Summary of Contents for Zero 8
- Page 1 USER MANUAL...
- Page 2 inside of front cover (empty) DO NOT PRINT...
- Page 3 Welcome to a life of ZERO emissions and total freedom...
-
Page 4: Table Of Contents
Getting Started ZERO 8 ZERO 9 ZERO 10 ZERO 10X Instructions For Battery Usage Safety Care & Maintenance Limited Warranty... -
Page 5: Getting Started
Getting Started Basic operation: Press power button for 3 seconds to turn on scooter. The scooter turns off Power On/Off automatically if not used for 90 seconds. Speed Control While stationary, and with the power on, press and release the MODE button to cycle through the three different speed levels 1 to 3. - Page 7 ZERO 8 Technical Specifications Model ZERO 8 Battery 48V 10.4Ah / 48V 16Ah / 52V 13Ah Tyre 8 inch, pneumatic front, solid rear rubber Brakes Single rear drum brake Range* ~35 km / ~55 km / ~50 km Top Speed (Limited to)
- Page 8 ZERO 8: Unfolding Lift folding lever to unlock steering column While holding lever up, unfold steering column Loosen quick Tighten quick-release -release clamp and clamp to secure T-bar extend T-bar...
- Page 9 ZERO 8: Folding Step 1: Step 2: Step 3: Turn power on Slide locking sleeves Fold down handle grips outward to release grips Step 6: Step 4: Step 5: Lift the folding lever and push the Open the quick-release clamp...
- Page 11 ZERO 9:Technical Specifications Model ZERO 9 Battery 48V 13Ah Tyre 9 inch pneumatic front & rear Brakes Single rear drum brake Range* ~45 km Top Speed (Limited to) 40 km/h (25 km/h) Weight 18 kg Suspension Front spring & rear hydraulic suspension...
- Page 12 ZERO 9: Unfolding Press down folding lever to Unfold steering column until it unlock steering column locks in vertical position Loosen quick -release Tighten quick-release clamp and extend T-bar clamp to secure T-bar...
- Page 13 ZERO 9: Folding Step 1: Step 2: Step 3: Turn power on Slide locking sleeves Fold down handle grips outward to release grips Step 6: Step 4: Step 5: (A) While pressing down on the folding Open the quick-release clamp...
- Page 15 ZERO 10:Technical Specifications Model ZERO 10 Battery 52V 7Ah / 52V 21Ah Tyre 10 inch pneumatic front & rear Brakes Dual disc brake Range* ~25 km / ~65 km Top Speed (Limited to) 48km/h (25km/h) Weight 20kg / 24kg Suspension Front spring &...
- Page 16 ZERO 10: Unfolding Press down folding lever to Unfold steering column until it unlock steering column locks in vertical position Loosen quick -release Tighten quick-release clamp and extend T-bar clamp to secure T-bar...
- Page 17 ZERO 10: Folding Step 1: Step 2: Step 3: Turn power on Slide locking sleeves Fold down handle grips outward to release grips Step 6: Step 4: Step 5: (A) While pressing down on the folding Open the quick-release clamp...
-
Page 19: Zero 10X
ZERO 10X: Technical Specifications Model ZERO 10X Battery 52V 18.2Ah / 52V 23.8Ah Tyre 10 inch pneumatic front & rear Brakes Dual disc brake Range* 60 - 70 km / 85 - 90 km Top Speed (Limited to) 65 km/h (25km/h) - Page 20 ZERO 10X: Unfolding Unfold steering column Unlock the clamp Secure the clamp...
- Page 21 ZERO 10X: Folding Turn power off Unlock the clamp Fold down Secure steering column the clamp...
-
Page 22: Instructions For Battery Usage
Instructions for battery usage First Charge It is important to fully charge the battery before your first use of the scooter. Features of the battery Your scooter’s battery comes with these built-in features: 1. Balanced charging protection: During charging, the battery automatically balances the voltage among the internal cells to protect each cell. -
Page 23: Safety
7. Do not ride on rainy days. 8. Slow down on slopes; do not ride on slopes of steeper than 15 degrees in gradient. 9. Before riding, always do a visual inspection to check that all nuts and bolts are secure; that there is enough tyre pressure and the tyres are not worn out;... -
Page 24: Care & Maintenance
Care & Maintenance Cleaning & Storage Before cleaning, be sure to turn off the scooter and disconnect it from the wall electrical outlet. Close the charging port to reduce chances of water entering it, causing damage or electric shock. Remove dirt or dust with a damp cloth. For stubborn dirt, scrub with a toothbush and wipe clean with a damp cloth. - Page 25 Care & Maintenance IMPORTANT Always recharge the battery before it is fully depleted. Over-discharging shortens the lifespan of the battery. Battery range is reduced at low temperatures. For example, at -20 ° C, the battery range may be less than half that at normal temperature. If the battery is not charged for a long time, it may no longer be usable.
-
Page 26: Limited Warranty
Limited Warranty BY USING THIS PRODUCT YOU AGREE TO THIS LIMITED WARRANTY. PLEASE READ THIS LIMITED WARRANTY CAREFULLY. To benefit from the limited warranty, the customer is advised to read Falcon PEV Pte Ltd (“Falcon”) Limited Warranty terms together with the “care and maintenance” sections provided in the user manual. This limited warranty applies to the extent permitted by law and unless restricted or prohibited by law. - Page 27 Limited Warranty 5. This Limited Warranty will only be effective when presented together, to either Falcon or its authorised centres, with proof of date and place of purchase of Products such as the purchase receipt. What this Limited Warranty does not cover: 1.
- Page 28 Limited Warranty 4. The customer is advised to take the following precautions: a. Do not ride on wet ground or in heavy rain; b. Take corners slowly and look out for pedestrians; c. Avoid potholes, kerbs and debris on the ground; d.
- Page 29 Notes...
- Page 30 Notes...
- Page 31 inside of back cover (empty) DO NOT PRINT...
- Page 32 Worldwide distribution by Falcon PEV Pte Ltd 2 Alexandra Road, #06-06 Delta House, Singapore 159919 www.FalconPEV.com.sg...
