- Page 1 Network Turret Camera Quick Start Guide UD04378B Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 2 Network Turret Camera·Quick Start Guide Quick Start Guide COPYRIGHT © 2017 Hangzhou Hikvision Digital Technology Co., Ltd. ALL RIGHTS RESERVED. Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of...
- Page 3 Network Turret Camera·Quick Start Guide Legal Disclaimer TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS, AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY.
-
Page 4: Regulatory Information
Network Turret Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. - Page 5 Network Turret Camera·Quick Start Guide This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 6: Safety Instruction
Network Turret Camera·Quick Start Guide Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. - Page 7 Network Turret Camera·Quick Start Guide ● Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 12 VDC according to the IEC60950-1 standard. Please refer to technical specifications for detailed information. ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard.
- Page 8 Network Turret Camera·Quick Start Guide ● The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam. ● Do not place the camera in extremely hot, cold (the operating temperature shall be-30°C ~+60°C, or -40°C ~ +60°C if the camera model has an “H”...
-
Page 9: Table Of Contents
Network Turret Camera·Quick Start Guide Table of Contents 1 Appearance Description ............... 10 1.1 Type I ................10 1.2 Type II ................11 1.3 Type III ................12 1.4 Type IV ................13 2 Installation..................15 2.1 Ceiling Mounting............15 2.1.1 Type I.............. -
Page 10: Available From A1 Security Cameras
Network Turret Camera·Quick Start Guide 5.2 Hik-Connect Setup ............51 5.3 Adding Camera to Hik-Connect ........51 5.4 Initializing the Memory Card ......... 53 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 11: Appearance Description
Network Turret Camera·Quick Start Guide 1 Appearance Description This camera series of turret camera has four appearance types. Type I Figure 1-1 Overview of Type I Turret Camera Table 1-1 Description Description Description Trim Ring Camera Enclosure Power Cord 10M/100M self-adaptive Mounting Base Ethernet interface Available from A1 Security Cameras... -
Page 12: Type Ii
Network Turret Camera·Quick Start Guide Type II Figure 1-2 Overview of Type II Turret Camera Table 1-2 Description Description Description Trim Ring Camera Enclosure Power Cord 10M/100M self-adaptive Mounting Base Ethernet interface Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 13: Type Iii
Network Turret Camera·Quick Start Guide Type III Overview of Type III Turret Camera Table 1-3 Description Description Description Audio Output Trim Ring 1-ch Alarm Input and Enclosure 1-ch Alarm Output RST (Reset) Button Mounting Base Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 14: Description No
Network Turret Camera·Quick Start Guide Description Description Memory Card Slot Camera Power Cord 10M/100M self-adaptive Ethernet interface Note: Press Reset button about 10s when the camera is power on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. -
Page 15: Type Iv
Network Turret Camera·Quick Start Guide Table 1-4 Description Description Description Trim Ring Power Cord 10M/100M self-adaptive Enclosure Ethernet interface (PoE) RST (Reset) Button Mounting Base Memory Card Slot Camera Notes: ● For this type IV camera, the layout of memory card slot and reset button may be different from model to model. -
Page 16: Installation
Network Turret Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12 VDC, please make sure your power supply matches with your camera. - Page 17 Network Turret Camera·Quick Start Guide Rotate the trim ring anticlockwise to take it off from the camera. Separate the camera and the enclosure. ③ Trim Ring ② Camera Lock Screw ① Mounting Base Figure 2-1 Disassemble the Camera Drill the screw holes and the cable hole on the ceiling according to the drill template.
- Page 18 Network Turret Camera·Quick Start Guide There are two cable outlet methods. One is to route the cables through the cable hole, and the other is to route the cables through the side outlet shown below. Figure 2-3 Side Outlet Three side outlets on the enclosure are selectable, which makes routing the cables easier instead of drilling a cable hole on the ceiling.
- Page 19 Network Turret Camera·Quick Start Guide Ceiling Figure 2-4 Secure the Mounting to the Ceiling 4. Connect the corresponding power/network cable and then install the camera to the mounting base with the supplied screws. Rotate the camera to secure it. Figure 2-5 Secure the Camera to the Mounting Base 5. Adjust the Lens.
