Summary of Contents for Sensaphone Stratus EMS LCD
-
Page 1: Installation Guide
StratuS EMS LCD InStaLLatIon guIDE VErSIon 1.0 SENSAPHONE ® REMOTE MONITORING SOLUTIONS... - Page 2 Every effort has been made to ensure that the information in this document is complete, accurate and up-to-date. Sensaphone assumes no responsibility for the results of errors beyond its control. Sensaphone also cannot guarantee that changes in equipment made by other manufacturers, and referred to in this manual, will not affect the applicability of the information in this manual.
-
Page 3: Important Safety Instructions
• Read and follow all warning and instruction labels on the product itself. • To protect the Stratus EMS LCD from overheating, make sure all openings on the unit are not blocked. Do not place on or near a heat source, such as a radiator or heat register. -
Page 4: Year Limited Warranty
THIS LIMITED WARRANTY CONTAINS SENSAPHONE’S STANDARD TERMS AND CONDITIONS. WHERE PERMITTED BY THE APPLICABLE LAW, BY KEEPING YOUR SENSAPHONE PRODUCT BEYOND THIRTY (30) DAYS AFTER THE DATE OF DELIVERY, YOU FULLY ACCEPT THE TERMS AND CONDITIONS SET FORTH IN THIS LIMITED WARRANTY. - Page 5 ITS VALIDITY, INTERPRETATION, PERFORMANCE AND ENFORCEMENT SHALL BE GOVERNED BY AND CONSTRUED IN ACCORDANCE WITH THE LAWS OF THE STATE OF DELAWARE, WITHOUT REGARD TO THE PRINCIPLES OF CONFLICTS OF LAW. Effective date 02/25/2015 PHONETICS, INC. d.b.a. SENSAPHONE 901 Tryens Road Aston, PA 19014 Phone: 610.558.2700 Fax: 610.558.0222...
-
Page 6: Technical Support
The Stratus EMS LCD is housed in a 18.85” x 3.25” x 1.7” inch enclosure, which is 1 EIA rack-mount space high. LaYout The Stratus EMS LCD has a 10” x 1” LCD on the front. The rear panel contains a power connector and USB type A connec- tor. See figure below: ‘Stratus EMS LCD - front &... -
Page 7: Operating Environment
The Stratus EMS LCD can be rack mounted using the included rack mount screws. Follow the steps below: 1) Mount the Stratus EMS LCD in your rack using the four screws and a large Phillips screwdriver. Be sure to mount the unit close to the Stratus EMS monitoring System so that the USB cable will reach. -
Page 8: Appendix A: Specifications
Enclosure: Powder-coated aluminum enclosure for 19” rack mount rEturnIng For rEPaIr In the event that the Stratus EMS LCD does not function properly we suggest that you do the following: 1) Record your observations regarding the Stratus EMS LCD’s malfunction.
