P V Otoscope
Specula, Focusing and leaning
Instructions
ttaching and removing
ear specula:
To equip the otoscope head,
single-use ear speculum, turn the
speculum clockwise until you can
feel a resistance.
To remove the speculum, twist
off the speculum by turning it
counterclockwise.

Focusing wheel:

The focusing wheel enables you to
adjust the focusing range in the
auditory canal (tympanic membrane).
The adjustment wheel moves up and
down to focus the lens.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PMV Otoscope and is the answer not in the manual?

Questions and answers

Summary of Contents for diagnostix PMV Otoscope

  • Page 1 P V Otoscope Specula, Focusing and leaning Instructions ttaching and removing ear specula: To equip the otoscope head, single-use ear speculum, turn the speculum clockwise until you can feel a resistance. To remove the speculum, twist off the speculum by turning it counterclockwise.
  • Page 2 P V Otoscope Cleaning and disinfection The instrument head with handle can be cleaned externally with a moist cloth until visually clean. Wipe disin- fection as specified by the disinfectant manufacturer. Only disinfectants with proven efficacy should be used, taking into account the national requirements.
