T2 4K Series
Digital Recorder/Players
T2 4K I/O Card Kit (SDI x8) Installation Manual
Version 3.1.0
www.grassvalley.com
F3771908011
August 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Grass Valley T2 4K Series and is the answer not in the manual?

Questions and answers

Related Manuals for Belden Grass Valley T2 4K Series

Summary of Contents for Belden Grass Valley T2 4K Series

  • Page 1 T2 4K Series Digital Recorder/Players T2 4K I/O Card Kit (SDI x8) Installation Manual Version 3.1.0 F3771908011 www.grassvalley.com August 2019...
  • Page 2 Valley, Inc., 125 Crown Point Court Grass Valley, CA, 95945 U.S.A. Trademarks and Belden, Belden Sending All The Right Signals and the Belden logo are trademarks or registered Logos trademarks of Belden Inc. or its affiliated companies in the United States and other jurisdictions.

  • Page 3: Safety Summaries

    Safety Summaries General Safety Summary Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. While using this product, you may need to access other parts of the system. Read the General Safety Summary in other system manuals for warnings and cautions related to operating the system.

  • Page 4: Safety Terms And Symbols

    Safety Summaries Battery Replacement To avoid damage, a battery must be replaced once every five years. Please contact Grass Valley Product Support to replace the battery. Safety Terms and Symbols Terms in This Manual These terms may appear in this manual: WARNING: Warning statements identify conditions or practices that can result in personal injury or loss of life.

  • Page 5: Service Safety Summary

    Service Safety Summary WARNING: The service instructions in this manual are intended for use by qualified service personnel only. To avoid personal injury, do not perform any servicing unless you are qualified to do so. Refer to all safety summaries before performing service.
  • Page 6 Safety Summaries EMC Directive Class A Warning This product must not be used in residential areas. FCC Emission Limits This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation.

  • Page 7: Required Tools

    Installation procedure of the video I/O card Precautions before operations This chapter mainly describes installation procedure of the video I/O card. Unless otherwise documented, installation procedures will be in reverse order of removals. If any installation instructions are documented, be sure to follow them. NOTE: Do not discard any of the removed parts such as screws or stays.
  • Page 8 Installation procedure of the video I/O card Disassembling the T2 4K 1. Remove the top cover (rear). (1) Remove 2 screws (with springs and large washers) on the rear side. (2) Hold the top cover (rear) with both hands to slide it out. (3) Remove the top cover (rear).
  • Page 9 Disassembling the T2 4K 2. Remove the shield gasket. 3. Disconnect following cables from the LTC/Monitor audio interface board. (1) The LTC In cable (2) The power cable of the LTC/Monitor audio interface board (3) The LTC Out/Monitor audio Out cable August 1, 2019 T2 4K I/O Card Kit (SDI x8) Installation Manual...
  • Page 10 Installation procedure of the video I/O card Installing the video I/O card 1. Remove the PCI-e slot cover. 2. Install the video I/O card. NOTE: To install the video I/O card, insert it into the PCI Express x16 slot. CAUTION: When installing the video I/O card, take care not to damage the motherboard.
  • Page 11 Installing the video I/O card 3. Reconnect three cables to the LTC/Monitor audio interface board. 4. Connect the LTC In cable to the connector of video I/O card. 5. Install a new shield gasket as before. August 1, 2019 T2 4K I/O Card Kit (SDI x8) Installation Manual...
  • Page 12 Commissioning Confirm hardware detection Confirm if the installed video I/O card is correctly detected by both Windows Device Manager and T2 Command Center software. Confirm on Windows Device Manager 1. Start the T2 in maintenance mode. 2. Open Windows Device Manager. 3.
  • Page 13 Connect equipment for commissioning Connect equipment for commissioning Connect required equipment for commissioning the T2 4K Series. NOTE: Required specification of source, monitor will be vary depending record or playback format in the workflow. NOTE: If the system works on internal sync, connecting REF signal generator is not required.
  • Page 14 Commissioning Configure I/O mode 1. Tap > > Config General Hardware 2. Tap button. Settings 3. I/O mode settings will appear. Choose I/O mode and format from the drop-down list then tap button. 4. Tap button. Configure sync mode 1. Tap >...
  • Page 15 Configure recording format Configure recording format 1. Tap > > Config Input Settings 2. Choose input format and SDI cabling mode from the drop-down list. 3. Tap button. Test video recording 1. Switch to 1ch view mode. 2. Press button. 3.
  • Page 16 Commissioning Test clip playback 4K video 1. Tap > > Config General Hardware 2. Tap button. Settings 3. I/O mode settings will appear. Choose [4K] 0 in 1 out mode and format* from the drop-down list then tap button. * Same format as step 3 in "Configure I/O mode"...
  • Page 17 Test clip playback HD/SD video 1. Tap > > Config General Hardware 2. Tap button. Settings 3. I/O mode settings will appear. Choose I/O mode depends on the workflow and format* from the drop-down list then tap button. * Same format as step 3 in "Configure I/O mode"...

  • Page 18: Initializing The Data

    Initializing the data You can initialize the database, the media drive (V: drive), and configuration. CAUTION: Current data will be lost. Backup the data beforehand. 1. In the Maintenance Tools main screen, select the tab. Data 2. Click Initialize 3. Check the items you want to initialize. - Delete the database contents.
  • Page 19 Test clip playback • - Format the media drive and initialize the folder structure. Media drive • - Initialize the configuration. Configuration • - Initialize the settings of the Customize Keyboard Shortcuts and Mouse keyboard shortcuts and mouse customization. • - Initialize the settings of Schedule Recording.
