INSTALLATION AND OPERATING MANUAL
Complete instructions for all models of evoUV
The evoUV is rated for use with pumps operating
Ensure that the unit is switched off at the mains
before you attempt to conduct any type
Evolution Aqua Ltd. - Evolution House - Kellet Close - Wigan - Lancashire - United Kingdom - WN5 0LP
t +44 (0) 1942 216554 - f +44 (0) 1942 216562 - e info@evolutionaqua.com - w www.evolutionaqua.com
30
with up to 20 metres of head.
WARNING:
of maintenance on the evoUV.
Advertisement
Table of Contents
Related Manuals for Evolution Aqua evoUV Series
Summary of Contents for Evolution Aqua evoUV Series
- Page 1 Evolution Aqua Ltd. - Evolution House - Kellet Close - Wigan - Lancashire - United Kingdom - WN5 0LP t +44 (0) 1942 216554 - f +44 (0) 1942 216562 - e info@evolutionaqua.com - w www.evolutionaqua.com...
-
Page 2: Important Safety Information
WARNING: PLEASE READ THE FOLLOWING SAFETY INFORMATION FIRST. IMPORTANT SAFETY INFORMATION - Please Read Carefully - Never look directly at an illuminated UV bulb. - Do not run this unit dry. Do not cover this unit. - Please ensure that the unit is full of water before switching it on. - Always isolate the unit from mains electricity and turn off any water supply before carrying out any maintenance. -
Page 3: Table Of Contents
INTRODUCING EVOLUTION AQUA’S evoUV Congratulations on purchasing an Evolution Aqua evoUV. Our range of evoUV pond clarifiers have been manufactured using the latest technology and design techniques. evoUVs have been designed to clear green water which is caused by single celled green algae and prevent it from returning. evoUVs will work alongside many different filtration systems but when used alongside Evolution Aqua’s pond... -
Page 4: Evouv Diagrams
evoUV DIAGRAMS INLET / OUTLET INLET / OUTLET DIMENSIONS: evo30 and evo55 including factory fitted attachments: 1000 x 185 x 115mm INLET / OUTLET INLET / OUTLET (K) (E) DIMENSIONS: evo110 including factory fitted attachments: 1000 x 260 x 115mm... -
Page 5: Evouv Parts List
evoUV COMPONENTS LIST Cross reference the components listed below, with the diagrams on the previous page. Description evo30 evo55 evo110 Control Panel Ballast Circuit Board Fuse 1½” Hosetail ----------------------------- End Cap UV Bulb Quartz Sleeve Control Panel Screw Hosetail O-Ring ----------------------------- Ballast Screw Gland Nut... -
Page 6: Flow Rates
The evo110 is an effective unit and has multiple uses. It can be used on large ponds, retail installations, Aquaculture and other commercial Aquaria installations. Please see your local Evolution Aqua dealer for details. -
Page 7: Installing Your Evouv
INSTALLING YOUR evoUV Before you do this, it is important that you familiarise yourself with the diagrams and parts list on pages 4 and 5. The two universal hosetails supplied with the evo30 and evo55, should be screwed into the inlet / outlet at either end of the unit. Hosetails are not provided with the evo110. - Page 8 POSITIONING AND MOUNTING THE evoUV IMPORTANT - Never mount the evoUV on its back. MOUNTED HORIZONTALLY PLEASE NOTE: Always leave approximately 1 metre of free space at one end of the evoUV MOUNTED for UV bulb and VERTICALLY Quartz Sleeve maintenance.
- Page 9 POSITIONING AND MOUNTING THE evoUV Pump Fed Installation POND FILTER EVOUV POND SYMBOL KEY: PUMP PUMP DIRECTION OF WATER FLOW Gravity Fed Installation WATER LEVEL POND FILTER POND EVOUV SYMBOL KEY: PUMP DIRECTION OF BALL VALVE / WATER FLOW SERVICE VALVE PLEASE NOTE: On Gravity Fed systems it is recommended to install a ball valve either side of the evoUV for maintenance.