- Page 20 Network Turret Camera·Quick Start Guide Lock Screw Figure 2-6 Loosen Lock Screw 2). Rotate the enclosure to adjust the pan angle; rotate the camera to adjust the tilt angle. P Direction T Direction R Direction ~ 75 Figure 2-7 Adjust the Lens 3).
-
Page 21: Type Ii
Network Turret Camera·Quick Start Guide Trim Ring Figure 2-8 Install the Trim Ring 2.1.2 Type II Steps: 1. Disassemble the camera. Rotate the enclosure anticlockwise to take it off from the camera. Separate the camera, the mounting base, and the trim ring. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 22 Network Turret Camera·Quick Start Guide ② Trim Ring ① Camera Mounting Base Figure 2-9 Disassemble the Camera Drill the screw holes and the cable hole on the ceiling according to the drill template. Figure 2-10 The Drill Template There are two cable outlet methods. One is to route the cables through the cable hole, and the other is to route the cables through the side outlet shown below.
- Page 23 Network Turret Camera·Quick Start Guide Figure 2-11 Side Outlet Three side outlets on the enclosure are selectable, which makes routing the cables easier instead of drilling a cable hole on the ceiling. Use a plier to remove the plastic and route the cables through the hole.
- Page 24 Network Turret Camera·Quick Start Guide Connect the corresponding power/network cable. Install the camera along with the enclosure to the mounting base by anticlockwise rotating the camera. Rotate the enclosure to adjust the pan angle; rotate the camera to adjust the tilt angle. P Direction T Direction R Direction...
-
Page 25: Type Iii
Network Turret Camera·Quick Start Guide 2.1.3 Type III Steps: 1. Disassemble the camera. Rotate the trim ring anticlockwise to take it off from the camera. Rotate the mounting base anticlockwise to take it off from the camera. Separate the camera and the enclosure. Trim Ring ①... - Page 26 Network Turret Camera·Quick Start Guide Take off the cover and insert the microSD card into the card slot. microSD Card Figure 2-17 Memory Card Slot Place the cover back. 3. Stick the drill template on the installation place and drill the screw holes and the cable hole on the ceiling according to the drill template.
- Page 27 Network Turret Camera·Quick Start Guide Figure 2-19 5. Connect the corresponding power/network cable. Refer to the section 2.3 for the water-proof accessory installation if the camera is installed in the outdoor. 6. Install the camera along with the enclosure to the mounting base by anticlockwise rotating the camera.
-
Page 28: Type Iv
Network Turret Camera·Quick Start Guide 360° P Direction 0° to 75° 360° T Direction R Direction Figure 2-21 Adjust the Lens 8. Attach the trim ring to the camera and rotate the trim ring clockwise to get it secured. Trim Ring Install the Trim Ring Figure 2-22 2.1.4 Type IV... - Page 29 Network Turret Camera·Quick Start Guide Loosen the fixing screw. Take the mounting base off from the camera and the enclosure. Separate the camera and the enclosure. ① ③ Fixing Screw ② Figure 2-23 Disassemble the Camera 2. Install memory card. Unscrew the memory card slot cover.
- Page 30 Network Turret Camera·Quick Start Guide Screw the memory card slot cover back. 3. Paste the drill template to desired mounting place. 4. Drill the screw holes (for expansion screws) and the cable hole on the ceiling according to the drill template. Note: If the camera is installed to a wooden wall, use self-tapping screws instead of expansion screws.
- Page 31 Network Turret Camera·Quick Start Guide Drill Template Mounting Base Figure 2-26 Fix Mounting Base 6. Connect the corresponding power/network cable. Refer to the section 2.3 for the water-proof accessory installation if the camera is installed in the outdoor. 7. Install the camera along with the enclosure to the mounting base.
-
Page 32: Mounting With Brackets
Network Turret Camera·Quick Start Guide Pan: 0° to 360° Rotate: Tilt: 0° to 360° 0° to 75° Figure 2-28 Adjust Surveillance Angle 9. Attach the trim ring to the camera and rotate the trim ring clockwise to get it secured. Install Trim Ring Figure 2-29 Mounting with Brackets... -
Page 33: Wall Mounting
Network Turret Camera·Quick Start Guide 2.2.1 Wall Mounting The wall mount is not included in the package. You need to prepare one, if you adopt this mounting type. Steps: Mark the screw holes on desired mounting place. Dimension of Demonstrated Wall Mounting Bracket Figure 2-30 2. Drill four screw holes with a Φ10 mm drill. - Page 34 Network Turret Camera·Quick Start Guide Mounting Base Fix Mounting Base Figure 2-31 Connect the corresponding power/network cable. Refer to the section 2.3 for the water-proof accessory installation if the camera is installed in the outdoor. Install the camera and the enclosure to the mounting base, adjust the surveillance angle, and fix the trim ring.
