- Page 1 Expert PDU energy 8001 The Energy Meter for IT environments Manual...
- Page 2 Manual Expert PDU energy 8001 © 2008 Gude Analog- und Digitalsysteme Rev. 1.1...
-
Page 3: Table Of Contents
3.3 Confi guration by using the Webinterface 3.4 IP Access Control List 3.5 SNMP 3.6 Syslog 4. Operating 4.1 Operating at the device 4.2 Controling Expert PDU energy 8001 by webinterface 5. Product Features 5.1 Bootloader mode 5.2 Firmware update 5.3 Technical information 5.4. -
Page 4: Security Advise
Please recycle the packaging materials. In case of further questions, about installation, operation or usa- ge of the device, which are not clear after reading the manual, please do not hesitate to ask our support team. Expert PDU energy 8001... -
Page 5: Description
1. Description Expert PDU energy 8001 is a 19“ device, that makes it possible to measure energy consumption for two channels. It operates as an energy consumption meter and measures cur- rent, voltage and active/apparent power. All of these information can be requested by Ethernet or directly at the device. -
Page 6: Hardware
Power Connector Expert PDU energy 8001. Your Expert PDU energy 8001 is now booting and shortly after ready for being connected to consumers and the Ethernet. 2.) Plug the Ethernet cable into the connector on the front side 2.) Plug the Ethernet cable into the connector on the front side 2.) Plug the Ethernet cable into the connector... -
Page 7: Lcd-Panel
2.3 LCD-Panel While booting up the device, the product name, the version of the fi rmware and the IP address of Expert PDU energy 8001 are visible: - Product name (A) and version of the fi rmware (B) - IP address (B) of Expert PDU energy 8001... -
Page 8: Confi Guration
IP address from this server. Please check at your DHCP server, which IP address was pro- vided to Expert PDU energy 8001 and make sure, that this IP address will be reserved. 3.2 Confi guration by using Gbl_Conf.exe To change the TCP/IP settings of your Expert PDU energy 8001 you need the tool Gbl_Conf.exe. -
Page 9: Confi Guration By Using The Webinterface
3.3 Confi guration by using the Webinterface Open your Browser. Enter the IP address of Expert PDU en- ergy 8001, to connect with it: http://“IP-Address of Expert PDU energy 8001“/ Figure 4 Log in and Login. To enter the confi guration menu, click on „Confi guration“ on the upper left side of the screen. - Page 10 8001. Use DHCP Here you can set, if Expert PDU energy 8001 shall get its TCP/IP settings directly from your DHCP server. If DHCP is activated, Ex- pert PDU energy 8001 proves if a DHCP server is active inside of your LAN.
- Page 11 Control List (IP ACL) of Expert PDU energy 8001. If you locked yourself out by mis- take, please activate the bootloader mode of Expert PDU energy 8001, Figure 7 Confi guration IP ACL start Gbl_Conf.exe and deactivate IP ACL.
- Page 12 Here you can enter the HTTP port number, if necessary. Pos- sible numbers are 1 ... 65534 (standard: 80). To get access to Expert PDU energy 8001, you have to enter the port number behind the IP address of Expert PDU energy 8001: http://192.168.0.2:1720/...
- Page 13 Figure 9 Confi guration - SNMP Download SNMP-MIB Here you can download the MIB of Expert PDU energy 8001. Use SNMP only if your network is fi tted for. More information about the SNMP functions of Expert PDU energy 8001, you can fi nd in chapter 3.6, on http://www.gude.info/wiki or ask...
-
Page 14: Ip Access Control List
IP Access Control List (IP ACL) acts as an IP fi lter for Expert PDU energy 8001. Wether it is active hosts and subnets only can contact Expert PDU energy 8001, if their IP adresses are stated in this IP ACL. -
Page 15: Syslog
UDP. Linux OS regularly have a syslog daemon installed, e.g. sys- log-ng. For Windows there are some freeware tools available. On following events, Expert PDU energy 8001 will send a sys- log message: - Booting up - Switching off... -
Page 16: Operating
„ok“. (see Figure 11) ok“. (see Figure 11) Figure 11 Menu Expert PDU energy 8001... -
Page 17: Controling Expert Pdu Energy 8001 By Webinterface
4.2 Controling Expert PDU energy 8001 by webinterface Open your Browser. Enter the IP address of Expert PDU en- ergy 8001, to connect with it: http://“IP-Address of Expert PDU energy 8001“/ Figure 12 Login and Login. Expert PDU energy 8001 - Status... -
Page 18: Product Features
„ok“ again simultaneously for three seconds. ok“ again simultaneously for three seconds. 5.2 Firmware update To update the fi rmware of Expert PDU energy 8001, you need the software tool Gbl_Conf.exe and an up-to-date version of the fi rmware. -
Page 19: Technical Information
Then click on Program Device Reset to Fab default. Please notice that all current settings will be deleted. The default settings will be loaded when Expert PDU energy 8001’s boot- loader mode is deactivated. Default Settings Expert PDU energy 8001... -
Page 20: Support
More information, current drivers and software can be found on http://www.gude.info. In case of further questions, about installation or opera- tion of Expert PDU energy 8001, please have a look at www.gude.info/wiki and do not hesitate to contact our support Expert PDU energy 8001... -
Page 21: Declaration Of Ce Conformity
Declaration of Conformity Konformitätserklärung / / The manufacturer Die Firma Gude Analog- und Digitalsysteme GmbH --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Address Anschrift/ Eintrachtstr. 113, 50668 Köln Phone Telefon/ 0221 – 912 90 97 Fax: 0221 – 912 90 98 Web: www.gude.info Mail: mail@gude.info / hereby declares that the following products erklärt hiermit, dass die Produkte... -
Page 22: Contact
Contact Gude Analog- und Digitalsysteme GmbH Eintrachtstrasse 113 50668 Koeln Tel.: +49-221-912 90 97 Fax: +49-221-912 90 98 E-Mail: info@Gude.info Web: www.Gude.info...