-
Page 10: Connection To Your Pipework
CONNECTION TO YOUR PIPEWORK Connection with flexible hose (evo30 and evo55 only) The evo30 and evo55 is supplied with two universal hosetails to take 1”, 1¼”, and 1½” diameter flexible hose. If you are using one of the two larger sizes, the smaller sections of the hosetails must be cut off to ensure sufficient water flow and to prevent possible damage to the pump. -
Page 11: Connection To The Electricity Supply
CONNECTION TO THE ELECTRICITY SUPPLY Electrical installations must be done by a qualified electrician. The power supply must meet the specifications on the product. The cores in the supply cable are coloured in accordance with the following code: Brown = Live. Blue = Neutral. Earth = Green/Yellow. Do not use the supply cable to lift the evoUV as this may cause damage. -
Page 12: Commissioning And Switching On The Evouv
COMMISSIONING Before you run your evoUV, you should first check that you have installed the unit and pipework correctly. Having taken a last look at your pipework to ensure that everything looks right, switch on the circulating pump, and check for any leaks. Only after you have satisfied yourself that the evoUV is installed correctly should you switch on the electricity to the unit. -
Page 13: Multifunction Led
The usable life of Evolution Aqua’s UV bulbs is 9000 hours. The memory chip is set to remind you that the bulb has passed 8000 hours, at which point you should think about replacing the bulb. - Page 14 RESETTING THE MEMORY CHIP Below is a diagram showing how to reset the memory chip: If your finger is removed from the reset pad before the light starts flashing then the reset process has been aborted. You should repeat the reset procedure. REMOVE KEEP YOUR FINGER ON THE RESET PAD FINGER...
-
Page 15: Uv Bulb Replacement
ROUTINE MAINTENANCE UV Bulb Replacement ALWAYS ISOLATE THE UNIT FROM ANY ELECTRICITY AND WATER SUPPLIES BEFORE CARRYING OUT MAINTENANCE ON THE UNIT. To Change the Bulb: 1. Unscrew a gland nut from one end of the evoUV. This will be the end where you intend to remove the UV bulb. -
Page 16: Replacing / Cleaning The Quartz Sleeve
Replacing / Cleaning Quartz sleeve ALWAYS ISOLATE THE UNIT FROM ANY ELECTRICITY AND WATER SUPPLIES BEFORE CARRYING OUT MAINTENANCE ON THE UNIT. To Replace / Clean the Quartz Sleeve: Unscrew a gland nut from one end of the evoUV. This will be the end where you want to remove the UV bulb / quartz Sleeve. -
Page 17: In Built Protection
In Built Protection The evoUV range of pond clarifiers have thermal overload and internal fuse protection. Thermal Overload Protection - This will automatically switch off the unit should the temperature exceed the maximum operating temperature limits. Internal Fuse - This protects the electrical components in the event of a power surge. Internal Fuse Replacement All electrical work should be carried out by a qualified electrician 1. -
Page 18: Trouble Shooting And Frequently Asked Questions
TROUBLE SHOOTING AND FREQUENTLY ASKED QUESTIONS My pond water is not clear, is this due to the evoUV not working correctly? Koi, goldfish and other pond inhabitants can cause murky water by stirring up the bottom of the pond. This murky water should not be confused with suspended algae. Always check all your pond filtration is working and is being maintained correctly prior to checking the evoUV. -
Page 19: Guarantee
Evolution Aqua and its dealers shall not be held liable for any loss of fish, plants or any other livestock as a result of any failure or defect of this product. - Page 20 Evolution Aqua are the award winning pond filtration manufacturer who put innovation, research and development at the top of their agenda. With a proven track record for delivering the latest technology to the aquatics and fish farming markets - we are the first choice for everyone from the general hobbyist to the serious fishkeeper.
