in a high position to obtain the best radio link (avoid basements).
- Page 5 1.2 CLT 8000 TYXAL+ touch screen keypad • Location It is advisable to install the touch screen keypad inside near one of the main entrances, if possible protected by an intrusion detector (e.g. DMB TYXAL+) The user must have easy access and it can be mounted on a wall at a height of 1.50 m.
- Page 6 Installing and mounting the products 1.3 DMB TYXAL+ motion detector DMB TYXAL+ uses infrared (heat) to detect any moving presence in the room. It has 2 removable lenses: - no. 1: standard (fi tted on the product supplied). - no. 2: animal immunity (does not detect animals of a certain size, or household appliances such as robot vacuum cleaners).
- Page 7 • Mounting - Open the unit - Mark and drill the holes according to the location of the detector (see below - Mount it on the wall V3,V7,V8 = Tamper alarm on opening. Important: do not damage or lose the rubber part (required for the tamper alarm).
-
Page 8: Confi Guring A Tl 2000 Tyxal+ Remote Control
Installing and mounting the products 1.4 Confi guring a TL 2000 TYXAL+ Activa- Deactivation remote control tion the alarm Button 1 Button 2 You can activate or deactivate the alarm system with the programmable programmable remote control. Depending on the confi guration defi ned with your installer, buttons 1 and 2 can be programmed and have different functions (see table opposite). -
Page 9: Maintenance Mode
Close the alarm control unit Ê Replace the cover of the siren Ë Screw in the closing screw and replace the protective tab Adding additional products (if necessary) Example: a telephone transmitter Maintenance Ë Enter the installer code (123456, by default) and confi rm with OK. mode 25/11/14 12:48... -
Page 10: Name The Products
Personalising the installation and the products The CLT 8000 TYXAL+ touch screen keypad allows all the personalisation operations of the system. The following menus can be accessed by the installer code. The CLT 8000 TYXAL+ touch screen keypad can be used for all activation actions. Deactivate the tamper alarm (see §... -
Page 11: Test Under Operating Conditions
Testing the installation Test under operating conditions Test your installation under actual operating conditions by triggering an alarm with each of your detectors. During this test, you must take the “exit timer” into account to achieve effective surveillance (up to 90 seconds). Test the motion detectors The motion detector stores each passage in the detection zone for 90 seconds (whether or not the system is on). -
Page 12: Additional Items
Overview of your installation Activation date: ........Name and stamp of installer: ........Items of the pack: No. or name of Immediate/delayed Type Name Comment (e.g. location) zone triggering DMB 0 01 02 Example: Zone 1 or Home Delayed (30 s) Ground floor corridor Motion detector or Corridor 1...
