TouchIT LCD Duo Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
TouchIT LCD Duo

Installation Guide

TouchIT Technologies, Inc

Advertisement

loading
Need help?

Need help?

Do you have a question about the LCD Duo and is the answer not in the manual?

Questions and answers

Summary of Contents for TouchIT LCD Duo

  • Page 1: Installation Guide

    TouchIT LCD Duo Installation Guide TouchIT Technologies, Inc...
  • Page 2 Chapter 1 TouchIT LCD Inside the manual you will learn all about how to mount the TouchIT LCD Duo (and Pro) models of Interactive LCD. For more information, please visit www.touchittechnologies.com...

  • Page 3: Important Safety Instructions

    Section 1 Safety Instructions IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Please read these instructions carefully before 1. Please read these instructions carefully before using the product and keep them using the product and keep them safe for safe for later reference. future reference.
  • Page 4 7. This product should be operated from the type of power When the power cord or plug is damaged, frayed or broken. indicated on the marking label. If you are not sure of the type of In the event that liquid has been spilled into the product (except power available, consult your dealer or local service company.

  • Page 5: Chapter Contents

    Section 2 32” Wall Mount Step 1 : CHAPTER CONTENTS Wall Mounting Choose a wall appropriate for mounting. *The thickness of wall is at least 5 cm or above. *Please confirm the material and strength of the wall is appropriate for mounting. * Use the expansion bolts (B) to fix the hanging bracket (A) on the wall.
  • Page 6 Step 2 : Step 3 : Suspend the display on the hanging bracket. Mount the hanging plate (C) on the display. * Please power off the display whilst mounting. * Use screw to fix the hanging plate (C) on the display. * Two adults should hold the display.
  • Page 7 * Please check the hook from the hanging plate is attached to the hanging bracket.
  • Page 8 Section 3 42” to 55” Wall Mount Step 1 : CHAPTER CONTENTS Wall Mounting Choose a wall appropriate for mounting. *The thickness of wall is at least 5 cm or above. *Please confirm the material and strength of the wall is appropriate for mounting. * Use the expansion bolts (B) to fix the hanging bracket (A) on the wall.
  • Page 9 Step 2 : Step 3 : Suspend the display on the hanging bracket. Mount the hanging plate (C) on the display. * Please power off the display whilst mounting. Two adults should hold the display. * Use screw to fix the hanging plate (C) on the display. * Slowly lower the display on the hanging bracket.
  • Page 11 Section 4 65” to 82” Wall Mount Step 1 : CHAPTER CONTENTS Wall Mounting Choose a wall appropriate for mounting. *The thickness of wall is at least 5 cm or above. *Please confirm the material and strength of the wall is appropriate for mounting. * Use the expansion bolts (B) to fix the hanging bracket (A) on the wall.
  • Page 12 Step 3 : Suspend the display on the hanging bracket. * Two adults should hold the display. * Slowly lower the display on the hanging bracket. * Please check the hook from the hanging plate is attached to the hanging bracket. Step 2 : Mount the hanging plate (C) on the display.
  • Page 13 Section 5 32” Table Top Stand Step 1：Open the package and take out the stand. CHAPTER CONTENTS Table Top Stand Check the parts and the quantities, please see the picture below. 1、32” Stand，1PCS 2、Screw M6*L10mm，6PCS...
  • Page 14 Step 2：Mounting the display（A） on the stand. *Use screw（B） to fix the display on the stand（C）.
  • Page 15 Section 6 42” Table Top Stand Step 1：Open the package and take out the stand. CHAPTER CONTENTS Table Top Stand Check the parts and the quantities, please see the picture below. 1、32” Stand，1PCS 2、Screw M6*L10mm，6PCS...
  • Page 16 3、Screw M6*L30mm，4PCS Step 3：Insert the stand into the rectangular holes under the stand holder as shown in the picture below. 4、Stand holder(*)，1PCS Step 2：Use screw size M6*L10mm to fix the stand holder(*) on the display. (*)Stand holder: The part is optional and comes with the stand which is sold separately.
  • Page 17 Step 4：Use screw sized M6*L30mm to fix the display on the stand as below picture.
  • Page 18 Section 7 46” Table Top Stand Step 1：Open the package and take out the stand. CHAPTER CONTENTS Table Top Stand Check the parts and the quantities, please see the picture below. 1、Stand，1PCS...
  • Page 19 Step 2：Remove the two screws on the rear side of the display Step 4：. Use screws to fix the display on the stand as shown in as shown in the picture below. the picture below. Step 3：Insert the stand into the rectangular holes under the monitor as shown in the picture below.
  • Page 20 Section 8 55” Table Top Stand Step 1：Open the package and take out the stand. CHAPTER CONTENTS Table Top Stand Check the parts and the quantities, please see the picture below. 1、32” Stand，1PCS 2、Screw M6*L10mm，6PCS...
  • Page 21 Step 2：Mounting the display（A） on the stand. *Use screw（B） to fix the display on the stand（C）.
  • Page 22 Section 9 65” to 70” Table Top Stand Step 1：Open the package and take out the stand. CHAPTER CONTENTS Table Top Stand Check the parts and the quantities, please see the picture below. 1、Stand，1PCS 2、Screw M4*L8mm，2PCS...
  • Page 23 Step 2：Insert the stand（A） into the rectangular holes that are Step 3：Use screw（C） to fix the display on the stand（A）. under the monitor（B）.
