5 9 0 5 A
L o o p L i n k & P R e s e t
N o . 5 9 0 5 A V 1 0 2 - I N ( 0 7 0 6 )
F r o m s e r . n o . 0 3 0 0 6 6 2 9 5
S I G N A L S T H E B E S T
COMMUNICATIONS INTERFACE
LOOP LINK 5905A
CONTENTS
Warnings ............................................................................ 12
Safety instructions .............................................................. 13
Declaration of Conformity .................................................. 15
Guidelines on how to replace batteries ............................. 16
Connection of Loop Link 5905A ........................................ 16
®
95/98/-NT ................................. 18
