Endon Burford Bollard Instruction Manual

Safety Warnings

• It is recommended that this light be installed by a qualified electrician in accordance with current IEE Wir-
ing Regulations and Building Regulations ( Part P ).
• This product is only suitable for connection to a 240v~50Hz supply and is for outdoor use.
• Run supply wire from a 5-amp electrical supply using double insulated 2 or 3-core cable of type H05RN-
F 1.0mm2 (not supplied) to selected site, ensuring it is adequately protected through the full length of the
cable run, it must come out of the flat surface of the wall in line with the entry to the fitting
• This fitting is a Class I product, and must be connected to Earth.
• Switch off the mains supply and remove the appropriate fuse or switch off the appropriate circuit breaker
before commencing installation.
• Except where installed in a conduit or duct which provides equivalent protection against mechanical dam-
age, a cable buried in the ground shall incorporate an earthed armour or metal sheath or both, suitable for
use as a protective conductor, or be of insulated concentric construction. Buried cables shall be marked
by cable covers or a suitable marking tape. Buried conduits and ducts shall be suitably identified. Buried
cables, conduits and ducts shall be at a sufficient depth to avoid being damaged by any reasonably fore-
seeable disturbance of the ground.
• Do not install a bulb with a greater wattage or different shape than specified on the label.
• If any modification is made it will invalidate the warranty and may render the product unsafe.
• If the glass or diffuser is broken or cracked it must be replaced, please consult your retailer. This is the
symbol which denotes this requirement:
• If there is a "Minimum Distance" Label, please do not allow Flammable Materials to rest within that dis-
tance from the lamps.
• If the Light Fitting must not be mounted on combustible surfaces there will be the above symbol on it.
• If there is no symbol then the Light Fitting may be mounted on any surface, including combustible ones.
Minimum Distance: This is
the symbol which denotes
this requirement.

Care Information

Allow 10 minutes to cool before replacing, adjusting or cleaning.
Clean with a dry cloth only. Do not use liquid or abrasive cleaners on this product.

Assembly/ User Instructions

Please read these instructions carefully before fitting and retain for reference.
Check the packaging and make sure that you have all the required parts.
Follow each assembly step in order to prevent incorrect assembly.
Ensure that the product is fully assembled as illustrated before use.
The Light pack contains:
Light fitting.
Terminal connection block(s).
Fixing pack.
These assembly diagrams are intended as a guide – if in doubt consult a qualified electrician.
Endon Lighting, LS9 0SE
Burford Bollard (IP44 Rated)
INSTRUCTION MANUAL
DISTANCE
Before you start
Luminaires not suitable for direct mounting
On normally flammable surfaces (surface
Mounted)
The following tools may be required:
Selection of cross and flat head screwdrivers.
Electric drill and assorted drill bits.
Wire strippers.
Electrical insulation tape.
56192-Burford-bollard 20150813
