BIG FOOT™
Model RE500
Get parts online at
www.huntriversedge.com
BIG FOOT™ XL with Footrest
Model RE507
IncLudEs MOdEL #'s:
TM
RE500, Big Foot
RE504, Baby Big Foot
TM
RE501, Big Foot
XL
TM
RE506, Big Foot
with Footrest
RE507, Big Foot
TM
XL with Footrest
RE503, Lite Foot
TM
RE511, Big Foot
TM
XL Lounger
RE509, Big Foot
TM
XLT
TM
Operator's Manual
Hang-On Stands
BIG FOOT™ XL
Model RE501
OMREHO001
Revised 02/23/12
© 2012 RETI, Inc.
All Rights Reserved.
Advertisement
Related Manuals for TMA RIVERS EDGE BIG FOOT RE500
Summary of Contents for TMA RIVERS EDGE BIG FOOT RE500
- Page 1 Operator's Manual Hang-On Stands BIG FOOT™ XL with Footrest Model RE507 BIG FOOT™ XL BIG FOOT™ Model RE501 Model RE500 IncLudEs MOdEL #'s: RE500, Big Foot RE504, Baby Big Foot RE501, Big Foot RE506, Big Foot with Footrest RE507, Big Foot XL with Footrest RE503, Lite Foot RE511, Big Foot...
-
Page 2: Warranty
Failure to use or improper use of the provided Full Body Harness (Fall Arrest System) that meets TMA standards may result in serious injury or death. ALWAYS wear the provided Full Body Harness (Fall Arrest System) that meets TMA standards while using this product. - Page 3 TWO YEARs OR WhEN ANY sIGNs Of DAMAGE OR YOu MusT AlWAYs usE ThE PROvIDED full BODY WEAR ExIsT BEfORE. hARNEss (fAll ARREsT sYsTEM) ThAT MEETs TMA sOME MODEls INCluDE A fOOTREsT, WhICh Is DE- sTANDARDs WhIlE usING ThIs PRODuCT. sINGlE sIGNED As A fOOTREsT ONlY.
- Page 4 Operator's Manual Rivers Edge Hang-On Stands WARNING ThE usE Of A lINEMAN's/ClIMBING BElT Is RE- QuIRED WhIlE AsCENDING, DEsCENDING AND IN- sTAllING A hANG-ON TREEsTAND TO sTABIlIZE ThE usER WITh ThE TREE. ClIMBING AIDs (sTICK lADDERs, sECTIONAl lAD- DERs, sTEPs, ETC.) MusT ExTEND ABOvE ThE PlAT- fORM TO AllOW ThE usER TO sTEP DOWN ONTO ThE PlATfORM.
-
Page 5: Inspection And Maintenance Schedule
• Inspect cables and cable ends for damage or kinking. • Use the provided Full Body Harness (Fall Arrest System) that meets • Inspect all hardware and chain components for damage. TMA standards at all times including ascending to and descending from a tree stand • Inspect for any structural damage to product. (Return to factory for repair or discard product if any damage is found.) • Be fully aware of foot placement • Inspect all nut and bolt assemblies to be certain none are loose. - Page 6 Operator's Manual Rivers Edge Hang-On Stands AssEMBlY INsTRuCTIONs (RE504, RE500, RE501, RE503, RE506, RE507) Tools needed – two 7/16" wrenches nylon washers IMPORTAnT AssEMBLY TIP: do not tighten any nut and bolt combi- 1/4-20 x 2-1/4" bolts nations completely until all parts are assembled together! Finger tighten plus one turn of a wrench only! This will temporarily hold the seat frame lock nut on the bolt while helping alignment of all parts! After all parts...
- Page 7 Operator's Manual Rivers Edge Hang-On Stands sETuP AND usE INsTRuCTIONs (RE504, RE500, WARNING RE501, RE503, RE506, RE507) During installation and removal of a hang-on treestand, you must DO NOT TWIsT sTRAP WhEN ATTAChING. sEE fIGuRE always and properly use the included Full Body Harness (Fall Arrest 4 fOR CORRECT ATTAChMENT.
- Page 8 Operator's Manual Rivers Edge Hang-On Stands BABY BIG fOOT (RE504) BIG fOOT (RE500) BIG fOOT xl (RE501) lITE fOOT (RE503) Check for parts online at www.huntriversedge.com or call 800-450-EDGE (3343) M-F 8-5...
- Page 9 Operator's Manual Rivers Edge Hang-On Stands RE504 RE500 RE501 RE503 KEY # DEsCRIPTION PART # QTY. PART # QTY. PART # QTY. PART # QTY. BOLT 5/16-18 X 1-3/4" HH BLK ZN 8655B 8655B 8655B 8655B CABLE 26" BLACK VINYL W/BLACK 48210 48210 48210 ENDS CABLE 28" BROWN VINYL W/BLACK 48212 ENDS BOLT 1/4-20 X 1-1/2" HH BLK ZN 48240B 48240B 48240B 48240B...