-
Page 35: Pendant Mounting
Network Turret Camera·Quick Start Guide 2.2.2 Pendant Mounting The pendant mounting bracket is not included in the package. You need to prepare one in advance, if you adopt this mounting type. Steps: Mark the screw holes on desired mounting place. Drill three screw holes for expansion bolts. -
Page 36: Mounting Base
Network Turret Camera·Quick Start Guide Mounting Base Fix Mounting Base Figure 2-34 6. Screw the cap to the pendant mount. Pendant Mount Install the Cap Figure 2-35 7. Connect the corresponding power/network cable. Refer to the section 2.3 for the water-proof accessory installation if the camera is installed in the outdoor. -
Page 37: Network Cable Water-Proof Accessory Installation
Network Turret Camera·Quick Start Guide Install the camera and the enclosure to the mounting base, adjust the surveillance angle, and fix the trim ring. Refer to corresponding steps in ceiling mounting of each camera type. Pendant Mounting Figure 2-36 Network Cable Water-proof Accessory Installation Purpose: If the camera is installed outdoor, you can adapt the water-proof... - Page 38 Network Turret Camera·Quick Start Guide ① ② ③ ④ ⑤ ⑥ ⑦ Figure 2-37 Water-proof Accessory Components Components Table 2-1 Components Camera’s Network Interface Socket O-Type Gasket Network Plug Waterproof Endcap Waterproof Rubber Gasket Lock Nut Network Cable from Router/Switch Steps: 1. Feed the plugless network cable ⑦...
- Page 39 Network Turret Camera·Quick Start Guide 3. Place the O-type gasket ② onto the end of the camera’s network interface socket ①. 4. Insert the network plug ③ into the camera’s network interface socket①. 5. Insert the water-proof rubber gasket ⑤ into the waterproof endcap ④, and secure lock nut ⑥...
-
Page 40: Setting The Network Camera Over The Lan
Network Turret Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. -
Page 41: Activating The Camera
Network Turret Camera·Quick Start Guide 3.2 Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. -
Page 42: Activation Via Sadp Software
Network Turret Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. - Page 43 Network Turret Camera·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera. Steps: 1. Run the SADP software to search the online devices. 2.
-
Page 44: Modifying The Ip Address
Network Turret Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. - Page 45 Network Turret Camera·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an active device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-5 Modify the IP Address Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 46 Network Turret Camera·Quick Start Guide Note: You can enable the Hik-Connect service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP. Refer to the user manual of SADP for details.
-
Page 47: Accessing Via Web Browser
Network Turret Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:... - Page 48 Network Turret Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
-
Page 49: Operating Via Hik-Connect App
Network Turret Camera·Quick Start Guide 5 Operating via Hik-Connect App Purpose: Hik-Connect is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so Note: Hik-Connect service is not supported by certain camera models. Enable Hik-Connect Service on Camera Purpose: Hik-Connect service should be enabled on your camera before using... -
Page 50: Enable Hik-Connect Service Via Web Browser
Network Turret Camera·Quick Start Guide Figure 5-1 Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Hik-Connect app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Hik-Connect Service via Web Browser Before you start: You need to activate the camera before enabling the service. - Page 51 Network Turret Camera·Quick Start Guide Steps: 1. Access the camera via web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Figure 5-2 Platform Access Configuration (Web) 3. Select Platform Access Mode as Hik-Connect. 4.
-
Page 52: Hik-Connect Setup
Network Turret Camera·Quick Start Guide Hik-Connect Setup Steps: 1. Download and install the Hik-Connect app by searching “Hik-Connect” in !pp Store or Google Play 2. Launch the app and register for a Hik-Connect user account. 3. Log in Hik-Connect app after registration. Adding Camera to Hik-Connect Before you start: You need to enable the Hik-Connect service on camera before... - Page 53 Network Turret Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.
-
Page 54: Initializing The Memory Card
Network Turret Camera·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection. - Page 55 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
