USE AND OPERATING
INSTRUCTIONS FOR THE
VAPORTRONIC 2.0
Vaportronic 2.0
Refillable, Electronic
Wall Cabinet System
May be used free-standing
or wall-mounted.
WALL-MOUNTING INSTRUCTIONS
1. Position Vaportronic 2.0 on wall where unit is to be mounted &
mark top of unit. Allow at least 3" clearance above unit for
hinged cover to lift open.
2. Measure 1.25" down from mark & drill top mounting hole using
3/16" drill bit.
3. Insert supplied anchor into hole & insert supplied screw into
anchor leaving a 1/8" protrusion.
4. Using supplied Allen wrench, open unit by removing bottom
screw. Open cover & hang unit on top mounting screw.
5. Mark bottom hole using hang hole in back panel, remove unit,
& drill bottom mounting hole using 3/16" drill bit. Insert
supplied anchor into hole.
6. Hang unit on top mounting screw & align with bottom
mounting hole. Insert supplied screw into anchor & securely
tighten.
7. Insert 2 AA batteries.
DEODORIZING ELEMENT INSTRUCTIONS
1. Open protective bag containing EZ-Disk by tearing at notch.
Gently press EZ-Disk down & back into slot(s) to prevent
element interference with fan.
2. Install 1-5 EZ-Disks depending on your cubic footage needs.
Each EZ-Disk treats 2,000 ft
3. Ensure slide switch is turned ON & adjusted to desired setting.
Use setting 1 when maximum dry vapor output is required.
4. Close lid & reinsert bottom screw using Allen wrench.
5. Wash hands with soap & water to remove any residue
from handling EZ-Disks.
0 - 0FF
Setting 1 - One minute ON, 5 minutes OFF
Setting 2 - One minute ON, 10 minutes OFF
Setting 3 - One minute ON, 15 minutes OFF
™