- Page 10 Operator's Manual Rivers Edge Hang-On Stands fIxED POsITION hANG-ON PARTs (RE507, BIG fOOT xl WITh fOOTREsT) fIxED POsITION hANG-ON PARTs (RE506, BIG fOOT WITh fOOTREsT) Check for parts online at www.huntriversedge.com or call 800-450-EDGE (3343) M-F 8-5...
- Page 11 Operator's Manual Rivers Edge Hang-On Stands fIxED POsITION hANG-ON PARTs lIsT (RE506/RE507) KEY # DEsCRIPTION RE507 PART # RE506 PART # BOLT 5/16-18 X 1-3/4" HH BLK ZN 8655B 8655B CABLE 28" BROWN VINYL W/BLACK ENDS 48212 CABLE 26" BLACK VINYL W/BLACK ENDS 48210 BOLT 1/4-20 X 1-1/2" HH BLK ZN 48240B 48240B BOLT 1/4-20 X 1-3/4" HH BLK ZN 48250B 48250B WASHER 1/4" FLAT BLK ZN 48261B 48261B BOLT 1/4-20 X 2-1/4" HH BLK ZN 48271B 48271B NUT 1/4-20 FLANGE NYLOCK BLK ZN 48752B 48752B...
- Page 12 Operator's Manual Rivers Edge Hang-On Stands AssEMBlY INsTRuCTIONs (RE509) platform cable Tools needed – two 7/16" wrenches IMPORTAnT AssEMBLY TIP: do not tighten any nut and bolt combi- nations completely until all parts are assembled together! Finger 1/4-20 x 1-1/2" bolts tighten plus one turn of a wrench only! This will temporarily hold the locknut lock nut on the bolt while helping alignment of all parts! After all parts...
- Page 13 Operator's Manual Rivers Edge Hang-On Stands 5. Attach the (2) provided 9" camo foam pads (48736) to the armrests by wrapping around tubing and attaching Velcro together. 6. Attach seat pad (48750) to metal seat frame by sliding seat frame into seat pocket.
- Page 14 Operator's Manual Rivers Edge Hang-On Stands sET-uP AND usE INsTRuCTIONs (RE509) WARNING During installation and removal of a hang-on treestand, you must DO NOT TWIsT sTRAP WhEN ATTAChING. sEE fIGuRE always and properly use the included Full Body Harness (Fall Arrest System) with climbing belt.
- Page 15 Operator's Manual Rivers Edge Hang-On Stands fIxED POsITION hANG-ON PARTs lIsT (RE509) BIG fOOT™ xlT Model RE509 KEY # PART # DEsCRIPTION QTY. KEY # PART # DEsCRIPTION QTY. 1423B BOLT 5/16-18 X 2" HH BLK ZN SEAT FRAME 8655B BOLT 5/16-18 X 1-3/4" HH BLK ZN CXR21 PLATFORM 48089 TREE HUGGER CXR25 SEAT POST 48212...
- Page 16 Operator's Manual Rivers Edge Hang-On Stands AssEMBlY INsTRuCTIONs (RE511) Tools needed – two 7/16" wrenches IMPORTAnT AssEMBLY TIP: do not tighten any nut and bolt combina- tions completely until all parts are assembled together! Finger tighten plus one turn of a wrench only! This will temporarily hold the lock nut on the bolt while helping alignment of all parts! After all parts are assembled together, all nut and bolt combinations must be completely tightened.
- Page 17 Operator's Manual Rivers Edge Hang-On Stands sETuP AND usE INsTRuCTIONs (RE511) WARNING During installation and removal of a hang-on treestand, you must always and properly use the included Full Body Harness (Fall Arrest DO NOT TWIsT sTRAP WhEN ATTAChING. sEE fIGuRE System) with climbing belt.
- Page 18 Operator's Manual Rivers Edge Hang-On Stands fIxED POsITION hANG-ON PARTs lIsT (RE511) fIxED POsITION hANG-ON PARTs (RE511) KEY # PART # DEsCRIPTION QTY. 1423B BOLT 5/16-18 X 2 HHCS GR5 BLK ZN 48153B BOLT 1/4-20 X 2 HHCS GR5 BLK ZN 48212 CABLE- 28" BROWN VINYL 48240B BOLT 1/4-20 X 1-1/2 HHCS GR5 BLK ZN 48261B...
-
Page 19: Bolt Identification Chart
Operator's Manual Rivers Edge Hang-On Stands BOlT IDENTIfICATION ChART Not all bolt sizes shown are included with all treestands. Bolts shown are for size reference only. Extra hardware may be included in the parts bag. 5/16-18 x 1-3/4" grade 5 hex head bolt 1/4-20 x 1-1/4" grade 5 hex head bolt 5/16-18 x 2" grade 5 hex head bolt 1/4-20 x 1-1/2" grade 5 hex head bolt 5/16-18 x 2-1/4"... - Page 20 Rivers Edge® Treestands, Inc. 1160 Eighth Avenue, PO Box 755 Cumberland, WI 54829 800-450-EDGE (3343) | Fax 715-822-2124 Email: info@huntriversedge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product images may have been removed for photography purposes only.
