Original ClearMirror
Installation Instructions
Fog-free Heaters for Vanity Mirrors
Models 16101-1212120H, 1414120H, 2020120H, 2030120H
and Custom Sizes
June 2018
Original ClearMirror heaters are designed to be powered by a switched circuit. A 15A or 20A
fuse or circuit breaker at the electrical box should protect the circuit. Read all instructions
before using the Original ClearMirror.
Advertisement
Table of Contents
Summary of Contents for ClearMirror 16101-1212120H
-
Page 1: Installation Instructions
June 2018 IMPORTANT INSTRUCTIONS Original ClearMirror heaters are designed to be powered by a switched circuit. A 15A or 20A fuse or circuit breaker at the electrical box should protect the circuit. Read all instructions before using the Original ClearMirror. -
Page 2: Tools Needed
WARNING: Failure to follow instructions could result in death or serious injury. NOTICE: ClearMirror height is usually 2 inches higher than the tallest user’s height. NOTICE: ClearMirror heater must be smaller than the mirror. Leave at least a 1” space from mirror edges to the heater edges. - Page 3 MEASURE FOR CLEARMIRROR INSTALLATION With mirror removed, mark junction box location on the wall where the sink’s center meets the top edge of the ClearMirror heater. Normally 2 inches higher than the tallest user as shown in Figure 1. INSTALL ELECTRICAL BOX Shut off power to the circuit where heater is to be connected at the disconnect means.
- Page 4 NOTE: Polarity is not relevant - there are neither positive nor negative connections on the ClearMirror heater pad, nor are there any ground wires CAUTION: Ensure leads are not stuck between the mirror and the wall. CONNECT LEADS TO POWER SUPPLY 1.
-
Page 5: Important Instructions
• Original ClearMirror must be properly installed before it is used. • Install Original ClearMirror over a bathroom vanity sink with wiring fed from behind the full, wall-mounted assembly. • Be certain that the controls are operational per the instructions above in that the bathroom light, ceiling fan or alternate switch power on and power off the Original ClearMirror. -
Page 6: Warranty Information
GROUNDING This Original ClearMirror heater is for use with 120 volt power supply. The cord (leads) exiting the back of the mirror assembly are 18-gauge and are not required to be grounded.
