Kestrel Tab-Tension CLR® Series
Floor Rising Ceiling/Ambient Light Rejecting (CLR®/ALR)
IMPORTANT SAFEGUARDS
Read these instructions carefully and retain them for future use. If this product is passed to a third party, then
these instructions must be included.
Caution: The screen's Black Bottom Drop is already set to its maximum drop distance. There is
NO extra Black Bottom Drop in the roller. Please be aware of this as it will void your warranty
with Elite ProAV™. Unapproved changes or modifications (except for cutting the power cord
for hardwire installations) to this unit are prohibited and will void your warranty.
• To avoid damaging the unit, do not use with any unauthorized accessories not recommended by the
manufacturer.
• Handle the unit carefully during transportation to avoid any damages.
• To ensure safe and reliable operation, direct connection to a properly grounded power source is advised.
• The power outlet supplying power to the unit should be close to the unit and easily accessible.
• Do not install the unit on uneven or inclined surfaces.
• Do not put heavy objects on the power cord and position it properly to avoid creating a trip obstacle.
• Never overload the power cord to prevent an electric shock or fire due to a loose contact or a short
circuit.
• There are not user serviceable parts in this unit. Do not attempt to disassemble this unit by yourself. No
one except authorized technicians can open and make repairs to this unit.
• Make sure the power source this unit is connected to has a continuous power flow.
• If there is need to use an extension cord, make sure the cord has an equal rating as the appliance to avoid
overheat.
• Do not handle the power plug when your hands are wet, or your feet are in contact with water.
Do not use this unit under the following circumstances.
Disconnect the power cord under the conditions of heavy rain, wind, thunder or lightning.
Avoid direct Sunshine, rain shower and moisture.
Keep away from fire sources and high temperature to prevent this device from overheating.
Cut off the power supply first before transportation or maintenance.
Fully disconnect from the power supply when the unit is not in use for a long period of time, as should
be done with any other electric household appliance.
To avoid possible injury and/or an electric shock, do not attempt to use the screen if there is obvious
damage or if there are any evident broken parts.
Keep hands clear from the closing panels.
Keep away from children when screen is in operation.
09242019JA
Tab-Tensioned Motorized Screen
User's Guide
1
www.eliteproav.com
