Operating Instructions
SPECIFICATIONS
Capacity. . . . . . . . 3/32", 1/8", 5/32", 3/16"
Air Pressure . . . . . . . . . . . . . . . .60-90 PSI
Average Air consumption . . . . . . 4 CFM
Air Inlet . . . . . . . . . . . . . . . . . . . . 1/4" NPT
Hose Size . . . . . . . . . . . . . . . . . . . 3/8" I.D.
Includes 2 Wrenches and Safety Cap
WARNING
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
ALWAYS WEAR
HEARING
PROTECTION
AVOID PROLONGED
EXPOSURE TO
VIBRATION
3/16" Air Hydraulic Rivet Gun
Warning Information
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
WARNING
Copyright © Professional Tool Products, 2018
SE200
Parts Breakdown
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE200 and is the answer not in the manual?

Questions and answers

Related Manuals for Silver Eagle SE200

Summary of Contents for Silver Eagle SE200

  • Page 1 SE200 3/16" Air Hydraulic Rivet Gun Operating Instructions Warning Information Parts Breakdown SPECIFICATIONS Capacity..3/32", 1/8", 5/32", 3/16" Air Pressure ....60-90 PSI Average Air consumption .
  • Page 2 SE200 3/16" Air Hydraulic Rivet Gun WARNING FAILURE TO OBSERVE THESE WARNINGS COULD RESULT IN INJURY THIS INSTRUCTION MANUAL CONTAINS • Place the tool on the work before starting the tool. Do not point or indulge in any horseplay with this tool.

  • Page 3: Air Supply

    SE200 3/16" Air Hydraulic Rivet Gun AIR SUPPLY by cleaning the air strainer and flushing out the tool with gum solvent oil or an equal mixture of SAE #10 and kerosene. If outside Tools operate on a wide range of air pressures. It is recommended...
  • Page 4 SE200 3/16" Air Hydraulic Rivet Gun 12 14 30-1 30-2 35 Spanner Gauge 30-3 15 Frame SE200 09/20/18...

  • Page 5: Warranty

    WARRANTY This warranty gives you specific rights. You may also have other rights Silver Eagle™ by Matco warrants its air tools for a period of 1 year to the which vary from state to state. consumer. We will repair any SE Series air tool covered under this warranty The foregoing obligation is Matco’s sole liability under this or any implied...

  • Page 6: Especificaciones

    SE200 Pistola Neumática Para Remaches 3/16” Instrucciones de Operación Información de Advertencia Revisión de Refacciones ESPECIFICACIONES Capacidad ..3/32”, 1/8”, 5/32”, 3/16” Presión de aire ....60-90 PSI Consumo promedio de aire .
  • Page 7 SE200 Pistola Neumática Para Remaches 3/16” EL INCUMPLIMIENTO DE OBSERVAR ESTAS ADVERTENCIAS PUEDEN RESULTAR EN ALGUNA LESIÓN lesión seria o la muerte. Sea consciente de la manguera ESTE MANUAL INSTRUCCIONES CONTIENE excedente, dejada por la superficie para caminar INFORMACIÓN IMPORTANTE DE SEGURIDAD.

  • Page 8: Diagnóstico De Averías

    SE200 Pistola Neumática Para Remaches 3/16” ALIMENTACIÓN DE AIRE LUBRICACIÓN Y MANTENIMIENTO Lubrique el motor neumático diariamente con un aceite para Las herramientas operan en un rango amplio de presiones de herramientas neumáticas de alta calidad. Si no se usa ningún aire.
  • Page 9 SE200 Pistola Neumática Para Remaches 3/16” Diagnóstico de averías para la cabeza de la matraca neumática 1. Asegúrese de que no haya ningún flujo de aire yendo hacia la matraca neumática 2. Use la llave inglesa para quitar la cabeza del armazón. (Fig. 1) 3.

  • Page 10: Spécifications

    SE200 Riveteuse Pneumatique 3/16” Instructions de fonctionnement Avertissement Pièces SPÉCIFICATIONS Capacité ..3/32”, 1/8”, 5/32”, 3/16” Pression d’air ....60-90 PSI Consommation d’air moyenne. . . 4 CFM Entrée d’air .
  • Page 11 SE200 Riveteuse Pneumatique 3/16” AVERTISSEMENT LE MANQUE D'OBSERVER CES AVERTISSEMENTS PEUT CAUSER DES BLESSURES de l’utilisation d’outils pneumatiques peut causer de GUIDE D’UTILISATION RENFERME sérieuses blessures ou la mort. Prenez garde aux D’IMPORTANTES CONSIGNES DE SÉCURITÉ. boyaux qui traînent par terre dans l’aire de travail.

  • Page 12: Alimentation En Air

    SE200 Riveteuse Pneumatique 3/16” ALIMENTATION EN AIR LUBRIFICATION ET D'ENTRETIEN Cet outil peut fonctionner à l’intérieur d’une large plage de Lubrifier le moteur pneumatique chaque jour avec de l’huile à pression d’air. Il est recommandé que la pression soit de 90 outil pneumatique de qualité.

  • Page 13: Garantie

    SE200 Riveteuse Pneumatique 3/16” Dépannage pour la tête de la riveteuse 1. Assurez-vous qu’il n’y a aucune circulation d’air allant à la riveteuse. 2. Utilisez la clé pour retirer la tête de l’armature. (Fig. 1) 3. Utilisez la clé pour enlever le logement de mâchoire, les mâchoires, le pousseur de mâchoire et le ressort du pousseur. (Fig. 2) 4.
